OM1200 Operations Manager NetOps Console
Server with Smart Out of Band
User Guide
Opengear OM appliances are NetOps Console Servers – Network Management appliances that combine the capabilities of a SmartOOB™ Console Server with the flexibility of NetOps Automation.
The compact OM1200 appliance is designed specifically for secure edge deployments, used in combination with Lighthouse Management Software. As a key component of Opengear’s Network Resilience Platform, it provides Presence & Proximity at every location that supports emerging requirements in Network Management and Automation.
Features
| • Half-width, shallow depth, 1RU form factor | • Global LTE interface (non-cellular optional) |
| • Cost-effective 4 or 8 Serial port-only models | • x86 platform; embedded physical security |
| • Mixed-port models: 4 or 8 Serial, 4 or 8 Ethernet | • Python runtime, Docker container support |
| Console Specifications | |
| Console Ports | OM1208-8E – 8 x RJ45 RS232 Cisco straight X2 pinout serial ports and 8 port embedded GbE switch OM1204 – 4 x RJ45 RS232 Cisco straight X2 pinout serial ports OM1208 – 8 x RJ45 RS232 Cisco straight X2 pinout serial ports OM1204-4E – 4 x RJ45 RS232 Cisco straight X2 pinout serial ports and 4 port embedded GbE switch |
| Interface | |
| Primary/Secondary Network Ports | 2 x 10/100/1000 Base-T Ethernet (OM120X), 2 x 10/100/1000 Base-T Ethernet/SFP Fiber auto-media ports (OM120X-XE) |
| Serial Ports | Cisco straight X2 50 to 230,400 bps Console Ports |
| USB | 2 x USB 3.0 Host Ports for storage and 2 x USB 2.0 ports for device console management |
| Remote Access | Integrated 4G LTE Cellular Card, Dual Ethernet, aggregation & redundancy, Automatic Network Failover, Easy browser UI, IPv6 |
| Power Requirements | |
| Power Adapter | 1x Universal 110-240V AC to 12V DC external power adapter IEC 62368, UL, CB, DoE, VI, PSE, LPS certified |
| Power Consumption | 25 W Maximum |
| Physical Dimensions | |
| Dimensions and Weight | 8 5/8 x 6 5/8 x 1 5/8 in – 2.2 lbs, 22 x 17 x 4.2 cm – 1 kg |
| Form Factor | Compact – SFF 1U half-rack width |
| Memory & CPU | |
| CPU | AMD GX-412TC (1.0/1.4GHz 64-bit x86 SoC) |
| Memory | OM120x – 2GB DRAM (SO-DIMM) OM120x-xE – 4GB DRAM (SO-DIMM) |
| Boot ROM | 16 MB SPI with password protection |
| Internal Storage | 16 GB m.SATA III SSD |
| Environmental | |
| Operating Temperature | 5°C to 50°C, 41°F to 122°F |
| Storage Temperature | -40°C to +75°C, -40°F to +167°F |
| Humidity | 5% to 90% |
| MTBF | 100,000 Hours (Power Supply) |
| Features | Smart Out-of-Band, Modern CLI/GUI/REST API, IPv4/IPv6 Networking, Serial Port Logging |
| Security, Encryption & Authentication | Trusted Platform Module 2.0 AAA – TACACS+, RADIUS, Active Directory/OpenLDAP, Kerberos, with local fallback Embedded Firewall IPSec and OpenVPN |
| Automation & Scalability | Opengear NetOps Modules Docker support Python and Ruby |
| Global LTE Cellular Interface | |
| Modules | OM12xx-L – Sierra Wireless EM7565 |
| Speed | CAT12 |
| Coverage | Global LTE-A Support |
| Certifications | |
| Cellular | PTCRB, GCF, Verizon, and AT&T |
| Emissions | EN 62311:2008, EN 62133 :2013, EN 301 489-1 V2.1.1(2017-02), EN 301 489-19 V2.1.1 (2019-04) , EN 301 489-52 V1.1.0 (2016-11), FCC Part 15 Subpart B:2015, ICES-003 Issue 6 |
| Immunity | EN 55032:2012, EN 55035:2017, EN 61000-3-2:2014, EN 6100-3-3:2013, EN 301 908-1, 2, 13 V13.1.1, EN 303 413 V1.1.1 NAPRD03 V5.37 |
| Other Agency Approvals | CE, IEC 6950-1, IEC 62368-1, CAN/CSA-C22.2, RoHS compliant, Security features to support NERC CIP standards |
| Warranty | 4 Years of hardware and support |
Available Models
Every OM1200 model shares the following features:
- Compact form factor (1RU half-width)
- CPU: 1.4 GHz 4-Core x86
- 16GB Internal Storage
- 2 USB 3.0 and 2 USB 2.0 ports
- Cisco X2 straight serial pinout
| MODEL | SERIAL PORTS | ETHERNET SWITCH PORTS | SFP PORTS | MEMORY | CELLULAR |
| OM1204 | 4 | No | No | 2GB | None |
| OM1204-L | 4 | No | No | 2GB | Global 4G LTE |
| OM1204-4E | 4 | 4 | 2 | 4GB | None |
| OM1204-4E-L | 4 | 4 | 2 | 4GB | Global 4G LTE |
| OM1208 | 8 | No | No | 2GB | None |
| OM1208-L | 8 | No | No | 2GB | Global 4G LTE |
| OM1208-8E | 8 | 8 | 2 | 4GB | None |
| OM1208-8E-L | 8 | 8 | 2 | 4GB | Global 4G LTE |
Note: All units ship with an external global AC power adapter: Part # 450038
The following power supply is available to order:
Part # 450036 – External Power Supply – 25W IEC-C14 inlet, 12V DC output barrel connector – IEC 62368
Package Checklist
| • Operations Manager OM1200 | • 4 x Rubber feet (370003) |
| • 1 x Rack Mount Kit (590054) | • 1 x 12V Global Power Supply (450038) |
| • 1 x DB9F-RJ45 Crossover (319015) | • Start-Up / Safety Instructions Card |
Cellular Enabled Models Also Include:
- 2 x Cellular Antennas (569041)
- 1 x Cellular Antenna Extender with magnetic base (449041)
Optional Accessories
| Part Number | Description | |
| Adapters | 319014 319015 319016 | Adapter – DB9F to RJ45 straight serial – DCE -For X2 Pinout Adapter – DB9F to RJ45 crossover serial – DTE -For X2 Pinout Adapter – DB9M to RJ45 straight serial – DCE – For X2 Pinout |
| Mounting | 590054 | Rack Mount Kit |
| Power Supply | 450036 450038 | External Power Supply – 25W IEC-C14 inlet, 12V DC output barrel connector – IEC 62368 External AC Power Adapter, universal input, output barrel connector – IEC 62368 |
| Cellular / GPS Antenna | 569018 449041 569041 | Antenna – GPS Active – 6′ Cable length Antenna Extender – Magnetic Base with 10′ Cable Antenna – Blade LTE-A with swivel base |
Warranty
| Part Number | Description |
| Included | 4-year standard warranty |
| OGEXTWAR5-OM1200 | Warranty OM1200 (Extends to 5th-year warranty) |
| OGEXTWAR6-OM1200 | Warranty OM1200 (Extends to 6th-year warranty) |
