3053 Heavy Duty Gardening Trolley

Product Information

Model Code: 3053

Product Name: Heavy Duty Gardening Trolley

Manufacturer: Oypla.com LLP

Manual Version: v1.0

Website: www.oypla.com

Safety Instructions

Ensure you read and fully understand instructions before
use.
This product is not a toy, and is only to be used for its
designated purpose.
Before using the product, make sure all the fastenings are
tightly in place and that everything is in order, and checked
periodically by an adult.
Do not carry out alterations or modifications to this
product.
The maximum weight capacity is 400kg. Do not exceed this.
Clean only with a damp cloth. Do not use strong industrial
cleaning substances.
Ensure the load is evenly spread.
Don’t turn too quickly as this may cause the load to become
unsafe and fall out.
Don’t pull the trolley off of curbs or other elevated places as
this may damage the load and/or the trolley. Use a ramp where
possible.
Leaving the product outside exposed to weather, especially
direct sun, rain, and salt air, will speed the weathering process.
This can be slowed by removing the product from these conditions or
covering it with a suitable cover.
If the product is damaged or has any defects, please contact
[email protected].

Assembly Instructions

Parts List:

If you are missing any of the below parts, please contact
[email protected].
Please be aware that you will be referring to this parts list
throughout the assembly process.

Part 2:

Place the handle beam (part 1) on top of the handle beam axle
(part 2), ensuring that the handle beam (part 1) is as far down as
possible. This should leave a section of the handle beam axle (part
2) exposed. Slide the handle beam washer (part 3) onto the exposed
section of the handle beam axle (part 2). Secure these in place
with a securing pin (part 4). Please see the images to help.

Part 5:

Slide the handle beam (part 1) onto the trolley platform (part
5) so that it aligns with either group of holes in the bottom of
the trolley platform (part 5). Once done, hold the handle beam
(part 1) in place using a trolley support bolt (part 6) and secure
this in place with a support washer (part 7) and a support nut
(part 8). Repeat for the other holes. Please see the images to
help.

View Fullscreen

Page 1
User Manual
Model Code: 3053

Contents

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

Heavy Duty
Gardening Trolley
Manual Version: v1.0 Model Code: 3053
Oypla.com LLP / www.oypla.com

Contents

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

Page 2

Safety Instructions

Notice: Ensure you read and fully understand instructions before use

While every attempt is made to ensure the highest degree of protection in all equipment, we cannot guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold
on this condition, which no representative of the company can waive or change.

This product is not a toy, and is only to Before using the product, make sure all

be used for its designated purpose.

the fastenings are tightly in place and

This product is intended for outdoor use

that everything is in order, and checked

only.

periodically by an adult.

Do not carry out alterations or

The maximum weight capacity is 400kg.

modifications to this product.

Do not exceed this.

Clean only with a damp cloth. Do not use Ensure the load is evenly spread. strong industrial cleaning substances. Don’t turn too quickly as this may cause

Leaving the product outside exposed to

the load to become unsafe and fall out.

weather, especially direct sun, rain and Don’t pull the trolley off of curbs or other

salt air, will speed the weathering

elevated places as this may damage the

process. This can be slowed by removing

load and/or the trolley. Use a ramp

the product from these conditions, or

where possible.

covering it with a suitable cover.

If the product is damaged or has any

Do not fill the tires with too much air as

defects, please contact

this may cause for them to become

[email protected].

damaged due to the density.

Warnings

The maximum weight capacity is

400kg. Do not overload this as it can cause

product failure and/or personal injury.

Manual Version: v1.0 Model Code: 3053
Oypla.com LLP / www.oypla.com

Contents

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

Page 3
Assembly Instructions
Parts List:
– If you are missing any of the below parts, please contact [email protected] – Please be aware that you will be referring to this parts list throughout the assembly
process.

Manual Version: v1.0 Model Code: 3053
Oypla.com LLP / www.oypla.com

Page 4

Contents

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

Part 2
Place the handle beam (part 1) on top of the handle beam axle (part 2), ensuring that the handle beam (part 1) is as far down as possible. This should leave a section of the handle beam axle (part 2) exposed. Slide the handle beam washer (part 3) onto the exposed section of the handle beam axle (part 2). Secure these in place with a securing pin (part 4). Please see the images to help.
2

Part 3 Part 1

Part 4

Part 6

Part 1

Part 5

Slide the handle beam (part 1) onto the trolley platform (part 5) so that it aligns with either group of holes in the bottom of the trolley platform (part 5). Once done, hold the handle beam (part 1) in place using a trolley support bolt (part 6) and secure this in place with a support washer (part 7) and a support nut (part 8). Repeat for the other holes. Please see the images to help.

Part 7

Part 8

Manual Version: v1.0 Model Code: 3053
Oypla.com LLP / www.oypla.com

Contents

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

3
Part 7

Page 5

Part 8

Part 6

Part 9

Slide the rear axle (part 9) onto the other set of holes. As with the handle beam, secure these in place using the trolley support bolts (part 6), support nuts (part 7) and support washers (part 8). Repeat for the other holes. Please see the image above.

4
Part 10 Part 2/9

Part 11
Push a wheel (part 10) onto either the handle beam axle (part 2) or the rear axle (part 9), then slide a wheel washer (part 11) onto either axle and secure both the wheel (part 10) and the wheel washer (part 11) into place with a securing pin (part 4). Repeat this step on the opposite side and the remaining axle to complete the wheels. Please see the images.

Part 4

Manual Version: v1.0 Model Code: 3053
Oypla.com LLP / www.oypla.com

Contents

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

Page 6
5

Part 12

Part 13

Align the metal tube on the bottom of the platform side panel (part 12) with the metal tube on the trolley platform (part 5), securing this in place with a hitch pin (part 13). Repeat this on the other side of the platform side panel (part 12) to complete this side and repeat this process on the opposite side of the trolley platform (part 5) to complete both sides. Please see the image for guidance.

Part 13

Part 14

Align the metal tube on the bottom of the trolley platform front panel (part 14) with the metal tube on the trolley platform (part 5), securing this in place with a hitch pin (part 13). Repeat this on the other side of the platform front panel (part 14) to complete this side and repeat on the opposite side of the platform (part 5) to complete both sides. Please see the image for guidance.

Manual Version: v1.0 Model Code: 3053
Oypla.com LLP / www.oypla.com

Contents

7 Part 15

Front Cover

–

2 Safety

Instructions

–

2 Warning

Instructions

–

3 Assembly

Instructions

–

8 Back Cover

End

Part 16
Slide the handle (part 15) into the handle rotation pod (part 16), making sure the holes in both parts are aligned. After Part 7 this. Push the handle support bolt (part 17) through both parts, holding them into place. Secure these with a support nut (part 7) and a support washer Part 8 (part 8).

Page 7 Part 17

Once completed, ensure that all the support nuts (part 8) are tightened so the parts are secure and won’t fall off over time and that the securing pins (part 4) are all bent to ensure that the wheels won’t fall off when using the Heavy Duty Garden Trolley. Make sure to pump the wheels (part 10) up before use so that when transporting heavy loads in the Heavy Duty Garden Trolley the wheels don’t become worn at a faster rate. Do not over fill the wheels as this may cause them to become too dense and more likely to burst.
