LLRGBX18 Pixel Dynamic Color LED Strip
Product Information
The LLX18 Pixel SPI is a small profile and energy-efficient
pixel color-changing light strip. It is designed for indoor use and
can be easily installed directly on the mounting surface using
double-sided tape or within discrete mounting extrusions. This
smart pixel-controlled LED strip features a microcontroller every
six LEDs, resulting in a uniquely controlled pixel every four LEDs.
With the LineLED RGB X18 with SPI protocol pixel control, you can
achieve infinite RGB lighting possibilities.
Features:
- Dynamic Color, RGB Pixel SPI – 24 VDC
- Easily installed with double-sided tape or within mounting
extrusions - Mind-blowing animations such as cascading and chasing
effects - Smart pixel-controlled LED strip
- Infinite RGB lighting possibilities
Technical Information:
- Type: LLRGBX18
- Output Options: RGB, RGBW
- Lumens Output: 169 lm/ft (LLRGBX18), 256 lm/ft (LLRGBWX18)
- Average Power Consumption: 4.5 W/ft (LLRGBX18), 5.7 W/ft
(LLRGBWX18) - Efficacy: 38 lm/W (LLRGBX18), 45 lm/W (LLRGBWX18)
- Cutting Increment: 3.94″
- Pitch Length: 0.66″
- Max Run Length (in series): 30 ft (LLRGBX18), 20 ft
(LLRGBWX18) - Dimensions: 0.39″ W x 0.09″ H
Accessories:
- CL1 Mounting clip
- LVSP-4T-BK Low Voltage, 4 Terminal Splice Box, Black
- LL.ZIP Strain relief clip (zip tie included)
Product Usage Instructions
To install the LLX18 Pixel SPI light strip, follow these
steps:
- Clean the mounting surface thoroughly to ensure proper
adhesion. - Peel off the backing of the 3MTM adhesive transfer tape on the
strip. - Stick the strip onto the desired mounting surface, ensuring it
is aligned correctly. - If using discrete mounting extrusions, follow the
manufacturer’s instructions for installation.
To control the LLX18 Pixel SPI light strip, use the following
instructions:
- Connect the power supply to the strip’s operating voltage of 24
VDC. - Use a compatible smart pixel controller or SPI protocol
controller to control the lighting effects. - Refer to the controller’s manual for instructions on
programming and controlling the pixel animations.
Note: The LLX18 Pixel SPI light strip is designed for indoor use
only. Avoid exposure to moisture or harsh environments.
LLX18 Pixel SPI
Dynamic Color, RGB Pixel SPI – 24 VDC
LLRGBX18
Features
LLRGBX18 Pixel SPI is a small profile and energy efficient pixel color-changing light strip. It is easily installed directly on to the mounting surface with double sided tape or within discrete mounting extrusions.
LLRGBX18 is a smart pixel controlled LED with a microcontroller every six LEDs resulting in a uniquely controlled pixel every 4″. This advanced design allows for mind blowing animations such as cascading and chasing effects at the granular level.
Infinite RGB lighting possibilities are now achievable with ease when using the LineLED RGB X18 with SPI protocol pixel control.
RGB
RGBW
Pixel
LLRGBWX18
Mounting LLED strip is equipped with 3MTM adhesive transfer tape (9472LE).
Applications Indoor only – millwork, cove, architectural reveals, undercabinet, display case, handrail, accent lighting.
Approvals Class 2 damp listed
Operating voltage 24 VDC
Life (L70) 50,000 hours
Warrant y 5 years
LM80
Technical information
TYPE
OUTPUT OPTIONS
Lumens Output (all channels full on) Average Power Consumption (for a 4′ section) Efficacy
Cutting Increment
Pitch Length Max Run Length (in series) Dimensions
LLRGBX18 LLRGBWX18
SO
SO
169 lm/ft
256 lm/ft
4.5 W/ft
5.7 W/ft
38 lm/W
45 lm/W
3.94″
0.66″
30 ft
20 ft
0.39″ W x 0.09″ H
RGBW (3000K)
Tape
TM-30 CRI Rf Rg R9
LLRGBWX18-SO 93 91 99 64
Section Start/End Options SL Soldered lead wires (72″)
3.94″
72″ 0.39″
LF Lead Female 3″ cable
3.0″
LM Lead Male 3″ cable
3.0″
Dominant Wavelength
Color
RGB/RGBW
Red
621nm
Green
519nm
Blue
465nm
NC No connector
3.94″
0.39″
Ordering code
MODEL
OUTPUT
COLOR TEMPERATURE
SECTION START
SECTION END
LENGTH
–
–
–
–
–
LLRGBWX18 – LineLED LLRGBWX18 SO – Standard PXSPI – Smart Pixel Control (SPI) LLRGBX18 – LineLED LLRGBX18
SL – Soldered lead wires (72″) LF – Female Quick Connect LM – Male Quick Connect NC – No Connector
SL-Soldered lead wires (72″) LF-Female Quick Connect LM-Male Quick Connect NC-No Connector
Ordered in one foot increments. See chart above for max run length.
