2003-6641 Installation Terminal Blocks
Product Information
The 2003 and 2203 series installation terminal blocks are
designed to be used as circuit terminal blocks for three-phase
power circuits in small circuit groups. These terminal blocks are
available with disconnect, single and double fuse solutions, or
with no functionality. They come with dual jumper slots on both
levels and have direct ground contact to DIN-rail. The product
portfolio includes:
- NTi/L/PE: The multilevel installation terminal block with
internal N-disconnection - N/L/PE: The multilevel installation terminal block without
N-disconnection - P1/P2/PE: The multilevel installation terminal block without
knife disconnect, with a separate top busbar carrier terminal block
for fuse holders - L/L: The add-on terminal block for wiring three-phase circuits
– both additional phases are combined in one multilevel
installation terminal block - L: The multilevel installation terminal block for easily
commoning a single potential
The technical data for these terminal blocks are:
| Potential | Operating Slot | Hybrid | Push-Button | End Plate 0.8mm | End Plate 1mm (2003-911 double fuse plug) | End Plate 1mm (2004-911 fuse plug) |
|---|---|---|---|---|---|---|
| NTi/L/PE | 2003-6641 | 2203-6541 | 2203-6641 | 2003-6692 | 2003-6693 | 2003-6694 |
| L/L | 2003-6642 | 2203-6542 | 2203-6642 | 2003-6692 | 2003-6693 | 2003-6694 |
| N/L | 2003-6649 | 2203-6549 | 2203-6649 | – | – | – |
| N/L/PE | 2003-6646 | 2203-6546 | 2203-6646 | – | – | – |
| L/L/PE | 2003-6645 | 2203-6545 | 2203-6645 | – | – | – |
| N/L/PE | 2003-6640 | 2203-6540 | 2203-6640 | – | – | – |
| L | 2003-6650 | 2203-6550 | 2203-6650 | – | – | – |
| N | 2003-6651 | 2203-6551 | 2203-6651 | – | – | – |
| LTi/L/PE | 2003-6644 | 2203-6544 | 2203-6644 | – | – | – |
| P2/P1/PE | 2003-6643 | 2203-6543 | 2203-6643 | – | – | – |
| P1/P2/PE | 2003-6660 | 2203-6560 | 2203-6660 | – | – | – |
| L/N/PE | 2003-6661 | 2203-6561 | 2203-6661 | – | – | – |
The terminal blocks can accommodate solid/stranded wires with a
range of 22-12 AWG and stranded wires with ferrules with a range of
22-14 AWG. They have a voltage rating of 300V and a current rating
of 20A.
Product Usage Instructions
To use the installation terminal blocks, follow these
instructions:
- Select the appropriate terminal block based on the circuit
requirements. - Insert the wires into the push-in termination slots on the
terminal block. - If using stranded wires without ferrules, ensure that the wire
strands are properly aligned before inserting them into the
slot. - If using stranded wires with ferrules, insert the ferrule into
the slot. - If using solid wires, strip the insulation to the appropriate
length and insert the exposed wire into the slot. - If using an end plate, attach it to the end of the terminal
block to cover the exposed slots. - If using jumpers, insert them into the dual jumper slots to
connect different potentials along side each other. - To mark the terminal block for easy identification, use either
the continuous marking strip or the WMB inline markers. - If using accessories such as test plug adapters or fuse plugs,
ensure that they are compatible with the terminal block and follow
the manufacturer’s instructions for installation.
TOPJOB® S Multilevel Installation Terminal Blocks
Open Tool Slot · Push-Button · Hybrid
2003 AND 2203 SERIES
INSTALLATION TERMINAL BLOCKS
WITH PUSH-IN CAGE CLAMP® AND PUSH-BUTTON
Dual jumper slots on both levels
Available with disconnect, single & double fuse solutions, or with no functionality
Marking with 2009-110 continuous marking strip
Marking on sides of blocks with WMB-Inline markers
Direct ground contact to DIN-rail
WAGO brings convenient push-button actuation to its TOPJOB® S Multilevel Installation Terminal Blocks. Besides choosing from an operating slot or push-button, these terminal blocks also offer a hybrid model that incorporates both options. These new offerings make the TOPJOB® S range incredibly versatile and can be use to save space within industrial applications, including process systems.
