Hios Pg-3000 Pg Series Pg-01 Brushless Screwdriver With Built In Torque Sensor User Manual (+ PDF)

The Brushless Screwdriver with Built-in Torque Sensor is part of
the PG Series, specifically the PG-3000, PG-5000, and PG-7000
models. It comes with a Control Unit, the PG-01. The user’s manual
for this product is labeled ET-A034 22A.

03 Important Safety Instructions
04 Checking Supplied Accessories
05 Setting Up the Device
06 Parts and Their Functions
09 Start and Stop
09 Adjust Torque
10 Set Learning Values (Teaching)
11 Evaluation of Screw Tightening
14 Connect the ScrewDriver to PC
20 Troubleshooting
21 After-sales Service
21 Specifications

Important Safety Instructions

Please read this manual and the power supply unit manual
carefully before use to ensure proper operation.
Do not use the product in a way not described in this
manual.
Do not install the device in places of high humidity or with a
lot of dust, high temperatures, fire hazards, direct sunshine, or
containing corrosive gas in the air.
Be sure to install an earth leakage breaker and a safety
breaker on the commercial power source before using it.
Avoid wearing clothes with flippers on the cuffs, gloves,
neckties, etc., as they may get caught in the rotating screwdriver
and cause injury or failure.
Wear suitable clothing and protective eye-wear for work. Cover
long hair with a hat, etc., to ensure safety.
Turn off power when leaving the workplace or when
attaching/removing a bit or an optional item.
Neutralize static electricity before use.
Avoid an unstable place or an unreasonable posture for work to
prevent injury.
Avoid long-time work and take regular breaks to prevent strain
on hands, neck, arms, or waist.

Product Usage Instructions

Setting Up the Device

Connect the cords.
Install the bit.
Remove the bit.
Turn on the power.

Start and Stop

To start the screwdriver, follow the instructions provided in
the manual.
To stop the screwdriver, follow the instructions provided in
the manual.

Adjust Torque

Refer to the reference table of output torque in the manual to
adjust the torque settings according to your requirements.

Set Learning Values (Teaching)

The manual provides information on how to set learning values
for the screwdriver. Follow the instructions provided to ensure
accurate screw tightening.

Evaluation of Screw Tightening

The manual explains how to judge the tightening torque value as
OK/NG.
It also provides information on evaluating the operation time
and includes a flowchart of judgment.

Connect the ScrewDriver to PC

Check the port in case of Windows 10.
Connect the screwdriver to the PC using either RS-232C or USB
connection.
The manual provides details on data output format,
error-related output, measurement judgment output, and PC
input.

Troubleshooting

Refer to the troubleshooting section in the manual for
assistance in resolving any issues or problems you may
encounter.

After-sales Service

If you require after-sales service, refer to the manual for
information on how to proceed.

Specifications

External Dimension Drawing
Specifications of PG-01

View Fullscreen

Brushless Screwdriver with Built-in Torque Sensor
PG Series
PG-3000 / PG-5000 / PG-7000
Control Unit
PG-01
User’s Manual
ET-A034 22A

Table of Contents
03 Important Safety Instructions
04 Checking Supplied Accessories
05 Setting Up the Device
Connect the Cords Install the Bit
Remove the Bit Turn On the Power
06 Parts and Their Functions
PG-3000/PG-5000/PG-7000 PG-01
09 Start and Stop
Start the Screwdriver Stop the Screwdriver
09 Adjust Torque
Reference Table of Output Torque
10 Set Learning Values (Teaching)
About Learning Values
11 Evaluation of Screw Tightening
OK/NG Judgment of Tightening Torque Value Evaluation of Operation Time Flowchart of Judgment
14 Connect the ScrewDriver to PC
Check the Port In Case of Windows 10
Data Output Format by Either RS-232C or USB Connection Error-related Output Measurement Judgment Output
PC Input Hyper terminal (Example: Windows XP) Example of a Measurement OK Message Abnormal Conditions
Data Taking-in Sheet (HIOS-PG-0611-V2-2_5) Operating Environment Configuration of the Screen Other Sheet
Collection of Screwdriver Data (Application)
20 Troubleshooting
21 After-sales Service
21 Specifications
External Dimension Drawing Specifications of PG-01

Important Safety Instructions
Please read this manual and the power supply unit manual carefully before use to ensure proper operation. In addition, do not use the product in the way not described in this manual. Please note that we are not responsible for any problems caused by using the product in a manner that does not conform to the contents of this manual, using it improperly, or repairing / modifying by a third party except by us or someone specified by us.