REV0.1 04182023
page 1 of 6
www.luminii.com tel: 224-333-6033
LLX18 Pixel SPI Dynamic Color, RGB Pixel SPI – 24 VDC
Accessories
CL1 Mounting clip
LVSP-4T-BK Low Voltage, 4 Terminal Splice Box, Black
0.20″ 0.05″
0.40″ 1.00″
0.23″
Recommended every 12″ when LineLED strip is facing down
3.00″
0.90″ 1.90″
LL.ZIP Strain relief clip
0.19″ 0.37″
0.77″
zip tie included
4.25″
REV0.1 04182023
page 2 of 6
www.luminii.com tel: 224-333-6033
LLX18 Pixel SPI Dynamic Color, RGB Pixel SPI – 24 VDC
Lens Options / Light Transmission
C
HF
Clear
Half (50%) Frosted
BOS Channel (BOSC-XX)
G
Graze
F
Frosted
CLA Channel (CLAC-XX)
FF
Flat Frosted
R
S
Raised
Square Frosted
MCAL Channel (MCALC-XX)
2.60″
0.60″
0.49″ 0.60″
0.84″
0.64″ 0.77″
1.50″
Q
13°
Round Square Frosted
13° Semi-Frosted
K45V Channel (K45V-XX)
0.75″
0.50″
0.75″
F SI R G
52% 66% 60% 76%
K45R Channel (K45R-XX)
0.75″
0.50″
0.75″
RF
61%
KRL Channel (KRLC-XX)
1.21″
S RQSF
62% 65%
KiloR Channel (KILORC-XX)
2.04″
1.44″
1.05″ 1.50″
CF
85% 75%
KM Channel (KMC-XX)
C
94%
Kilo Channel (KILOC-XX)
1.50″
1.05″ 1.50″
CF
85% 75%
KRM Channel (KRMC-XX)
1.01″
C HF F 13°
82% 68% 45% 75%
KL Channel (KLC-XX)
0.30″
0.70″ 0.83″
C HF F
81% 67% 51%
KS Channel (KSC-XX)
0.42″
0.70″ 0.83″
0.36″
C HF F
81% 67% 51%
KRS Channel (KRSC-XX)
1.01″
0.44″
0.56″ 0.69″
0.49″
0.56″ 0.69″
C HF F FF R G
82% 68% 45% 52% 58% 76%
KXL Channel (KXLC-XX)
0.50″
0.70″ 0.83″
0.63″
0.56″ 0.69″
C HF F FF G
82% 68% 45% 52% 76%
KRXL Channel (KRXLC-XX)
1.21″
0.63″
0.70″ 0.83″
0.55″
0.30″
0.56″ 0.69″
C HF F FF R M
86% 71% 56% 60% 85% 64%
RO15 Channel (RO15-XX)
0.71″
Ø1.50″
0.55″
1.40″
C HF F FF M
86% 71% 56% 60% 64%
C HF F
81% 67% 51%
C HF F
81% 67% 51%
CF
65% 41%
Installation
All mounting channels are field cuttable using miter saw with circular blade suitable for cutting aluminum.
Ordering
Extrusions are sold separately. View respective specsheets for details on ordering extrusions and their accessories (endcaps, mounting brackets, etc).
REV0.1 04182023
page 3 of 6
Led Dotting per Extrusion
using the frosted lens option
Extrusion KSC , KRSC KMC , KRMC , K45V KXLC , KRXLC KLC , KRLC KILOC , KILORC
RO15 BOSC CLAC MCAL
LED Model LLRGBX18 CD CD SD CD SD SD CD SD ND
CD SD ND CD – Clear Dotting SD – Slight Dotting ND – No Dotting
www.luminii.com tel: 224-333-6033
LLX18 Pixel SPI Dynamic Color, RGB Pixel SPI – 24 VDC
Power Consumption
Tested at full power with PDC Series power supplies.
