RF502A Remote Control
Product Information:
The product in question is a remote-controlled bed with various
adjustable actuators that allow the user to adjust the position of
the head, foot, and lumbar areas. The bed also features a white
noise function and massage options for the head and foot areas. The
remote control includes buttons for adjusting the bed’s position
and settings, as well as a child lock function and a pairing
button.
Product Usage Instructions:
- To adjust the bed to the ZG position, click the ZG button. The
actuator will stop when any button is clicked during movement. - To move the actuators to the AntiSnore position, click the
AntiSnore button. The actuator will stop when any button is clicked
during movement. - To raise the head of the bed, press and hold the HEAD UP button
on the remote. Release the button to stop movement. - To lower the head of the bed, press and hold the HEAD DOWN
button on the remote. Release the button to stop movement. - To raise the foot of the bed, press and hold the FOOT UP button
on the remote. Release the button to stop movement. - To lower the foot of the bed, press and hold the FOOT DOWN
button on the remote. Release the button to stop movement. - To move the bed to a flat position, click the FLAT button. The
bed will stop moving if any button is clicked during the
process. - To adjust the massage intensity for the head area, click the
MASSAGE HEAD button. The intensity level will switch between
0-1-2-3. - To adjust the massage intensity for the foot area, click the
MASSAGE FOOT button. The intensity level will switch between
0-1-2-3. - To set the massage time, click the MASSAGE TIME button and
choose between 10-20-30 minutes. - To display the menu interface on the screen, click the MENU
button. - To go back to the previous screen, click the BACK button.
- To navigate the screen content, use the UP, DOWN, LEFT, and
RIGHT buttons. - To confirm screen content, click the OK button.
- To reduce the volume of the white noise function, click the
WHITE NOISE VOLUME DOWN button. - To activate or pause the white noise function, click the WHITE
NOISE ACTIVE/PAUSE button. - To increase the volume of the white noise function, click the
WHITE NOISE VOLUME UP button. - To move the actuator to a saved memory position, click the
MEMORY POSITION button. - To lock or unlock the remote control, double-click the CHILD
LOCK button. - To pair the remote control with the bed, press and hold the
PAIR button for 3 seconds.
Issue DepartmentBedding Division Date 2023-05-26
System Instruction
Author
Instruction of RF432A 2Instruction of RF502A
Edition
1.1
Page 1 of 5
Figure 1 button ofremote 1 / 5
Issue DepartmentBedding Division Date 2023-05-26
System Instruction
Author
Instruction of RF432A Item
Edition
1.1
Page 2 of 5
1.1 ZG button 15
Click the ZG button, the actuator moves to ZG position, stop when click any button during the movement.
1.2 AntiSnore button 12
Click AntiSnore button, actuators move to AntiSnore position, stop when click any button
during movement.
1.3 Head up 13
Press and hold HEAD UP button of remote, head actuator moves out, stop when released
1.4 Head down 14
Press and hold HEAD DOWN button of remote, head actuator moves in, stop when released
1.5 Foot up 17
Pressa and hold FOOT UP button of remote, foot actuator moves out, stop when released;
1.6 foot down 18
Press and hold FOOT DOWN button of remote, foot actuator moves in , stop when released When moving to flat position, lumbar actuator and tilt actuator move first, after 500ms, head and
foot actuators start moving;
2 / 5
Issue DepartmentBedding Division Date 2023-05-26
System Instruction
Author
Instruction of RF432A
Edition
1.1
Page 3 of 5
1.7 Flat 16
Click FLAT button, the bed goes flat, stop when click any button during the process of going flat
1.8 Massage head 1
Click MASSAGE HEAD button, head massage motor switches massage intensity, massage intensityswitches among 0-1-2-3
1.9 Massage foot 3
Click MASSAGE Foot button, head massage motor switches massage intensity, massage intensityswitches among 0-1-2-3
1.10 Massage time 2
Click MASSAGE time button to set massage time among 10-20-30mins.
1.11 Menu 4
Click Menu button to display the menu interface at screen.
1.12 back 5
Click Back button to operate the screen content as back.
1.13 up down left right 6 7 9 10
Click these buttons to operate the screen content as up,down,left,right.
1.14 ok 8
Click ok button to operate the screen content confirm.
3 / 5
Issue DepartmentBedding Division Date 2023-05-26
System Instruction
Author
Instruction of RF432A 1.15 white noise volume down 19
Edition
1.1
Page 4 of 5
Click white noise volume down button to reduce the white noise volume.
1.16 white noise active/pause 20
Click white noise active/pause button to active or pause the white noise.
1.17 white noise volume up 21
Click white noise volume down button to plus the white noise volume.
1.18 Memory position 11
Click memory position to move the actuator to the memory position.
1.19 child lock 22
Double click child lock button to lock or unlock the remote.
1.20 pair 23
Click pair button for 3 seconds to pair.
FCC
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
4 / 5
Issue DepartmentBedding Division Date 2023-05-26
System Instruction
Author
Instruction of RF432A
Edition
1.1
Page 5 of 5
IC RSS warning
This device complies with Industry Canada licence-exempt RSS standard (s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,including interference that may cause undesired operation of the device.
ISED RSS Warning:
This device complies with Innovation,Science and Economic Development Canada licenceexempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’ISED applicables aux appareils radioexempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