Installation
Do not install the device at the places described below. Otherwise, it may cause a fire or a failure. A place of high humidity or with a lot of dust A place where it becomes high temperatures A place of fire A place of direct sunshine A place containing corrosive gas in the air Unstable place
Do not use the device where the ambient temperatures are out of the range of 5 to 40 °C.
Power Supply
Be sure to install an earth leakage breaker and a safety breaker on the commercial power source before using it.
Connect the earth wire to the earth wire terminal of the outlet. You may have an electric shock without the earth wire connection in case of an electric leakage.
Avoid the octopus foot wiring and use of an extension cord. Otherwise, it may cause a fire or an electric shock.
Do not connect anything other than specified to the connection part of this device. Otherwise, it may cause an electric shock or a failure.
Handling
Do not wear clothes with flippers on the cuffs, gloves, neckties etc. Otherwise, they may get caught in the rotating screwdriver and cause an injury or a failure.
Wear suitable clothing and protective eye-wear for work. Cover long hair with a hat etc. so that you can work safely.
Turn off power when you leave the workplace, or when you attach / remove a bit / an optional

item.
If static electricity is charged, you need to neutralize it before use.
Avoid an unstable place or an unreasonable posture for work. Otherwise, it may cause an injury.
Long-time work or some types of work may cause strain on your hands, neck, arms or waist, causing an injury. Avoid long-time work and take a break regularly.
We recommend use of a balancer to prevent the device from falling and to protect cords / wires.
Hold the plug when you attach / remove the power cord, screwdriver and so on.
Protect cords / wires by not giving damages to them; not remodeling them; not pulling them; not bending them forcibly; etc. Also, do not place heavy items on the power cord. Otherwise, it may cause a fire or an electric shock.
If you detect an uneven rotation, strange noises, overheating or activation of a breaker, etc., stop using the device immediately and have it repaired. However, note that the device may be overheated depending on the frequency of the workpiece or screw types. As a countermeasure, prepare spare screwdrivers of the same model to extend the tact time and use them alternately, or review the selection of screwdriver models.
Do not overload the device so much that it cannot clutch. Otherwise, it may cause a failure of the motor.
Do not touch the screwdriver while it is rotating. Otherwise, it may cause an injury or a failure.
Keep your hands and face away from the rotating section while in use. Otherwise, it may cause an injury.
Remove the bit from the screwdriver when you
03

are not working.
If you cannot attach / remove the bit in the way described in this document, please make contact with our service section.
Fix the workpiece with jig / clump while in working.
Do not use the switch lever as a hanger. Otherwise, it may cause an accident or an injury.
Do not give a strong impact or excessive force. Otherwise, it may cause a failure.
Do not operate the screwdriver with wet or oiled hands.
Do not operate the FOR / REV switch before the screwdriver completely stops. Otherwise, it may cause a failure.
Do not disassemble / remodel this device. Otherwise, it may cause a failure.
High torque has a large recoil on the hand or arm. Hold the driver firmly to avoid being swung around.
Maintenance and Inspections
Turn off power and remove the power plug from the outlet when the device is not in use for a long time.

Remove the accessories from the screwdriver and store them in the package box when it is not in use them for a long time.
Inspect the device regularly to confirm there are no damages. If you use it with damages, it may cause a fire or an electric shock.
When you clean the device, turn off the power and remove the power plug from the outlet. Otherwise, it may cause a fire or an electric shock.
Use dry cloth to wipe of dust or stains. The dust may absorb moisture to allow current to flow, causing a fire.
Store the device in a place where the appropriate temperatures and humidity are controlled.
Do not store the device in an unstable place or a place with vibrations. Otherwise, it may cause a failure.
Keep the device out of reach of anyone but people involved in the workpiece.
We recommend genuine HIOS parts for replacement.

Checking Supplied Accessories
If an item is missing or damaged, contact the store where you purchased the product. Screwdriver Bit Screwdriver Cord (2m) Sensor Cord (1.7m) PG-01 AC Adapter RS-232C Cable USB to RS-232 Conversion Cable* Manual User Software CD-ROM
* Please download and install the device driver for the USB to RS-232 conversion cable from the ATEN website.

