NW-200-12 200W Switching Power Supply
Product Information
Dimension:
- Length: 200 mm
- Width: 110 mm
- Height: 50 mm
Weight: 0.49 Kg
Applications
- Industrial control system
- Industrial automation machinery
- Mechanical and electrical equipment
- Electronic instruments, equipment or apparatus
- LED Lighting Series
Features
- International broad voltage AC input
- Protection against short-circuit, overload, and overheat
- 100% full-load aged 300VAC surge withstandable for 5
seconds - Working temperature up to 60°C
- 5G vibration tested
- High efficiency, long lifespan, and high reliability
- 2 years warranty
Specifications
| Product No. | NW-200-12 | NW-200-15 | NW-200-24 | NW-200-48 |
|---|---|---|---|---|
| DC voltage | 12V | 15V | 24V | 48V |
| Rated Current | 16.5A | 13.3A | 8.3A | 4.2A |
| Current Range | 0-16.5A | 0-13.3A | 0-8.3A | 0-4.2A |
| Output Rated Power | 200W | 200W | 200W | 200W |
| Ripple and Noise (Max) | 150mVp-p | 180mVp-p | 240mVp-p | 250mVp-p |
| Voltage adjustment | 10.8-13.2V | 13.5-16.5V | 22-27.6V | 44-52V |
| Voltage Accuracy | Note3 | – | – | – |
| Linear Adjustment | Note4 | – | – | – |
| Load Adjustment | Note5 | – | – | – |
| Start and rise time | 1000ms, 30ms/230VAC | 1000ms, 30ms/110V | – | – |
| Hold timeTyp | 50ms/230VAC | 10ms/115AC | – | – |
| Voltage range | – | – | – | – |
| Frequency range | 50HZ/60HZ | – | – | – |
| Input EfficiencyTyp AC current Typ Surge current (Typ) | 80% | 81% | 82% | 85% |
| Cold Start | 65A/230VAC | – | – | – |
| Current leak | – | – | – | – |
Product Usage Instructions
1. Ensure the input voltage matches the international broad
voltage AC input range.
2. Connect the product to the appropriate industrial control
system, industrial automation machinery, mechanical and electrical
equipment, electronic instruments, equipment or apparatus, or LED
lighting series.
3. Make sure the protection features are enabled to prevent
short-circuits, overloads, and overheating.
4. If necessary, adjust the output voltage within the specified
voltage adjustment range.
5. Check the ripple and noise levels to ensure they are within
the specified limits.
6. Follow the specified start and rise time for proper power
supply operation.
7. Check the hold time to ensure the power supply can maintain a
stable output during power interruptions.
8. Follow the specified input efficiency and AC current
requirements for optimal performance.
9. If applicable, perform a cold start according to the
specified procedure.
10. Make sure there are no current leaks from the power
supply.
11. For any issues or defects, refer to the 2 years warranty for
support and assistance.
Dimension L: 200 mm W:110 mm H:50mm
Weight: 0.49Kg
200W LED POWER SUPPLY SINGLE OUTPUT
Applications
Industrial controlsystem Industrial automation machinery Mechanical and electrical equirment
Electronic instruments, equirments or apparatus LED Lighting Series
Features
International broad voltage AC input Protection: short-circuit, overload,overheat 100% full-load aged 300VAC surge for 5 seconds withstandable Working temperature up to 60 5G vibration tested
High efficiency, long life span, and high reliability 2 years warranty
Specifications
Product No.
NW-200-12 NW-200-15 NW-200-24 NW-200-48
DC voltage
12V
15V
24V
48V
Rated Current Current Range
16.5A 0-16.5A
13.3A 0-1.3A
8.3A 0-8.3A
4.2A 0-4.2A
Output
Rated Power Ripple and Noise(Max)Note.2 Voltage adjustment
200W 150mVp-p 10.8-13.2V
200W 180mVp-p 13.5-16.5V
200W 240mVp-p 22-27.6V
200W 250mVp-p
44-52V
Voltage Accuracy Note3
±1%
±1%
±1%
±1%
Linear Adjustment Note4
±0.5%
±0.5%
±0.5%
±0.5%
Load Adjustment Note5
±0.5%
±0.5%
±0.5%
±0.5%
Start and rise time
1000ms,30ms/230VAC 1000ms,30ms/110V
Hold timeTyp
50ms/230VAC 10ms/115AC
Voltage range
AC 110V±15%/AC 220±15% changed by switch
Frequency range
50HZ/60HZ
Input
EfficiencyTyp AC current Typ Surge current (Typ)
80%
81%
82%
85%
4.17A/110V 1.9A/220V
Cold Start65A/230VAC
Current leak
<2mA/240VAC
Protection Overload
Working temp.
Working humidity
Environment Storage temp & hmdty
Temp. coefficient
Vibration proof
Safety regulation
Voltage proof
Safety reg. & EMC
(Note.6
insulation resistance
EMC irradiation
EMC disturbance proof
Larger than 105% of capacity
restoration after abnormity removed -20+60(Refer to the tenuation curve)
2090% RH, without condense -40+80
±0.03%/ 050
10500HZ,5G 10min / cycleXYZ axes 60 min each GB195110.1-2004/IEC61347-1:2003 CE(EMC+LVD) I/P-O:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG,O/P-FG:100M Ohms/500VDC/25/70% RH EN 55032:2015+A11:2020;EN55035:2017+A11:2020 EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019
Dimensions
200*110*50mm(L*W*H)
Packing
0.49kg/PCS;24PCS/18.2kg
1. Unless specially indicated, all data are taken under 230VAC input, rated load and 25 environment temp. 2.Ripple and noise: measured with a 12″ double ripple cord connected in parallel with a 0.1F and a 47 F capacitor on 20MHz bandwidth.
Notes:
3.Accuracy: including preset errors, linear adjustment rate and load adjustment rate.
4.Linear adjustment: taken under rated load from low voltage to high voltage.
5.Load adjustment: taken under 0~100% of rated load.
6. Power supply is taken as part of the whole system, and needs to be confirmed with terminal instruments for EMC.
Appearance Frame diagram
Terminal foot definition
Foot No.
Foot function
1
OUTPUT+
2
OUTPUT+
3
OUTPUT-
4
OUTPUT-
5
FG
6
AC/N
7
AC/L
Tenuation curve
Static property curve
