aiwa AI1001 Prodigy Air 2 Wireless Bluetooth Earbuds
Overview
| Model Number | AI1001 | |||||
|
Before Use |
Wake up Earbuds: | Put the earbuds into the charging case, then take out the earbuds from charging case, this action will exit the “storage mode” and wake up earbuds. | ||||
|
Blutooth Pairing |
1. Power on & Pairing |
Take out the earbuds from charging case,the indicators of Right and Left Earbuds flash blue and red alternately. If two earbuds paired successfully, the indicator of one earbud will turn off and the indicator of the other earbud will flash blue and red alternately. |
Binaural Mode | Power on Manually | Press and Hold Left/Right Earbud 3 seconds | |
| Power off Manually | Press and Hold Left/Right Earbud 4 seconds | |||||
| Increase Volume | Click Right Earbud | |||||
| Decrease Volume | Click Left Earbud | |||||
| Next Track | Double Clicks Right earbud | |||||
| Previous Track | Double Clicks Left earbud | |||||
| Music play/Pause | Press and Hold Right Earbud 2 seconds | |||||
|
2. Search Pairing Name |
2.Search pairing name on device: AIWA Connect Pro | Voice Assistant | Press and Hold Left Earbud 2 seconds | |||
| Answer Call | Click Left/Right Earbud | |||||
| End Call | Press and Hold Left/Right Earbud 2 seconds | |||||
| Decline incoming call | Double Clicks Left/Right earbud | |||||
| Low Latency On/Off | Triple Clicks Left/Right earbud | |||||
|
3. Connect to Device |
3.Click the pairing name,if connection is succesful, the light is off. |
Monaural Mode: | ||||
| Decrease Volume | Single Click | |||||
| Increase Volume | Double Clicks | |||||
| Voice Assistant | Press and Hold Right Earbud 2 seconds | |||||
|
Auto shut down after 5 mins, if BT does not connect to BT device |
Reset Funtion | 1. turn off Bluetooth device and turn off bluetooth Earbuds. 2. Take out one earbud from charging case, the indicator light flashes red and blue alternately, and then click the button four times quickly to turn off the earbud. 3. Take out the other earbud and repeat the step 2 | ||
|
Charging | Charging （Earbuds) | Solid Red |  | |
| Charging Complete (Earbuds) | Light off | |||
| Charging (Charging case) | Blue light flashes | |||
| Charging complete (Charging case) | Blue light on | |||
| Charging time | About 2-3 Hours | |||
FCC Warning Statement
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
- This device may not cause harmful interference, and
- This device must accept any interference received, including interference that may cause undesired operation.