Setting Up the Device
Connect the Cords
Connect all the attached cords. After all cords are successfully connected, put the power plug into an outlet.
CAUTION
Make sure the combination of the screwdriver and the power supply is appropriate. Make sure the power is off. Connect the plug and screwdriver cord to the power supply. Connect the screwdriver and sensor cords to the screwdriver and connect the sensor cord to
PG-01. Connect the AC adapter to PG-01.
Install the Bit CAUTION
Do not install or remove the bit with the power on. It may cause an accident. Insert the bit while pushing the joint shaft collar into the body.
Release the collar and check if the bit is locked. Pull the bit gently to confirm it does not come out.
Remove the Bit Pull out the bit while pushing the collar against the body.
Turn On the Power Turn on T-70BL and PG-01.
CAUTION
PG-01 automatically performs zero-adjustment when the power is turned on. Do not apply a load to the tip of the screwdriver or do not start the screwdriver during the adjustment.
05

Parts and Their Functions
PG-3000/PG-5000/PG-7000

PG-3000

PG-5000

PG-7000

Joint shaft collar Operate the collar to install or remove the bit.
Nut protection cover This protects the torque adjustment nut. Turn it counterclockwise for removal.
Torque adjustment nut Use this for adjustment of the output torque.
Switch lever Start the screwdriver with the lever.
Forward / reverse switch You can switch the screwdriver’s rotational direction. : Clockwise OFF: no rotation(PG-5000/PG-7000) : Counterclockwise
Screwdriver cord connector To connect the screwdriver cord.
Hanger To hang the screwdriver on the balancer or like.
Sensor cord connector To connect the sensor cord.
06

PG-01
The measurement result of tightening a screw will be informed by the indicator and sound.

Control Unit

Front Side

Back Side

L.NG Indicator This indicator is lit when the measured value is no good (smaller than the minimum pass value).
L.G Indicator This indicator is lit when the measured value is good (larger than the minimum pass value and below the minimum learning value).
GOOD Indicator This indicator is lit when the measured value is good (larger than the minimum learning value and smaller than the maximum learning value).
H.G Indicator This indicator is lit when the measured value is good (larger than the maximum learning value and below the maximum pass value).
H.NG Indicator This indicator is lit when the measured value is no good (larger than the maximum pass value).
Teaching Indicator This indicator is lit when in the teaching mode (for setting of learning values).
Teaching Button This is for setting to the teaching mode. Pressing and holding this button (2 seconds or longer) in the teaching mode will cancel the mode. For details of teaching, refer to “Set Learning Values (Teaching)” (P.10).
07

OPERATION OK Indicator This indicator is lit while the screwdriver is rotating positively.
OPERATION NG Indicator This indicator is lit when the operation ends without torque up. This blinks when the operation ends due to an abnormal measurement time.
Power Button This switch turns power on and off. Press and hold the button for 2 seconds to turn off the power.
Power Indicator This indicator is lit when power is supplied.
Sensor Cord Connector This is used to connect the sensor cord.
I/O Connector The I/O flat cable is connected here for the evaluation result to be output. The output format is an open collector. Use this when you cannot connect with RS-232C.

PIN No. 12 13 14 15
16 17

Output signal COM GND L.NG (NG) L.G (OK) GOOD (OK)
H.G (OK) H.NG (NG)

Description
—
Output when the measurement value is NG (below the minimum pass value)
Output when the measurement value is OK (equal to or larger than the minimum pass value and smaller than the minimum learning value)
Output when the measurement value is OK (equal to or larger than the minimum learning value and smaller than the maximum learning value)
Output when the measurement value is good (equal to or larger than the minimum learning value and smaller than the maximum learning value)
Output when the measurement value is no good (larger than the maximum pass value).

RS-232C Connector An RS-232C cable is connected here.

PIN No.

Signal name

I/O

RXD

OUT

TXD

GND

AC Adaptor Connector An AC adaptor is connected here. Power will be automatically supplied when an AC adaptor is
connected.

Start and Stop
Start the Screwdriver
Pull the switch lever to start the bit turning. Release it to stop turning.
Stop the Screwdriver
When the set torque is reached, the clutch in the screwdriver works to stop turning.
Adjust Torque
CAUTION
The “reference table of output torque” and the torque adjustment scale are approximate and do not guarantee actual setting values. For accurate torque check, please use an HIOS torque meter and Fidaptor. If the torque is determined beforehand, turn the torque adjustment nut and nut fixing ring
referring to the “reference table of output torque”. Turn the torque adjustment nut clockwise to increase the torque and turn it counterclockwise to decrease the torque. Adjust it so that the end face of the nut fixing ring is right above the scale. After the nut fixing ring is positioned, fit the torque adjustment nut accordingly.

