Biamp Apprimo8m 8 Inch Lcd Screen User Manual (+ PDF)

The equipment is for indoor use only.
To reduce the risk of fires or electric shock, do not expose
the equipment to rain or moisture.
Do not block the ventilation holes on the back of equipment at
any time.
Do not subject the equipment to severe shocking.
Prevent any foreign matter falling into the external slot.
Do not open the case of the equipment. There is a risk of
electric shock, and there are no user serviceable parts inside.
Opening the case will void your warranty.

Features

8 LCD Screen,1280×800
Quad-core Cortex-A55 up to 1.8GHz
Android 11
8*1W Speaker

Package Contents

Please make sure all of the following are present when you
unpack your AD players.

8 all in one AD player
Power adapter
Android Retail Tablets 1 1 .6 LC D IP S pa ne l
User Manual

Android OS Home Screen

Insert the power lead into the DC socket, and then insert the
other end into the power socket.
The Equipment will automatically power on.
Screen will show starting logo.
Waiting for about 25 seconds and enter into main
interface.

Common Problems And Countermeasures

Can’t open the machine. Solutions: connect the charger after 10
minutes to boot.
In the touch screen have no reaction when charging or
automatically jump to the other interface. Solution: The connection
is not the factory configuration chargers may cause bad touch,
please use the factory configuration when charging.
After open the WiFi, not be able to connect to the router.
Solution: May the WiFi password input error, please enter the
password correctly.
Computer USB connection reaction. Solution: Check whether the
connecting line between the machine with a computer is connected,
then click the machine upper /left screen.
In the abnormal operation after crash, lag. Solution: Press the
restart button, then restart will be back to normal.
WIFI and Bluetooth function description. Open Settings, turn on
WIFI or Bluetooth function, wait to scan nearby devices, click
Connect pairing.

FCC Warning

This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:

This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.

Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.

Product Usage Instructions

The All in one AD player is designed for indoor use only. To
reduce the risk of fires or electric shock, do not expose the
equipment to rain or moisture. Please do not block the ventilation
holes on the back of the equipment at any time. Do not subject the
equipment to severe shocking, and prevent any foreign matter from
falling into the external slot. The case of the equipment should
not be opened as there is a risk of electric shock, and there are
no user serviceable parts inside. Opening the case will void your
warranty.

To use the device, insert the power lead into the DC socket, and
then insert the other end into the power socket. The equipment will
automatically power on, and the screen will show starting logo.
Wait for about 25 seconds, and then enter into the main
interface.

In case of any common problems such as not being able to open
the machine, no reaction on the touch screen when charging or
automatically jumping to another interface, unable to connect to
Wi-Fi after opening it, or in the abnormal operation after crash,
press the restart button to restart, and it will be back to normal.
For computer USB connection reaction, check whether the connecting
line between the machine with a computer is connected, then click
on the machine upper/left screen. For WIFI and Bluetooth function
description, open Settings, turn on WIFI or Bluetooth function,
wait to scan nearby devices, click Connect pairing.

Please note that this equipment comes with an 8 LCD Screen with
a resolution of 1280×800, Quad-core Cortex-A55 up to 1.8GHz,
Android 11, and 8*1W Speaker. Please ensure that all the package
contents are present when you unpack your AD players, which include
8 all in one AD player, power adapter, Android Retail Tablets 1 1
.6 LC D IP S pa ne l, and user manual.

Lastly, please be aware of the FCC warning, which states that
this device complies with part 15 of the FCC Rules. Operation is
subject to two conditions: the device may not cause harmful
interference, and it must accept any interference received,
including interference that may cause undesired operation. Any
changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment. If you encounter any issues, please reorient
or relocate the receiving antenna, increase the separation between
the equipment and receiver, connect the equipment into an outlet on
a circuit different from that to which the receiver is connected,
or consult the dealer or an experienced radio/TV technician for
help.

View Fullscreen

All in one AD player
8″ LCD Screen
User Manual
1

Contents
Notes of Importance…………………………………………………………………………………………….. 2 Features. …………………………………………………………………………………………………………….. 3 Package Contents. ……………………………………………………………………………………………….. 4 Android OS Home Screen. …………………………………………………………………………………….. 5 Factory Reset. ………………………………………………………………………………………………………. 6 Specifications…………………………………………………………………………………………………… 7
1

Notes of Importance
1) The equipment is for indoor use only. 2) To reduce the risk of fires or electric shock, do not expose the equipment to rain or
moisture. 3)Do not block the ventilation holes on the back of equipment at any time. 4)Do not subject the equipment to severe shocking 5)Prevent any foreign matter falling int the external slot. 6) Do not open the case of the equipment. There is a risk of electric shock,and there
are no user serviceable parts inside. Opening the case will void your warranty.
2

Features
8″ LCD Screen,1280×800 Quad-core Cortex-A55 up to 1.8GHz Android 11 8*1W Speaker
3

Package Contents
Please make sure all of the following are present when you unpack your AD players.

8″ all in one AD player

Power adapter

Android Retail Tablets 1 1 .6″ LC D IP S pa ne l
User Manual
User manual

All in one AD player

Android OS Home Screen
1) Insert the power lead into the DC socket, and then insert the other end into the power socket.
2) The Equipment will automatically power on 3) Screen will show starting logo. 4) Waiting for about 25 seconds and enter into main interface.

Android OS Home Screen

No. Item 1 CPU 2 O/S 3 DRAM 4 Memory 5 LCD 6 LCD Resolution 7 Touch screen 8 Ethernet 9 Camera 10 Video format
11 Audio format 12 DC input 13 Poe 14 VESA 16 Power consumption 17 The dimensions 18 WiFi 19

SPEC Quad-core Cortex-A55 up to 1.8GHz Android 11 2GB EMMC,16GB 8″ 8″,1280×800 touch panel 100M Ethernet NO MPEG1;MPEG2;MPEG4;4K UHD,H.265,H.264,RV,VC1,VP8 MP2,MP3,AAC etc. NO 48V1A 100x100mm 13W(max) 8″, 198.1×133.33×15.5mm 802.11b/g/n

Common Problems And Countermeasures
1. Can’t open the machine Solutions: connect the charger after 10 minutes to boot.
2. In the touch screen have no reaction when charging or automatically jump to the other interface. Solution: The connection is not the factory configuration chargers may cause bad touch, please use the factory configuration when charging.
3. After open the WiFi, not be able to connect to the router Solution: May the WiFi password input error, please enter the password correctly.
4. Computer USB connection reaction Solution: Check whether the connecting line between the machine with a computer is connected, then click the machine upper /left screen
5. In the abnormal operation after crash, lag Solution: Press the restart button,then restart will be back to normal.
6. WIFI and Bluetooth function description Open Settings, turn on WIFI or Bluetooth function, wait to scan nearby devices, click Connect pairing
8

FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
9

IC Warning This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Cet appareil est conforme aux CNR exemptes de licence d’Industrie Canada . Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) Ce dispositif ne peut causer d’interférences ; et ( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent causer un mauvais fonctionnement de l’appareil. Ce matériel est complété par une exposition de rayonnements ISED pour un environnement naturel. Ce matériel doit être installé et se faire avec une distance minimale de 20cm entre les radiateurs et les autresYour body shop. Note: The device for operation in the band 51505250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.
10
