3924-613 4-Light Polished Nickel Shaded Pendant Light
Product Information
The product is a convertible lamp for pendant rods or chains,
with item number 3924-613. The product comes with mounting
hardware, a mounting plate, ground screw, and mounting screws. It
also includes fixture wires (black or smooth, white or ribbed, and
bare copper for ground), house wires (black for hot, white for
neutral, and green for ground), and a chain (HCHYC4072-613) or
pendant rod (W30-1-613*1(F1), W30-1-613*2(F2), W30-H-613*1(F3)).
The product also comes with a candle cover (CCV21100P-613).
Product Usage Instructions
- Before installation, make sure to shut off power at the fuse
box or circuit breaker box. - For pendant rods installation (Fig. 1), attach the mounting
plate and ground screw to the junction box using the provided
mounting screws. - Then, attach the pendant rod to the mounting plate using the
provided hardware (F1, F2, F3). - Finally, attach the candle cover and set up the fixture wires
according to Fig. 2. - For chain pendant installation (Fig. 4), remove the old fixture
including the mounting hardware, and unpack the new fixture. - Attach the mounting plate and ground screw to the junction box
using the provided mounting screws. - Attach the chain to the mounting plate using the provided
hardware. - Finally, attach the candle cover and set up the fixture wires
according to Fig. 2. - After installation is complete, turn the power back on at the
fuse box or circuit breaker box and test the fixture. - Notice: It is important to use proper chain pliers (not
included) to open and close the chain included with this fixture.
Do not open them with other tools that may twist or stress the
chain links.
INSTALLATION INSTRUCTIONS
Item#3924-613 (Convertible Lamps For Rods Pendant) (Rev. 05/31/2021) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPARATION (Fig. 1) 1. Shut off power at the fuse box or circuit breaker box
and remove the old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the parts in a clean area. Take care not to misplace any small parts necessary for installation. ASSEMBLING THE FIXTURE WITH CHAIN LOOP (Fig.1&Fig. 3) 3. Secure rod (J) onto all thread (I) on fixture body. 4. Determine the desired hanging height and thread rods (F1, F2 and F3) to the all thread on rod (J). Then screw loop (H1) to rod (F1). Carefully pass the wires through each rod as you assemble. 5. Attach quick link (G) to loop (H1) and loop (H2) on canopy (D). Carefully feed wire through loop (H1), quick link (G) and loop (H2). 6. Attach mounting plate (A) to junction box (not included) with mounting screws (B) (Size: #8-32N*L0.5″). The side of the mounting plate (A) marked “GND” and two convex points must face out. CONNECTING THE WIRES (Fig. 2) 7. Connect the electrical wires as shown in fig 2, making sure that all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect the fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the mounting plate (A) using the green screw provided. 8. Tuck wire connectors neatly into the junction box and raise canopy (D) to ceiling. COMPLETING THE INSTALLATION (Fig. 1) 9. Place canopy (D) over mounting plate (A) and secure with screws (E). 10. Place candle covers (L) over sockets (M). 11. Install (4) four candelabra base bulbs (K) up to 60 watts each or CFL or LED equivalent (not included) in accordance with the fixture specification–DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)
Your installation is now complete. Return power to the junction box and test the fixture.
Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.
Fig. 1 Set#A-021-118DH -mounting plate -Ground Screw -Mounting Screw*2
H2 H1
F1 F2 F3
J I
A B D E G
Rod# W30-1-613*1(F1) W30-1-613*2(F2) W30-H-613*1(F3)
K
L
M
Candle cover# CCV21100P-613
Fig. 2 FIXTURE WIRES Black or Smooth
FIXTURE WIRES White or Ribbed
FIXTURE WIRES Bare Copper (Ground)
HOUSE WIRES Black (Hot)
HOUSE WIRES White (Neutral)
HOUSE WIRES Green (Ground)
Page: 1/3
LA-3427E
Fig.3
A B D
E H2
G H1
F1
a. Hardware Bag:
A. Mounting plate*1 B. Mounting Screw*2
D. Canopy *1 E. Screw*2 G. Quick Link*1
A
B
D
E
G
H
H. Loop*2
b. Hardware Bag: F1. ROD 12″*1 F2. ROD 12″*2 F3. ROD 6″*1
F2
F3
F1
Page: 2/3 Page: 2/3
LA-3427E
INSTALLATION INSTRUCTIONS
Item#3924-613 (Convertible Lamps For Chain Pendant) (Rev. 05/31/2021) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPARATION (Fig. 4) 1. Shut of power at the fuse box or circuit breaker box and
remove the old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the parts
in a clean area. Take care not to misplace any small parts necessary for installation. ASSEMBLING AND HANGING THE FIXTURE (Fig.4) 3. Secure rod (J) onto all thread (I) on fixture body. Carefully pass wires through rod (J) as you assemble. 4. Secure loop (H1) to all thread on rod (J). 5. Connect chain (N) to loop (H1) by using quick link (G). 6. By measuring, determine the correct number of links needed for the desired hanging height. Using the chain pliers, disconnect and discard the excess chain (N). 7. Carefully lace fixture wires through chain (N). 8. Open the other end of the chain (N) and attach it to loop (H2). Then close the chain (N). 9. Carefully feed fixture wires through loop (H2) and canopy (D) and pull tight. 10. Attach mounting plate (A) to junction box (not included) with mounting screws (B) (Size: #8-32N*L0.5″). The side of the mounting plate (A) marked “GND” and two convex points must face out. CONNECTING THE WIRES (Fig. 2) 11. Connect the electrical wires as shown in fig 2, making sure that all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect the fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the mounting plate (A) using the green screw provided. 12. Tuck wire connectors neatly into junction box and raise canopy (D) to ceiling. COMPLETING THE INSTALLATION (Fig. 4) 13. Align canopy (D) over mounting plate (A) and secure with screws (E). 14. Place candle covers (L) over sockets (M). 15. Install (4) four candelabra base bulbs (K) up to 60 watts each or CFL or LED equivalent (not included) in accordance with the fixture specification–DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)
Your installation is now complete. Return power to the junction box and test the fixture.
Fig. 4 Set#A-021-118DH -mounting plate -Ground screw -Mounting screw*2
H2 N
G H1
J I
Chain# HCHYC4072-613 Candle cover# CCV21100P-613
Fig. 2 FIXTURE WIRES Black or Smooth
FIXTURE WIRES White or Ribbed
A B D E
K L M
FIXTURE WIRES Bare Copper (Ground)
Note: Illustration (Fig.4) on this manual is for
HOUSE
installation purposes only. It may or may not be
WIRES Black (Hot)
identical to the fixture purchased.
HOUSE WIRES White (Neutral)
Notice: It is important to use proper chain pliers (not included) To OPEN and CLOSE the chain included with this fixture. Do not open them with other tools that may twist or stress the
chain links. It is important to use proper chain pliers like the ones shown in the diagram.
Page: 3/3
LA-3427E
HOUSE WIRES Green (Ground)