Try to fasten a screw and check how it is fastened after the screwdriver stops and adjust the most appropriate torque.

PG-7000
PG-5000 PG-3000

Reference Table of Output Torque

0.55 N·m 0.5

1.2 N·m 1.0

0.4 0.8

0.3

0.6

0.2 12345678
Torque Scale

0.4 12345678
Torque Scale

N·m 2.8 2.6 2.4 2.2 2.0 1.8 1.6 1.4 1.2 1.0
1 2 3 4 5 6 7 8 9 10 Torque Scale
09

Set Learning Values (Teaching)
Measure the “tightening torque” and “working time” by using screws and materials actually used to set the reference values for work. The two values recorded are the minimum and maximum, respectively. Also, after teaching, it is possible to change the error tolerance of the learning values and the learned values in the attached application or Excel file.
CAUTION
Teaching should be done under the same conditions as actual operation. An error may occur in the measured value if the screw to be used, the materials to be fastened, the attaching method of the screw, etc., are different from actual operation. Press and hold the teaching button.
Control Unit
A buzzer sounds in about 2 seconds and the teaching mode is enabled. The teaching indicator is lit. L.NG indicator and H.NG indicator blinks. Using the screws and materials to be actually used, perform tightening more than 3 times.
Every time after tightening is completed, a buzzer sounds once, and the measured value is recorded. The measured values of the third to tenth trials are recorded and the values after the eleventh trial
will overwrite the old values. Press and hold the teaching button.
A buzzer sounds in about 2 seconds and the teaching mode ends. The teaching indicator, L.NG indicator and H.NG indicator turn off.
About Learning Values
The learned values do not disappear even when the power is turned off. To reset the learned values, perform teaching again. The previous learned values will be deleted when
the teaching mode is enabled. After purchasing, please perform teaching with PG-01 for the first time. Otherwise, it is not possible to
set learning values with the attached application.
10

Evaluation of Screw Tightening
It measures actual screw tightening work in real time, compares the measurement with the learning value, and informs the user of the evaluation result with a indicator and sound.
The reverse rotation of the screwdriver is not evaluated. The allowable error range at the time of purchase is set to 10% for both upper and lower limits. If you
want to change it, please use the attached application.

OK/NG Judgment of Tightening Torque Value
If no error is detected in the screw tightening work, one of L.G, GOOD or H.G indicator is lit and the buzzer sounds.

Allowable error range Lower limit value

Allowable error range Upper limit value

Threshold value

Learning value

Threshold value

If the torque is within the learning values, the GOOD indicator will be lit, and if it falls within the allowable error range, either L.G or H.G indicator will be lit. Conversely, when the torque is less than the lower limit value, the L.NG indicator will be lit, and when the torque exceeds the upper limit value, the H.NG indicator will be lit, which means fail.

Evaluation of Operation Time
The operation time from start of rotation to stop of the screwdriver is evaluated against the learning values.
The blinking and lighting of the OPERATION NG indicator will turn off when the START signal is entered again.
Control Unit
Main reasons why OPERATION NG indicator is lit No torque up signal is sent because of reasons like screwdriver idling. Main reasons why OPERATION NG indicator blinks A torque up signal was not sent during the learning measurement period.
If it is not necessary to strictly measure the operation time, by using the application, change the setting value so that the learning interval will become larger. Continuous ON/OFF operations at the end of tightening (pushing the button twice or three times in a row)
CAUTION
There is a nonintervention time of 100mS for torque measurement and evaluation after the START is input.
Nonintervention time of 100mS
If the screwdriver output is given to a screw even after tightening, the value will be larger than the measuring value and not the expected tightening value. To perform proper screw tightening, please do not perform continuous operations.
12

Flowchart of Judgment

Power ON

Select an operation

Set the judgment value (TEACHING)

L.NG, and H.NG blinks if no teaching value is set.

Normal operations

Set the evaluated value TEACHING LED is lit (red) L.NG & H.NG LED blinks (red)

The set value can be changed later from the tabulation software on the connected PC.

