1859154 4.5 Foot PE Blend Potted Tree
Product Information
The 4.5 FT PE Blend Potted Tree is a pre-lit artificial
Christmas tree that comes with three sections: two pre-lit tree
sections marked with corresponding hang tags (A and B) and a resin
pot base. The tree is powered by a power cord that needs to be
plugged into an electrical wall outlet. The tree comes with a
replacement fuse and bulb.
Product Usage Instructions
- Choose a location near an electrical wall outlet for the
tree. - Place the pot base on a level surface and insert the bottom
section (B) into the pot, making sure the pole is firmly inserted
and secured into the pot. Insert the top section (A) into the
bottom section (B). - Gently shape all branches and tips into place, beginning with
the tips closest to the interior pole. For each branch, position
one tip to the right, one tip to the left, and one at the center of
each main stem. Repeat this pattern for each branch until
complete. - Plug the tree into a wall outlet.
- If the entire tree or tree section (top or bottom) does not
light, check to see if all plugs are properly connected and verify
that the power cord is plugged into the wall outlet. - If a strand of lights does not light:
- Check that all bulbs tightly fit inside their sockets and
ensure no bulbs are broken or missing. Replace broken or missing
bulbs with the provided replacement bulbs. If all bulbs are firmly
in the sockets, slightly twist the bulbs from side to side to
ensure proper connection. - Check the fuse in the mini light cord and replace if necessary.
IMPORTANT: This is the only time you should remove the tape
wrapping the outlets of the mini lights. Please remove tape to
inspect 3-Amp fuse and replace tape to original condition after
inspecting. - If the lights still do not work, carefully remove each bulb,
one by one, from the problem light string. Pull both the bulb and
plastic base straight out of the socket. Do not twist bulbs while
removing from sockets. Check the two wires located at the bottom of
the bulb holder. Each wire should be aligned properly on the bulb
holder to ensure a proper connection with the lamp socket. If one
wire is missing or too short, please replace it with the provided
replacement bulb.
- Check that all bulbs tightly fit inside their sockets and
- If the fuse blows, first unplug the tree from the wall outlet.
Then, replace the fuse, per the instructions below and follow
product marking for the proper fuse rating. If the replacement fuse
blows, a short circuit may occur, and the product should be
reviewed to determine the cause.- Light set fuse replacement (replaceable 3-amp 125V fuses are
located inside the plug, as seen in Figure 2.)
- Light set fuse replacement (replaceable 3-amp 125V fuses are
4.5 FT PE BLEND POTTED TREE
Instruction Manual
SKU# 1859154
Please read instructions carefully before use. Retain for future reference.
Assembled Dimensions
PARTS LIST: No. Description
1
Pre-Lit Tree Section A
2
Pre-Lit Tree Section B
3
Resin Pot
No Assembly Tools Required
Quantity No. Description
1
4
3-Amp 125V
Replacement Fuse
1
5
Replacement Bulb
1
1
Quantity 2 6
IMPORTANT SAFETY INSTRUCTIONS: · This product is equipped with push-in type bulbs. Do not twist bulbs. · This product employs an overload protection (fuse). A blown fuse indicates an overload or short-
circuit situation. If the fuse blows, unplug the product from the outlet. Also, unplug any additional strings or products that may be attached to the tree. Replace the fuse as per the Use and Care Instructions section below and check the product. If the replacement fuse blows, a short circuit may be present and the product should be discarded. · This tree includes a polarized plug (one blade is wider than the other) as a feature to reduce the risk of electric shock. Do not replace attachment plug. Discard the product if the attachment plug is damaged. · This product is FOR INDOOR USE ONLY. · When adjusting branches make sure all wires are free from the branch hinges. · This is an electrical product not a toy! To avoid risk of fire, burns, personal injury, or electrical shock it should not be played with. · Do not mount or place near gas or electric heaters, fireplaced, candles, or other similar sources of heat. · Do not cover product with cloth, paper or any material when product is in use. · Do not hang ornaments or other objects from the cord, wire or light strings. Hang ornaments only on the tree branches. · For your safety, unplug the product if left unattended. · Do not let bulbs rest on the supply cord or on any wire. · To reduce the risk of overheating, replace burned out bulbs promptly. Use 2.5V, 0.425W maps only.
