Sector II Rectangular Boom Pole LED

TRAFFIC BARRIERS

SECTOR II RECTANGULAR BOOM POLE LED INSTALLATION MANUAL

Centurion Systems (Pty) Ltd www.centsys.com

Company Profile

• 1986 – In-house R&D development team
• 1990
• 1995
• 1999 – Manufactures to international quality standard ISO
  9001:2015
• ISO 9001:2015
• After-sales multi-language Technical Support
• 100% testing of products
• Sales and technical support to Africa, Europe, Asia, the
  Americas, Australia and the Pacific
• Call Centre Operating Times Monday to Friday 08h00 to 17h00
  GMT+2, Saturdays 08h00 to 14h00 GMT+2

Contents

• 1. INTRODUCTION
• 2. PRODUCT IDENTIFICATION
• 3. PHYSICAL INSTALLATION
  • 3.1. Mounting the PSU and Relay
  • 3.2. Boom pole modifications
• 4. COMPLETING THE INSTALLATION
  • 4.1. Wiring the Control Card
    • 4.1.1. Option 1
    • 4.1.2. Option 2
  • 4.2. New Controller setup
    • 4.2.1. Settings for Option 1
    • 4.2.2. Settings for Option 2
  • 4.3. Old Controller setup
    • 4.3.1. Settings for Option 1
• 5. INSTALLATION HANDOVER

Icons used in this manual

• – indicates tips
  and other information that could be useful during the
  installation.
• –
  denotes variations and other aspects that should be considered
  during installation.
• – indicates
  warning, caution or attention! Please take special note of critical
  aspects that MUST be adhered to in order to prevent injury.

SECTION 1

1. Introduction

ATTENTION!

To ensure the safety of people and possessions, it is important
that you read all of the following instructions.

Incorrect installation or incorrect use of the product could
cause serious harm to people.

The installer, being either professional or DIY, is the last
person on the site who can ensure that the operator is safely
installed and that the whole system can be operated safely.

Warnings for the Installer

• CAREFULLY READ AND FOLLOW ALL INSTRUCTIONS before installing
  the product.

SECTION 2

2. Product Identification

PRODUCT IDENTIFICATION

1. LED strip
2. Boom pole harness
3. Cable gland
4. Mounting bracket
5. LED power supply
6. Multi-function relay
7. LED PSU harness
8. Relay wiring harness

SECTION 3

3. Physical Installation

3.1. Mounting the PSU and Relay

PHYSICAL INSTALLATION

The following steps should only be performed once the
rectangular boom pole has been successfully fitted onto the SECTOR
II.

Always ensure that the boom pole is in the raised position
before disconnecting AC and DC power to the Traffic barrier to
prevent damage to the controller.

Disconnect both AC and DC power to the SECTOR II before doing
any work.

1. Open the SECTOR II cabinet.
2. From the top of the inner flap, mark and centre punch hole
   positions at 76mm and 107mm.

3.2. Boom pole modifications

…

SECTION 4

4. Completing the Installation

4.1. Wiring the Control Card

• 4.1.1. Option 1
• 4.1.2. Option 2

4.2. New Controller setup

• 4.2.1. Settings for Option 1
• 4.2.2. Settings for Option 2

4.3. Old Controller setup

• 4.3.1. Settings for Option 1

5. Installation Handover

…

WARNING! WARNING! WARNING! WARNING!
WARNING!

SAFETY FIRST

MOVING BARRIER CAN CAUSE SERIOUS INJURY OR
DEATH!

KEEP AWAY! THE BARRIER MAY MOVE AT ANY TIME! DO NOT
ALLOW CHILDREN TO PLAY IN THE AREA OR OPERATE THE
BARRIER.

Please ensure that you follow all instructions carefully and
take all necessary safety precautions when installing and using the
product.