Tightening ON LED OFF at completion Initial resetting of PG-01

OPERATION OK LED ON (green) One beep

End of tightening (Torque up signal)

No torque up signal OPERATION NG LED ON (red)

NG Evaluation
OK
L.G, GOOD or H.G LED ON (green) One beep Signal output

L.NG LED or H.NG LED ON (red) If measurement time is NG, OPERATION NG LED blinks (red) Two beeps Signal output

End

Connect the ScrewDriver to PC
Connect the RS-232C cable to PG-01. Connect the USB to RS-232C conversion cable to the RS-232C cable. Connect the USB to RS-232C conversion cable to PC. Download the device driver from the ATEN website and install it on PC.
Check the website for how to install and supported OSs. https://www.aten.com/global/en/products/usb-peripherals/usb-converters/uc232a/ Turn on PG-01.
Check the Port
Open the device manager to check which port PG-01 is connected to. In Case of Windows 10 Right-click the Start button and select Device Manager.
Click the port (COM and LPT) in the list and check COM number displayed in <ATEN USB to Serial Bridge (COMXX)>.
14

Data Output Format by Either RS-232C or USB Connection
The data for judgment is output for each measurement in the three formats in the sequence below.

Measurement Data

D10XXXXXXXXX<LF>

Torque conversion value 4 digits

Measurement time 5 digits (unit: mS)

Recorded Learning Value

D00XXXXXXXXXXXXXXXXXXXXXX<LF>

Display learning number

Display learning minimum value

Display minimum learning measurement time

Display learning maximum value

Display maximum learning measurement time

Judgment reference values

D20XXXXXXXXXXXXXXXXXXXX<LF>

Judgment error rate

Judgment minimum value

Judgment measurement time minimum value

Judgment maximum value

Judgment measurement time maximum value

Error-related Output E90 End which cannot be detected by 0 areas, and judged E91 Abnormal termination at measurement time
E92 Study shortage and end which cannot be judged
E93 Judgment=LOW NG E94 Judgment=HIGH NG

[Zero area detection/Impossible judgment ending] [The abnormally end at the measurement time] [The ending about which it is impossible to judge by the learning lack] [Judgment = Low NG] [Judgment = High NG]

Measurement Judgment Output
E00 Judgment=GOOD E01 Judgment=LOW OK E02 Judgment=HIGH OK

[Judgment = Good] [Judgment = Low OK] [Judgment = High OK]

PC Input

Hyper terminal (Example: Windows XP)
After the PC is turned on and the version information is displayed, auto-zero correction is performed. The following messages for debugging are displayed that are not directly related to measurement.
Ver3.04 2022/05/25 [Zero Adj A/D=7C2 G=1EA F=200] [Zero Adj A/D=806 G=1EB F=200] [Zero Adj A/D=808 G=1EC F=200] [Zero Adj A/D=803 G=1ED F=200] [Zero Adjustment end A/D=7FF Gain=1ED]

Example of a Measurement OK Message In general, messages are either operation check messages or measurement data.

[Job Num = 4] S00 [Lever SW ON] [Job Num = 6] S02 [Torque UP ON]

Operation check message for debugging

D10026900668 D000005026903150033701891 D2002026303210033001928

Measurement data

M21[Judgment=LOW OK] E01 [Judgment end]

Operation check message for debugging

Abnormal Conditions

This displays the condition when judgment results are abnormal.

[Job Num = 4] S00 [Lever SW ON] [Job Num = 6] S02 [Torque UP ON]

Operation check message for debugging

D10028600590 D000006009600010000101894 D2002140513090131201931

Measurement data

[Abnormal termination at measurement time] E91

Operation check message for debugging

Data Taking-in Sheet (HIOS-PG-0611-V2-2_5)
By using the data taking-in sheet in the attached CD-ROM, you can check the OK/NG of screw tightening on the PC or record the measurement data.
CAUTION
Enable macros.

Start settings after turning on PG-01 and connecting it to the PC. When using USB, the PC may turn off PG-01 automatically in some cases. In that case, please
disconnect and reconnect the screwdriver.
There is no reaction to the reverse rotation of the screwdriver. If you want to take in two types of data, create two files (for example, test1.xls and test2.xls) in
advance. Then, start up two applications, and then open each file.
If you open files by double-clicking them in Windows Explorer, two files are opened in the same
application and the application cannot be used.