ASSEMBLY INSTRUCTIONS: 1. Before you start to assemble your tree, please choose a location near an electrical wall outlet.
Place the pot base on a level surface. a. Open the box and identify the three sections: base pot, top section and bottom section, marked with corresponding hang tags (A and B) on each tree section. Please follow the diagram provided for assembly.
2. Insert the bottom section (B) into the pot. Make sure the pole is firmly inserted and secured into the pot. Insert the top section (A) into the bottom section (B). (Fig.1)
3. Once the tree sections are put together, gently shape all branches and tips into place. Begin by shaping the tips located closest to the interior pole. For each branch, position one tip to the right, one tip to the left, and one at the center of each main stem. Repeat this pattern for each branch until complete.
4. Plug your tree into a wall outlet.
Fig. 1
2
USE AND CARE INSTRUCTIONS:
· Inspect product carefully before using or reusing.
· To store, disassemble the tree and place in its original box. Store tree in a cool dry place where the
temperature does not exceed 100 degrees Fahrenheit.
· This product is for indoor use only and is for decoration only.
· Not a toy and not intended for children.
· If any lights do not work on your pre-lit tree, please check the following:
a. If the entire tree, or tree section (top or bottom) does not light check to see if all plugs are
properly connected and verify the power cord is plugged into the wall outlet.
b. If a strand of lights doesn’t not light:
i. Check that all bulbs tightly fit inside their sockets and ensure no bulbs are broken or
missing. Replace broken or missing bulbs with the provided replacement bulbs. See
the Bulb Replacement section for further instructions). If all bulbs are firmly in the
sockets, slightly twist the bulbs from side to side to ensure proper connection.
ii. Check the fuse in the mini light cord and replace if necessary. IMPORTANT: This is
the only time you should remove the tape wrapping the outlets of the mini lights.
Please remove tape to inspect 3-Amp fuse and replace tape to original condition
after inspecting.
iii. If the lights still do not work, carefully remove each bulb, one by one, from the
problem light string. Pull both the bulb and plastic base straight out of the socket. Do
not twist bulbs while removing from sockets. Check the two wires located at the
bottom of the bulb holder. Each wire should be aligned properly on the bulb holder to
ensure a proper connection with the lamp socket. If one wire is missing, or too short,
please replace it with the provided
replacement bulb.
· Fuse Replacement: This product comes with overload
protection (fuse). A blown fuse indicates an overload or
short circuit. If a fuse blows, first unplug tree from the wall
outlet. Then, replace the fuse, per the instructions below and
follow product marking for the proper fuse rating. If the replacement fuse blows, a short circuit may occur, and the
Fig. 2
product should be reviewed to determine the cause.
a. Light set fuse replacement (replaceable 3-amp 125V
fuses are located inside the plug, as seen in Figure 2.)
i. Disconnect the string of lights that will not light from the working light sets.
ii. Locate the blown fuse by sliding access cover on top of the plug towards prongs.
iii. Remove the blown fuse by turning the plug over. The fuse should fall into your hand.
Gentle tapping may be required to dislodge the fuse.
iv. Locate the spare replacement fuses in the spare parts bag.
v. Insert the new fuses. Close the fuse cover by sliding the fuse access cover towards
the cord.
vi. CAUTION: To reduce the risk of fire replace the fuse in mini light sets with only 3-
amp 125-volt fuse. Do not replace the attachment plug. Discard the product if the
attachment plug is damaged.
· Bulb Replacement:
a. Make certain the tree is unplugged from the electrical outlet.
b. Pull the bulb and plastic base straight from its socket. Do not twist bulbs while you are
removing them.
3
c. Additional bulbs are included in the spare parts bag. Replace burned-out bulbs with replacement bulbs included with this product packing only.
· This product contains a cord with a polarized plug to reduce electrical shock. If the plug doesn’t fit fully into the outlet, reverse the plug as it is designed to only fit one way. If the plug still does not fit, contact a qualified electrician. Do not use this product with an extension cord unless the plug can be fully inserted. Do not alter or replace the plug.
For Decoration Only. Not a Toy. Not intended for children.
Distributed by TRACTOR SUPPLY COMPANY 5401 Virginia Way, Brentwood TN 37027
For customer support call 1-888-376-9601 www.TractorSupply.com MADE IN CHINA
