HL-Y15W Wireless Charging PCBAC
Product Information:
- Manufacturer: Zhongshan Honglan Electronic Technology Co.,
Ltd - Product Name: Wireless Charging PCBAC
- Model Number: HL_Y15W
- Environmental Protection: ROHS
- PCB Color: Black, Green
- Weight: Not specified
- Product Size: 35*35*1.2mm
- ROHS Requirement: The wireless charger shall meet ROHS
Product Usage Instructions:
Indicator Light Description:
Power on: Green light, light up 3 times.
Standby Charging: Green light flashing.
Full: Green light always on.
FOD Warning: Red light on.
Breathe: Flashing green light.
Flashing Red Light: Flashing red light.
Basic Performance Parameters:
- Input Current: DC12V 2A-max
- Stand-by Power Consumption: 0.2W
- Working Frequency: 115KHz-205KHz
Protection Requirement:
- OCP (Over Current Protection):
Current-limiting is 12V 1.8A. - SCP (Short-Circuit Protection): The
short-circuit protection test ensures that when RX output is
short-circuited to the ground, the input power of the product will
be reduced without causing any damage. The MTBF (Mean Time Between
Failures) should not be less than 30000 hours at a temperature of
25°C.
Precautions for Use:
No information provided.
Please note that the final interpretation of this specification
belongs to Zhongshan Honglan Electronic Technology Co., Ltd.
Zhongshan Honglan Electronic Technology Co., Ltd
Zhongshan Honglan Electronic Technology Co. , Ltd.
CUSTOMER
SPECIFICATION FOR APPROVAL
CUSTOMER P/N
MATERIAL NO.
PRODICT NAME
Wireless charging PCBAC
SPECIFICATIONS
MODEL NO.
HL_Y15W
ENVIRONMENTAL PROTECTION :
ROHS
PCB COLOR
Black
Green
REMARKS
Honglan Electronic
CUSTOMER APPROVAL
EDIT
Electronic Confirm
Structure Confirm
Packing Confirm
CHECK
CHECK
Zhongshan Honglan Electronic Technology Co. , Ltd.
2F, 12 Nam Shing Lane, Yik Lung Road, Xiaolan, new Zhongshan
TEL+86177 2459 9870
FAX
Page 1 of 5
Zhongshan Honglan Electronic Technology Co. , Ltd.
CHANGE LIST
Rev.
Description
Before
After
Date
Name
Remark
25
Zhongshan Honglan Electronic Technology Co. , Ltd.
Content
1 Indicator light description ………………………………. 4 2 Basic Performance Parameters ……………………………. 4 3 Protection Requirement …………………………………….. 4 4 Mean Time Between Failure (MTBF ……………………… 5 10 Product Weight …………………………………………… 5 11 Product size picture …………………………….. 5 12 RoHS Requirement ………………………………………… 5 13 Product packing picture ……………………………….. 5 14 Statement …………………………………………………… 6
Page 3 of 5
Zhongshan Honglan Electronic Technology Co. , Ltd.
1
INDICATOR LIGHT DESCRIPTION
state
colour green light
Green
Power on
Light up 3 times
Standby Charging
Full
FOD
warning
Red light on
breathe
Green light Flashing always on red light
Flashing red light
2
BASIC PERFORMANCE PARAMETERS
4.1 Input voltage DC12V±0.25V
Input CurrentDC12V 2A-max
4.2 Stand-by power consumption0.2W
4.3 Working Frequency115KHz-205KHz
3
PROTECTION REQUIREMENT
3.1 OCP
current-limiting is 12V 1.8A.
3.2 SCP
The short-circuit protection test is that when RX output short-circuit to the ground, the input power of the product will be reduced and no damage will be caused. When the short-circuit cond
The MTBF should not be less than 30000 hours at the temperature of 25.
4
Page 4 of 5
Zhongshan Honglan Electronic Technology Co. , Ltd.
5
PRECAUTIONS FOR USE
6
WEIGHT
17.5 g±0.2 g
7
PRODUCT SIZE PICTURE
35*35*1.2mm
8 PRODUCT PACKING PICTURE
9
ROHS REQUIREMENT
The wireless charger shall meet ROHS.
10 STATEMENT
The final interpretation of this specification belongs to Zhongshan Honglan
Electronic Technology Co. , Ltd.
Page 5 of 5