Operating Environment
The data taking-in sheet was confirmed to be effective in the following environments: Microsoft Windows XP Microsoft Excel 2003 If it is not functioning, select application type “screwdriver data collection”. Please be aware that maintenance and support services are unavailable since this is sample software.

Configuration of the Screen

Connection confirmation window

The login information is displayed.
Disconnect button This ends data import.
Connect button This makes the data import standby. If the previous data is necessary, please save the current data first and then connect the screwdriver. (The previous data will be cleared upon connection.)
COM port Check the port number and enter it. Then, press [Enter] on the keyboard. Usually, select COM as the port. Cell colors Gray: the screwdriver is not connected. Yellow: the screwdriver is connected.
LAN settings Optional
Judge On/Off Errors E90/E91/E92 can be turned ON/OFF. ON: the measured values are entered in the datasheet. OFF: the measured values are entered in the irregular sheet.
Measurement settings processing table The table shows commands and settings processing that are displayed in the log.
Judgment This indicates OK/NG of screw tightening with colors.
Output data Torque equivalent value: this indicates values taken during actual operation. Measurement time: this indicates the time from screw tightening to torque-up. Number of the learning: indicates the number of teaching operations performed. Minimum of the learning: indicates the minimum teaching value (modifiable). Maximum of the learning: indicates the maximum teaching value (modifiable). Measurement time of minimum: indicates the teaching minimum time (modifiable). Measurement time of maximum: indicates the teaching maximum time (modifiable). After inputting a number, press [Enter] on the keyboard. These learning-related values will be sent to PG-01 by clicking the [Write learn-value] button after entering a number. If the [Learned value change] button is not pressed, the memory in PG-01 won’t be updated and the previous value will be recovered after the next torque-up operation.
Judgment comparison data Torque value: indicates the value output on the graph sheet. Judgment minimum value: indicates the amount minus the % setting for the learning minimum value. Judgment maximum value: indicates the amount plus the % setting for the learning maximum value. Meas. Time of judge minimum: indicates the amount of the time minus the % setting for the learning minimum measurement time. Meas. Time of judge maximum: indicates the amount of the time plus the % setting for the learning maximum measurement time.
Judgment error rate (%) This sets the acceptable evaluation threshold before a screw tightening operation.
18

Selecting the judgment error rate while the screwdriver is connected transmits the selected rate to PG-01. Even after disconnecting the PC, the selected rate will be retained. The selectable rates: 0%, 2%, 5%, 10% or 20% (02=2%) Work On Normally this turns on automatically when an operation is performed.
Other Sheet

Collection of Screwdriver Data (Application)
The operation data is collected in the same way as the data taking-in sheet. The data is saved in the CSV format. For details, click [Instructions] on the screen of screwdriver data collection.

Troubleshooting
If you have any problem while using this machine, please check the items in this section before making inquiries. Then, if the problem persists, please contact your dealer or us.
The L.NG or H.NG indicator blinks when the power is turned on.
There is a possibility that the learning values are not set correctly. Repeat teaching 3 times or more to set the learning values.
The L.NG or H.NG indicator flashes even when the teaching mode is ended and measurement cannot be performed.
There is a possibility that data for evaluation comparison is insufficient. If the learning count is less than 3, the indicator will keep flashing even if the teaching mode ends. Repeat teaching 3 times or more again to set the learning values. In the following cases it is difficult to make an evaluation, and it may not be counted as learning. Torque value is 10 or less (“E90” [Zero area detection/Impossible judgment ending]) Idling of the screwdriver occurs or the measurement time is 100 mS or shorter. (“S01” [Lever switch Off(no torque up)])
Setting cannot be changed from the tabulation software.
Click the [Write learn-value] button after input of a number. The settings in PG-1 will be updated by clicking the [Write learn-value] button.
The torque is abnormally low or high.
Turn off the power to check if the cords are connected correctly and then turn on the power again. If the problem persists, replace the sensor cord.
When a Problem Cannot Be Solved
When contacting us, have the following information ready: Product name Description of the problem (detailed description of the operation performed and its result, etc.) Serial number (on the label of the product)
20

After-sales Service
The PG Series is equipped with an axial force sensor. We recommend overhauling and inspecting the axial force sensor about once a year depending on usage conditions.

Specifications

The product specifications are subject to change without prior notice due to improvements of the product.

Model

PG-3000

PG-5000

PG-7000

Start Type

Lever

Output Torque Range (N·m)

0.20.55

0.41.2

1.02.8
