SPENCE Automatic Watch
Product Information:
The timepiece is a Mechanical Automatic watch that does not
require a battery. The watch is powered by the movements of the
wearer’s wrist during wear. It can also be manually wound. The
watch is equipped with an hour hand, minute hand, second hand,
screw-down crown, and a uni-directional turning bezel. The
screw-down crown is used to ensure water resistance. The watch must
be worn for at least 8 hours a day to ensure it is fully wound.
Product Usage Instructions:
Using the Screw-Down Crown:
1. Do not pull the crown unless it is unscrewed first. To
unscrew the crown, turn it anti-clockwise until it turns freely
without tension.
2. Gently pull the crown out to the other desired positions for
watch setting (see specific operating instructions on the following
pages).
3. To screw the crown, push it all the way in towards the watch
and then begin to turn it clockwise until it is securely screwed
down.
NOTE: Failure to securely screw down the crown after setting the
watch may affect its water resistance.
Winding the Mainspring:
1. Unscrew the crown by turning it anti-clockwise.
2. When it is in position [1], turn the crown clockwise to wind.
Wind 5-10 times and it will start to move naturally after shaking
slightly.
3. Push the crown in then screw it securely.
Setting the Time:
1. Unscrew the crown and pull it out to position [2] (1st
click).
2. Turn the crown clockwise to set the correct time.
3. Push the crown in then screw it securely.
Changing the Bracelet to NATO Strap:
1. Flip the cover.
2. Press the buttons on the clasp sides to release the
bracelet.
3. Remove the bracelet from the watch.
4. Insert the spring bars into the lugs of the watch.
5. Thread the NATO strap through the spring bars and fold it
over itself.
6. Thread the buckle through the strap and adjust it to fit your
wrist size.
7. Reattach the cover.
Using a Deployant Clasp:
1. Flip the cover.
2. Press the buttons on the clasp sides to release it.
3. Place your wrist in the bracelet.
4. Close the clasp and press the buttons to secure it.
Resizing a Metal Bracelet:
1. Use a tool to push out the pins from the links you want to
remove.
2. Remove the desired number of links.
3. Reinsert the pins into the remaining links.
This timepiece is equipped with a self-winding Mechanical Automatic movement. It does not need a battery.
It is powered by the motions of the user’s own wrist during the wear of the watch. You may also choose to wind the watch manually.
For more details on operating this timepiece please refer to
the enclosed booklet or visit:
spinnaker-watches.com
INSTRUCTION MANUAL
VOL.1.124 EN
For more infomation Pour plus d’informations Para más información Per maggiori informazioni Für mehr Informationen
HOUR HAND
MINUTE HAND
SCREWDOWN CROWN
SECOND HAND
UNI-DIRECTIONAL TURNING BEZEL
PLEASE READ THE FOLLOWING BEFORE UNSCREWING THE CROWN
Screw-down Crown
Screw-down crowns are used to ensure water resistance. ALWAYS be certain that your crown is securely screwed down (Position [0] is secured. Positions [1] and [2] are not secured for water resistance ). Do NOT unscrew your crown while you are in any environment where moisture is present.
(1st click)
012
CLOSED:
OPENED:
SECURELY SCREWED NOT SECURED
AND
FOR
WATER RESISTANT WATER RESISTANCE
1
USING THE SCREW-DOWN CROWN
Do NOT pull the crown unless it is UNSCREWED first:
TO UNSCREW: Turn the
crown anti-clockwise until it
turns freely without tension.
GENTLY pull the crown out
0
to the other desired positions for watch setting
(see specific operating
instructions on the following
pages).
TO SCREW: Push the crown
ALL THE WAY IN (towards
the watch) THEN begin to
turn clockwise until it is
1
securely screwed down.
NOTE: Failure to SECURELY screw down the
crown after setting the watch may affect its
water resistance.
2
Before you use this watch, It is recommended that you manually wind the mainspring to start it moving.
This Watch Is An Automatic Watch Equipped With A Manual Winding Mechanism.
WINDING THE MAINSPRING
1. Unscrew the crown by turning it anti-clockwise.
0
2. When it is in position [1],
turn the crown clockwise
to wind. Wind 5-10 times
and it will start to move
1
naturally after shaking
slightly.
3. Push the crown in then screw it securely.
3
* This watch MUST be worn for at least 8 (Eight) hours each day to ensure it is fully wound. An automatic watch will only wind when the watch is on your wrist and your arm moves. Winding the watch by the crown will put power on the spring but not enough to allow the watch to function fully. If your watch stops overnight or loses time it means it is not being fully wound.
IMPORTANT NOTE
1. If your watch is running smoothly, please do not wind the crown to avoid overwinding the movement. Provided you are wearing the watch frequently, your watch should have sufficient power to operate without any fuss.
2. If your watch has stopped running after a
period of not wearing the watch, gently
move the watch side to side 20 to 30 times
to move the rotor or gently turn the crown
5 to 10 times to get the second hand run at
its normal speed.
4
HOW TO SET THE TIME
1. Unscrew the crown and pull it out to position [2]-(1st click).
2. Turn the crown clockwise to set the correct time.
3. Push the crown in then screw it securely.
0 12
0
2
5
HOW TO CHANGE THE BRACELET TO NATO STRAP
3.
5.
1.
2.
4.
6
7
6.
8.
HOW TO USE
A DEPLOYANT CLASP
7.
9.
2 1
1. Flip the cover. 2. Press the buttons on the clasp sides.
8
9
HOW TO RESIZE
3.
METAL BRACELET
On the inside of the bracelet, you will see some small arrows engraved on removeable links.
1.
4. 2.
10
Nylon Head Hammer
11
5.
7.
6.
8.
Nylon Head
Hammer
Finish
12
13
9. Micro size adjustment
10.
11.
Finish
14
15
WATER RESISTANCE
Note that the water resistance chart serves only as a guide (please refer to the water resistance chart on the next page). Actual water resistance may vary depending on a number of factors including water temperature, water salinity and use under water.
The water resistance of your timepiece may eventually be compromised over time with general wear and tear and use of your timepiece under adverse conditions.
Always remember to employ the screw down crown if available to maintain the water resistance of your timepiece. Warranty may be voided if the screw down crown has not been properly employed.
Note that you should NEVER wear your watch in a jacuzzi, hot shower or steam room where steam may enter the case despite the watertight seals used to protect your watch.
This may cause condensation inside your watch, which may affect and damage the inner workings of your watch.
WATER RESISTANCE 50M/
CHART
5ATM
SPLASH/ SHOWERING
SWIMMING/ BATHING
BRIEF SWIMMING/ WATER SPORTS
PROLONGED SWIMMING/ FREE DIVING
SCUBA DIVING
PROFESSIONAL DEEP SEA DIVING
100M/ 200M/ 300M/ 500M/ 10ATM 20ATM 30ATM 50ATM