Product Portfolio:
Highlights:
· Maintenance-free CAGE CLAMP® connection technology
· IP20 finger safe/touch safe · 2009-110 continuous strip
· 2002-400 continuous jumper
· Open-tool slot, push-button and hybrid variants available in the same profile
· Functionality for top levels – disconnect, fusing options, custom diode or LED plugs, etc.
NTi/L/PE: The multilevel installation terminal block with internal N-disconnection – used as a circuit terminal block for three-phase power circuits in small circuit groups
N/L/PE: The multilevel installation terminal block without N-disconnection – for simple commoning of three circuit potentials
P1/P2/PE: The multilevel installation terminal block without knife disconnect, with a separate top busbar carrier terminal block for fuse holders
L/L: The add-on terminal block for wiring threephase circuits – both
additional phases are combined in one multilevel installation
terminal block
L: The multilevel installation terminal block for easily commoning a single
potential
Solid/Stranded: 22 – 12 AWG Stranded w/ferrule: 22 – 14 AWG
300 V 20 A
Technical Data:
Potential NTi/L/PE L/L N/L N/L/PE L/L/PE N/L/PE L N LTi/L/PE P2/P1/PE P1/P2/PE L/N/PE End Plate 0.8mm End Plate 1mm (2003-911 double fuse plug) End Plate 1mm (2004-911 fuse plug)
Operating Slot 2003-6641 2003-6642 2003-6649 2003-6646 2003-6645 2003-6640 2003-6650 2003-6651 2003-6644 2003-6643 2003-6660 2003-6661 2003-6692 2003-6693 2003-6694
Hybrid 2203-6541 2203-6542 2203-6549 2203-6546 2203-6545 2203-6540 2203-6550 2203-6551 2203-6544 2203-6543 2203-6560 2203-6561 2203-6692 2203-6693 2203-6694
Push-Button 2203-6641 2203-6642 2203-6649 2203-6646 2203-6645 2203-6640 2203-6650 2203-6651 2203-6644 2203-6643 2203-6660 2203-6661 2203-6692 2203-6693 2203-6694
Accessories:
Item No. 206-1125 206-1204 210-136 210-658 210-720 258-5000 2002-400 2002-4xx 2003-499 2003-500
Description QuickStrip Tool Crimp Tool (24-12 AWG) 2mm Test Plug Mini-Angled Acutation Tool Actuation Tool smartPRINTER Marking System Continuous Jumper – 2-Way Comb style jumpers- 1-10 way N/L Test Plug Adapter N Test Plug Adapter
Item No. Description 2003-911 Double Fuse Plug w/LED indication 2003-911/ Double Fuse Plug w/out LED indication 1000-923 2004-911 Fuse Plug 2009-110 Continuous Marking Strip 2009-115 WMB-Inline Markers 2009-174 Test Plug Adapter – Jumper Slot 2009-182 Testing Tap – Jumper Slot 2009-414 Push-in type wire jumper; 110mm
Carrier Terminals Single and double fuse plugs with or without LED indication
Disconnect Terminals Easily isolate a circuit for testing and troubleshooting
Fast & Simple Testing Various testing taps and item-specific test plug adapters
smartPRINTER
Convenient identification with WMB markers or multi-line continuous marking strip
Dual jumper slot
Comprehensive range of jumpers with push-in type jumper bars, continuous and staggered jumpers
Simply accommodate different potentials along side each other
Push-In CAGE CLAMP®
Push-in termination technology
Push-in termination of solid conductors and fine-stranded conductors with ferrules
Marking System
Terminal block marking using continuous marking strips
Terminal block marking using WMB inline markers
Design
Free and easy configuration with smartDESIGNER software