Nominal Length 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
LLRGBX18
W/ft
Total Wattage
4.6
4.6
4.6
9.1
4.5
13.1
4.5
17.4
4.4
21.7
4.4
25.8
4.3
29.8
4.3
33.4
4.2
37.2
4.2
40.9
4.1
45.7
4.0
49.2
4.0
52.3
3.9
55.6
3.9
58.8
3.8
61.8
3.7
64.0
3.7
66.8
3.7
69.4
3.6
72.0
3.6
74.6
3.5
75.9
3.4
78.2
3.4
80.2
3.3
82.3
3.3
84.3
3.2
85.0
3.1
86.7
3.1
88.2
3.0
89.7
LLRGBWX18
W/ft
Total Wattage
5.7
5.7
5.7
11.3
5.7
16.5
5.6
21.9
5.5
27.1
5.5
32.3
5.4
37.1
5.3
41.6
5.3
46.4
5.2
51.2
5.1
57.4
5.1
61.9
5.0
66.0
4.9
69.6
4.8
73.0
4.7
76.2
4.6
78.4
4.5
81.2
4.4
83.6
4.3
86.0
REV0.1 04182023
page 4 of 6
www.luminii.com tel: 224-333-6033
LLX18 Pixel SPI Dynamic Color, RGB Pixel SPI – 24 VDC
Voltage Drop Calculator
The below chart assumes nominal voltage of 24 Volts and a Voltage Drop Allowance of 3% through the wire
Wattage [W] 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 96
12 AWG 1088.2 544.1 362.7 272.0 217.6 181.4 155.5 136.0 120.9 108.8
98.9 90.7 83.7 77.7 72.5 68.0 64.0 60.5 56.7
Maximum Wire Length From Power Supply to Start of Run [ft]
14 AWG
16 AWG
18 AWG
20 AWG
22 AWG
684.4
430.3
270.6
170.2
107.1
342.2
215.1
135.3
85.1
53.5
228.1
143.4
90.2
56.7
35.7
171.1
107.6
67.7
42.6
26.8
136.9
86.1
54.1
34.0
21.4
114.1
71.7
45.1
28.4
17.8
97.8
61.5
38.7
24.3
15.3
85.5
53.8
33.8
21.3
13.4
76.0
47.8
30.1
18.9
11.9
68.4
43.0
27.1
17.0
10.7
62.2
39.1
24.6
15.5
9.7
57.0
35.9
22.6
14.2
8.9
52.6
33.1
20.8
13.1
8.2
48.9
30.7
19.3
12.2
7.6
45.6
28.7
18.0
11.3
7.1
42.8
26.9
16.9
10.6
6.7
40.3
25.3
15.9
10.0
6.3
38.0
23.9
15.0
9.5
5.9
35.6
22.4
14.1
8.9
5.6
24 AWG 67.3 33.7 22.4 16.8 13.5 11.2 9.6 8.4 7.5 6.7 6.1 5.6 5.2 4.8 4.5 4.2 4.0 3.7 3.5
REV0.1 04182023
page 5 of 6
www.luminii.com tel: 224-333-6033
LLX18 Pixel SPI Dynamic Color, RGB Pixel SPI – 24 VDC
Power Supply
See fixture and power supply instructions & spec sheet for wiring information. Dimming possible in select models – view Luminii website for list of compatible dimmers.
Non-Dimming Power Supply
MODEL
POWER
OUTPUT
–
–
–
PSV – PSV Series 96 – 96 Watt 24 – 24 VDC
DIMMING
ND – Non Dimming
LOCATION
D – Damp
MODELS Length Width Depth
96W 8.25″ 3.75″ 1.63″
PSV-96-24-ND-D
INPUT 120 – 277VAC
Neutral Ground
Load
To on/off Switch
24V DC+ To Decoder
24V DC-
Decoders
Programmable advanced DMX512 lighting controller featuring a touch-screen interface. Operates as stand alone controller or integrated with most architectural lighting control systems. Can controller endless DMX512 enabled devices.
Mounts to standard single or dual gang wall box with the included power supply inside the junction box. Terminal block design for power and data connections.
MODEL TSDMX-E TSDMX-E – Touchscreen DMX controller
Features
· Sleek glass design which sits 0.43″ from the wall
· Graphical color display to show selected environment
· Color/dimmer/speed palette
· Color temperature mixing
· Touch sensitive buttons. No mechanical parts
· Touch sensitive wheel allows for accurate color selection
· Multi-zone microSD memory
· Multi-room control with 500 scenes, 10 zones
· 1024 DMX channels. Control 340 RGB fixtures
· USB & Ethernet connectivity for programming and control
Power Supply 7 VDC (included) Pr ogrammabili t y PC, Mac, Tablet, Smartphone Output Signal DMX512 (1024 channels) Color Parameters · Brightness · Saturation · Speed of color changing sequence · Fading / dimming / brightness
MODEL SR-DMX-SPI SR-DMX-SPI – Smart Pixel Decoder
REV0.1 04182023
The SR-DMX-SPI is a smart LED pixel decoder that controls RGB/RGBW pixel LED strips with SPI signal. Designed with an OLED backlit panel, the pixel controller allows for easy configuration of most settings. Four push buttons are available for control of the LED functions.
Features
· 1024 DMX channels. Control 340 RGB fixtures
· SPI signal output for RGB/RGBW pixel light control
· DMX512 controllable and RF/WIFI remote controllable
· Capable of addressing up to 1020 RGB pixels & 765 RGB pixels
· OLED panel allows for easy configuration
Operating Voltage 12-36 VDC Power Capacity up to 96W at 24V Operating Temperature Range from -4°F to +122°F in case
page 6 of 6
www.luminii.com tel: 224-333-6033
