Drop-In Ice Bin
Product Information
The drop-in ice bin is a countertop accessory designed to
provide convenient storage for ice. It is made from durable
materials to ensure long-lasting performance. The ice bin comes
with all the necessary parts for installation, including brackets,
weld studs, and nuts. It is available for purchase at
webstaurantstore.com.
Product Usage Instructions
- Remove all contents from the carton and inspect the ice bin for
any damage. Do not install if the unit is damaged. - Place the ice bin cutout template (available on
webstaurantstore.com) at the desired location on the countertop.
Cut along the indicated cut line, ensuring that the front edge of
the ice bin is parallel to the countertop edge. - Using a pencil, carefully trace along the cutout template cut
line onto the countertop. Remove the template from the
countertop. - Drill a pilot hole inside the cut line.
- Place the saw inside the pilot hole and carefully saw along the
cut line. - Remove the countertop cutout section and align the ice bin in
the open space to mark where the four weld studs need to be drilled
into the counter. - After marking, drill through the counter for each corner of the
ice bin. - Apply sealant around the perimeter of the ice bin cutout.
Carefully place the ice bin in the cutout hole. - Slide the brackets over each weld stud and screw on the
nuts. - Use a wrench to tighten each nut to secure the ice bin to the
countertop. - Clean away any excess caulk or debris with a cloth.
- Install drain(s) as necessary.
For further assistance or troubleshooting, please refer to the
complete user manual or contact customer support at
REGENCYTABLESANDSINKS.COM.
DROP-IN ICE BIN ASSEMBLY INSTRUCTIONS
· Metal edges may be sharp. Handle with caution.
· It is recommended that this product be installed by a qualified installer.
· Be sure to follow all local plumbing and building codes.
· Inspect ice bin for damage before installation.
· Safety goggles and gloves should be worn during installation to prevent personal injury.
Included Parts:
· Ice Bin · Weld studs and brackets · Cutout Template
(available at webstaurantstore.com)
TOOLS REQUIRED:
(not included)
· Pencil · Saber saw, keyhole saw,
or router · Power drill · Silicone caulk · Safety glasses and
cut-resistant gloves · Wrench
1
Remove all contents from carton. Inspect the ice bin for any damage prior to installing. Damaged units should not be installed.
2
Place ice bin cutout template (available on webstaurantstore.com) at desired location on countertop. This should be cut out along the indicated cut line. Ensure front edge of the ice bin is parallel to the countertop edge.
3
Using a pencil, carefully trace along the cutout template cut line onto the countertop. Remove the template from the countertop.
4
Drill a pilot hole inside the cut line.
5
Place the saw inside of the pilot hole and carefully saw along the cut line.
REGENCYTABLESANDSINKS.COM
DROP-IN ICE BIN ASSEMBLY INSTRUCTIONS
6
Remove the countertop cutout section.
Align the ice bin in the open space to mark where the four weld studs need to be drilled into the counter.
7
After marking, drill through the counter for each corner of the ice bin.
8
Apply sealant around the perimeter of the ice bin cutout. Carefully place the ice bin in the cutout hole.
9
Slide the brackets over each weld stud and screw on the nuts.
Use a wrench to tighten each nut to secure the ice bin to the countertop.
10
Clean away any excess caulk or debris with a cloth.
Install drain(s).
REGENCYTABLESANDSINKS.COM
