UPPFRISKANDE Wall Mounted Extractor Hood
Product Information
The UPPFRISKANDE is a wall-mounted hood designed for use in
kitchens. It features a chimney, a lamp, a control panel, and a
grease filter. The hood has various suction power levels and a
duration setting of 5 minutes. The light button allows for
adjusting the intensity of the lamp. The product is equipped with
LED lighting.
Technical Data:
- Type of Appliance: Wall-mounted Hood
- Width: 798mm
- Dimensions:
- Depth: 510mm
- Total height in suction mode (min-max): 750-1030mm
- Total height in recirculation mode (min-max): 735-1090mm
- Total Power: 257W
- Light Info:
- Number & Power: 1x7w
- Type: LED Strip
- Minimum Installation Height – Gas Cooker: 650mm
- Minimum Installation Height – Electric Cooker: 500mm
- Product Weight: 15.6kg
Product Usage Instructions
To use the UPPFRISKANDE wall-mounted hood, follow these
steps:
- Mount the chimney on the wall according to the provided
installation instructions. - Connect the hood to the power supply.
- Press the Motor OFF button (A) to turn off the hood.
- Use the suction power selection buttons (B, C, D, E) to choose
the desired suction power level. The higher the number, the
stronger the suction. - Press the suction power 4 selection button (E) to activate the
duration setting. The hood will automatically turn off after 5
minutes. - Press the ON/OFF light button (F) to turn on the lamp. Hold the
button to adjust the intensity of the light. - Note that there will be a 5-second delay when switching
directly to suction power 1 from any other speed due to the
electronic control of the product.
For more detailed information and instructions, please download
the full version of the user manual from www.ikea.com.
en
UPPFRISKANDE
T10 T20
ABC D
E
F
G
H
1x 1x 2x 4x 2x 2x 9x 3x
I
2x
M
2x
Q
2x
R
1x
J
1x
K
1x
N
2x
O
2x
L
1x
P
1x
S
1x
T
1x
MANUAL www.ikea.com
MANUAL
ENGLISH
5
ENGLISH
5
Description of the appliance
1
1 Chimney
2 Lamp
3 Control panel
2
4 Grease filter
3 4
Control Panel
AB
CD
E
F
A Motor OFF button B Suction power 1 selection button C Suction power 2 selection button D Suction power 3 selection button
E
Suction power 4 selection button Duration 5 minutes
F ON/OFF light button
NB: with the light on, press and hold to adjust its intensity
NB: Please note that there will be a 5second delay when switching directly to suction power 1 (from any other speed) due to the electronic control of the product.
ENGLISH
6
Technical Data
Type of appliance
Wall-mounted Hood
Width
mm
798
Dimensions
Depth Total height in suction mode (min-max)
mm
510
mm
750-1030
Total height in recirculation mode (min-max)
mm
735-1090
Total power
W
257
Type
LED
Light info
Number & Power
W
1x7w
Connection
LED Strip
Minimum installation height – gas cooker
mm
650
Minimum installation height – electric cooker
mm
500
Product weight
Kg
15.6
Product information in accordance with EU Regulation no. 65/2014 – UK SI 2019 No.539
Name of Supplier
IKEA
Model identification code
UPPFRISKANDE 00527021
Annual energy consumption – AEC
Kwh/year
40.4
Energy efficiency class
A+
Fluid dynamic efficiency FDE
%
35.2
Fluid dynamic efficiency class
To
Luminous efficiency LE
lux/W
44.1
Luminous efficiency class
lux
To
Grease filtering efficiency – GFE
%
85.1
Grease filtering efficiency class
B
Minimum air flow (normal power)
m3/h
130.0
Maximum air flow (normal power)
m3/h
430.0
Airflow setting in boost mode
m3/h
720.0
A-weighted sound power level of noise emissions at minimum speed
Db(A) re 1pW
34.0
A-weighted sound power level of noise emissions at maximum speed
Db(A) re 1pW
58.0
A-weighted sound power level of noise emissions in boost mode
Db(A) re 1pW
70.0
Power consumption in off mode-P0
W
NA
Power consumption in standby mode-Ps
W
0.49
Product information in accordance with EU Regulation no. 66/2014 – UK SI 2019 No.539
Factor of increase over time – f
0.7
Energy efficiency index – EEI
42.8
Airflow measured at best efficiency point – QBEP
m3/h
420.0
Air pressure measured at best efficiency point – PBEP
Pa
465.0
Maximum airflow – Qmax
m3/h
720.0
Electric power consumption at best efficiency point – WBEP
W
154.0
Rated power of lighting system – WL
W
7.0
Average illuminance of the lighting system on the cooking surface – Emiddle
lux
309.0
To download the full version visit www.ikea.com
© Inter IKEA Systems B.V. 2023
23244
AA-2411568-1
LIB0190851 Ed. 06/23
