ESR-4145 Pipe Hanger 767G
Product Information
Product Name: Pipe Hanger 767G
Lot Number: ESR-4145
Manufacturer: Hilti Corporation
Trademark: Hilti
Country of Origin: Taiwan
Registered Trademark: Yes
Additional Information: This product is
designed for pipe hanger applications. It has a lot number of
ESR-4145 and is manufactured by Hilti Corporation, a renowned
company based in Taiwan. The product carries the registered
trademark of Hilti and is made with high-quality materials to
ensure durability and reliability.
Product Usage Instructions
- Ensure you have received all the necessary components for
installation. - Identify the KCM-WF-ST pipe hanger and the threaded rod.
- Position the KCM-WF-ST pipe hanger on the desired location for
pipe support. - Insert the threaded rod through the designated hole in the pipe
hanger. - Tighten the threaded rod by turning it clockwise until it is
fully engaged and bottomed out.
Note: It is important to ensure that the threaded rod is turned
until it is fully engaged and bottomed out to provide secure and
reliable pipe support.
2371063-11.2022
150 Kwik Cast KCM-WF ¼” + ” + ½” BLK-BLU #2363080
1a
hmin = 2 ½”
KCM-WF ¼” + ” + ½”
LOT NUMBER:
ESR-4145
Pipe Hanger 767G
qr.hilti.com/r8107118
Made in Taiwan 7 6 1 3 0 2 4 6 1 5 3 4 6 Hilti = registered trademark of Hilti Corporation, Schaan, LI
1b
2
1
KCM-WF-ST
2
3
4* 0 in
0 in
”
90°
¼” 0in
* Turn threaded rod until bottomed
½”
out to ensure full thread engagement
UL/FM Listing does not cover the ¼-inch rod size
