Brazo LED Table Lamp
Brazo Table and Brazo Floor Product Information:
The Brazo Table and Brazo Floor are high-performance LED lamps
that are designed to provide efficient and adjustable lighting for
various work environments. The lamps are available in four
finishes: Silver, Black, White, and Bronze. Both lamps feature a
full range dimming control with a rotary dimmer and have a lifespan
of 50,000 hours. The lamps are Title 20 compliant and have a 1-year
warranty.
Brazo Table:
- Fixture Type: Table
- Light Source: (108x) High output LED
array - Product Codes: Brazo Table (Silver): BRAZ TBL
SLV, Brazo Table (Black): BRAZ TBL BLK, Brazo Table (White): BRAZ
TBL WHT, Brazo Table (Bronze): BRAZ TBL BRZ - Features: Full range dimming control, 50
Lumens/Watt Luminaire efficacy, Color Rendition Index of 85 CRI,
Cable length of 8′ (244cm) - Specifications: Voltage: 120-240V 50-60Hz,
Power Consumption: 9W, Color temperature: 3000K, Luminosity: 450
Lumens - Dimensions: Height: 26.5″ (67cm), Width: 4″
(10.2cm), Surface mount available for 1.18″ (3cm), 2″ (5cm), and 3″
(7.5cm) worksurfaces - Certifications: Title 20 compliant
- Packaging Weight and Dimensions: 14.2lbs
(6.4kgs), 39″ x 11″ x 5″ (99cm x 28cm x 13cm)
Brazo Floor:
- Fixture Type: Floor
- Light Source: (108x) High output LED
array - Product Codes: Brazo Floor (Silver): BRAZ FLR
SLV, Brazo Floor (Black): BRAZ FLR BLK, Brazo Floor (White): BRAZ
FLR WHT, Brazo Floor (Bronze): BRAZ FLR BRZ - Features: Full range dimming control, 50
Lumens/Watt Luminaire efficacy, Color Rendition Index of 85 CRI,
Cable length of 8′ (244cm) - Specifications: Voltage: 120-240V 50-60Hz,
Power Consumption: 9W, Color temperature: 3000K, Luminosity: 450
Lumens - Dimensions: Height: 26.5″ (67cm), Width: 8.5″
(21.5cm) - Certifications: Title 20 compliant
- Packaging Weight and Dimensions: 15.55lbs
(7.1kgs), 39″ x 11″ x 5″ (99cm x 28cm x 13cm)
Brazo Table and Brazo Floor Product Usage Instructions:
Before using the Brazo Table or Brazo Floor, please ensure that
the lamp is properly assembled and connected to a power source. To
turn the lamp on or off, simply use the switch located on the power
cord.
To adjust the brightness of the lamp, use the rotary dimmer
located on the base of the lamp. Turn the dimmer clockwise to
increase the brightness and counterclockwise to decrease the
brightness.
The surface mount option is available for the Brazo Table. To
use this option, attach the surface mount bracket to the table
using the provided screws. Then, attach the lamp to the bracket
using the provided hardware.
Please note that custom requests can be considered for volume
orders of both lamps.
BRAZO TABLE
DESCRIPTION
Brazo’s precision machined aluminum construction allows for optimal task lighting control with 360° adjustability and 90° tilt. Brazo features a luminous and energy-efficient LED light source which can be dialed to any desired beam-spread and brightness depending on the task.
FIXTURE TYPE Table
LIGHT SOURCE (108x) High output LED array
PRODUCT CODES
Brazo Table (Silver): Brazo Table (Black): Brazo Table (White): Brazo Table (Bronze):
BRAZ TBL SLV BRAZ TBL BLK BRAZ TBL WHT BRAZ TBL BRZ
LIGHT CONTROL Full range dim (rotary dimmer)
FEATURES
360° arm rotation 90° arm tilt Calibrated light focus control Height adjustable Advanced LED array eliminates multiple shadows Ships flat-packed 97% recyclable
FINISHES
SPECIFICATIONS
Voltage: 120-240V 50-60Hz Power Consumption: 9W Color temperature: 3000K Luminosity: 450 Lumens Luminaire efficacy: 50 Lumens/Watt Color Rendition Index: 85 CRI Title 20 compliant 50K hour lifespan Cable length: 8′ (244cm) Global multi-plug adapter available 1 year warranty
SILVER
BLACK
WHITE
BRONZE
DIMENSIONS
BRAZO TABLE
26.5″ (67cm)
14″ 21″ (35.5 53.5cm)
90º 360º
CERTIFICATIONS
8.5″ (21.5cm)
PACKAGING WEIGHT AND DIMENSIONS BRAZO TABLE: 14.2LBS 39” X 11” X 5”
6.4KGS 99cm X 28cm X 13cm
NOTES Custom requests can be considered on volume orders
26.5″ (67cm)
14″ 21″ (35.5 53.5cm)
4″ (10.2cm)
SURFACE MOUNT AVAILABLE FOR 1.18″ (3cm), 2″ (5cm) AND 3″ (7.5cm) WORKSURFACES
BRAZO FLOOR
DESCRIPTION
Brazo’s precision machined aluminum construction allows for optimal task lighting control with 360° adjustability and 90° tilt. Brazo features a luminous and energy-efficient LED light source which can be dialed to any desired beam-spread and brightness depending on the task.
FIXTURE TYPE Floor
LIGHT SOURCE (108x) High output LED array
PRODUCT CODES
Brazo Floor (Silver): Brazo Floor (Black): Brazo Floor (White): Brazo Floor (Bronze):
BRAZ FLR SLV BRAZ FLR BLK BRAZ FLR WHT BRAZ FLR BRZ
LIGHT CONTROL Full range dim (rotary dimmer)
FEATURES
360° arm rotation 90° arm tilt Calibrated light focus control Height adjustable Advanced LED array eliminates multiple shadows Ships flat-packed 97% recyclable
SPECIFICATIONS Voltage: 120-240V 50-60Hz
FINISHES
Power Consumption: 9W
Color temperature: 3000K
Luminosity: 450 Lumens
Luminaire efficacy: 50 Lumens/Watt
SILVER
BLACK
WHITE
BRONZE
Color Rendition Index: 85 CRI
Title 20 compliant
50K hour lifespan Cable length: 8′ (244cm)
DIMENSIONS
Global multi-plug adapter available
BRAZO FLOOR
1 year warranty CERTIFICATIONS
26.5″ (67cm)
90º
360º
PACKAGING WEIGHT AND DIMENSIONS BRAZO FLOOR: 15.55LBS 39” X 11” X 5”
7.1KGS 99cm X 28cm X 13cm NOTES Custom requests can be considered on volume orders
48″ 55.5″ (122 141cm)
8.5″ (21.5cm)
