6580-WS SERIES
6580-WS Heavy Duty Commercial Wi-Fi Smart Lock
This Wi-Fi-enabled smart lock can be connected directly to the internet without a hub. The 6580-WS series locks are GRADE 1 Commercial suitable for heavy use in a business or commercial setting.
Key Features
- Designed to be easy to install, connect, manage and use.
- Embedded Wi-Fi for standard connectivity. No gateway or hub is required.
- Remote control and monitoring from anywhere using your smartphone or laptop.
- Supports passage mode, auto-lock mode, and passage schedules.
- Lock retains all programming and data even in the event of a power outage or internet interruption.
- Secure bi-directional encryption. Low battery warning indicator.
- Store up to 40 weekly access schedules (e.g., M-F, 9-5).
- Set notifications for user entry and alerts for unexpected issues.
- Lockout functionality after 5 incorrect code attempts.
- Utilize temporary codes for guests and visitor management. 2 override keys are included.
- Works with KeyinCloud ACS wired solutions.
|  |
Product Specifications
| Environment: | For normal internal and external use |
| Exterior Dimensions: | 8 (H) x 3 5/8 (W) |
| Interior Dimensions: | 8 (H) x 3 5/8 (W) |
| Backset: | 2¾ in. (70mm) |
| Locking Device: | Cylindrical Latch |
| Construction: | Zinc alloy, suitable for indoor & outdoor use |
| Operating Temperature: | -31°F (-35°C) to 151°F (66°C) |
| Thickness: | 1 3/8 – 2 3/4 in. (35mm – 60mm) |
| Door Handing: | Non-handed, field reversible |
| Batteries: | 4 AA (not included) |
| Keyway: | 6-pin Schlage C (SF IC core available) |
| Code Length: | 4 – 10 digits |
| Code Capacity: | Up to 3,500 |
| Communication: | Single band 2.4GHz Wi-Fi (IEEE 802.11b/g/n) with WPA/ |
| Standards: | WPA2 Tested to Grade 1 Certified to ANSI A156.2/A156.25 |
