Sportnow A61-036v01 Basketball Hoop With Backboard Instruction Manual

A61-036V01 Basketball Hoop with Backboard

Product Information:

The product is a basketball hoop system designed for outdoor
use. It consists of a base, poles, brackets, backboard, rim, and
net. The system can be filled with either sand or water to provide
stability.

Product Usage Instructions:

1. Safety Precautions:

• Do not assemble the product without following the
  instructions.
• Check all packaging to ensure no missing or damaged parts.
• Do not move the product without at least three adults
  present.
• Regularly check the base for leakages, as slow leaks can cause
  the product to tip over.
• Stand in front of the product and pull the pole forward to
  balance it on its wheels.

2. Assembly Steps:

1. Insert pole X,Y into Steel Cap O as shown in the picture on the
   right.
2. Insert pole X into Y as shown in the picture on the left.
3. Connect pole X and Y using bolt F, as shown in the left
   picture.
4. Connect braces U1, U2, U3, and U4 to the base using bolt D.
   Connect braces U3 and U4 to steel cap O, and U1 and U2 to bottom
   pole Y using bolt F.
5. Connect rim J, backboard M, and bracket K using bolts B1 and
   B4. Note that the longer B4 is at the top and shorter B1 is at the
   bottom.
6. Connect bracket K to backboard M using bolts C1 and C2.
7. Connect backboard M and bracket K using bolt F.
8. Insert top pole W into middle pole X using bolt F.
9. Assemble the net as shown in the picture on the right.

3. Base Filling:

If the product does not need to be moved frequently, it is
recommended to fill the base with sand instead of water. Water can
freeze and damage the base. Please note that once sand is placed in
the base, it cannot be poured out.

IN220800684V02_UK
A61-036V00_A61-036V01
WARNING: IMPROPER INSTALLATION OR SWINGING ON THE RING MAY CAUSE SERIOUS INJURY OR
DEATH
– Notice to assemblers: · All basketball stands, including those for display, must be assembled according to instructions. Failure to follow instructions could result in serious injury. · Please read all warnings and cautions before assembly. It is recommended to supervise children as they play with this product. Assemble this product with at least two adults.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

SAFETY INSTRUCTIONS
For safety, do not assemble without following instructions. Check all packaging before assembling, ensuring parts are not missing or damaged.
* This product should be moved by at least three adults. Not to be moved by children. * Check the base (if applicable) regularly for leakages. Slow leaks can cause the product to tip over. * Stand in front of the product and pull the pole forward, so it is balanced on its wheels. * Move the product to the desired location and carefully set the base down.
WARNING
1.Do not hang on the rim or any parts of the product, including backboard , support braces or net. 2.Never play on damaged equipment. If there any damages to parts, please contact customer service. 3.Do not leave the product in an upright posilion without filling base with water or sand, as it may tip over and cause injury or damage. 4.Do not let water freeze in the base during extremely cold weather. Pour out the water and fill with sand. 5.Always keep top pole and lifter pole covered with a cap. 6.When playing, do not wear jewellery, as it could get damaged. 7.When adjusting height or moving the stand, keep hands a way from moving parts. 8. Do not let children move or adjust the stand.

PART LIST
2x 2x
6x 2x
8x

Insert pole X,Y to Steel Cap O, as shown in the picture on the right.
Insert pole X to Y, as shown in the picture on the left.
O

4x

6x

F1 F2

F2 F3

1) Connect pole X and Y, using bolt F, as shown in the left picture.

Y

F2

F2

Connect braces U1, U2, U3 and U4 to the

base, using bolt D. Connect braces U3 and

U4 to steel cap O, and U1 and U2 to bottom

pole Y, using bolt F.

Connect rim J, backboard M and bracket K, using bolts B1 and B4. Please note, the longer B4 is at the top and shorter B1 is at the bottom.

2x

2x

Connect bracket K to backboard M, using bolts C1

2x

and C2.

4x
Connect backboard M and bracket K, using bolt F.
Insert top pole W into middle pole X, using bolt F.

Assemble the net, as shown in the picture on the right.

Sand

Water cap Water

If the product does not need to be moved frequently, it is recommended to use sand in the base instead of water. Water could freeze, which damages the base. Please note, sand cannot be poured out after it is placed in the base.
