WA01086 Outdoor Rollator

Product Information

The WA01086 is a rollator designed to provide support and
mobility to individuals with limited mobility. The rollator comes
equipped with adjustable handgrips, a parking/service brake,
height-adjustable handles, rear wheels, a back support belt, a
sitting area with a drawstring shopping bag, and front wheels. The
rollator has pneumatic tires that require tire pressure of
approximately 2.4 bars for safe use. The rollator is constructed
from durable materials and comes with a suspension system for added
comfort.

Product Specifications

• Minimum Height: N/A
• Maximum Height: N/A
• Length: N/A
• Width: N/A
• Folded Width: N/A
• Folded Height: N/A
• Folded Length: N/A
• Minimum/Maximum Seat Height: N/A
• Seat Width: N/A
• Seat Depth: N/A
• Total Weight (kg): N/A
• Carry Weight (kg): N/A
• Rear Wheel Size: N/A
• Front Wheel Size: N/A
• Max User Weight (kg): N/A
• Frame Material: N/A
• Wheel Material: N/A
• Handle Material: N/A
• Suspension: Yes
• Bag Depth: N/A
• Bag Width: N/A
• Bag Length: N/A

Product Usage Instructions

Before Use

Do not hang bags on the handles as it can cause the rollator to
tip over. Use the service brake when going downhill by pulling the
brake levers up. Use the rollator only on firm, level ground. Do
not lean too much against the handles as it can cause the rollator
to tilt backward. Be cautious when folding and unfolding the
rollator.

Cleaning

Clean and disinfect the rollator regularly using a mild soapy
solution without abrasives. Do not use steam jet equipment or
scouring or corrosive cleaning agents.

Maintenance

Check regularly whether all screws and nuts are tightened. Loose
screws and nuts must be tightened again. Self-locking nuts must be
replaced after loosening because they have lost their self-locking
effect. If you have a slackening of the brakes, binding of the
wheels, or other functional restrictions, contact your local
dealer.

Setup/Deploy Rollator

1. Apply the parking brake as described in Fig. 6. Then pull the
   rollator apart as shown in Fig. 1.
2. With both hands, push down the side tubes of the seat area on
   the left and right until the folding mechanism engages (Fig. 2). Do
   not touch under the seat, otherwise, you could pinch your
   fingers.
3. Insert the back strap into the rails from above and lock with
   the screws (Fig. 3).

Tire Pressure

Before starting any use, check the tire pressure of the
pneumatic tires and ensure that it is approximately 2.4 bars to
avoid damaging the tires and ensure a safe stand of the
rollator.

Adjust Handle Height

1. Loosen the locking screw (Fig. 4) and adjust the handles to the
   desired height. Ensure that both handgrips are set at the same
   height and locked securely.
2. Tighten the locking screw again.

Brake

The rollator has two types of brakes:

1. Service Brake (when pushing): Pull the brake levers upwards
   (Fig. 5).
2. Parking Brake (when parking): Push the brake levers down (Fig.
   6).

Climbing Aid

To lift the front wheels for mounting curbs and other obstacles,
use your foot to step down on the extended frame.

Fold Rollator

If the shopping bag is filled, remove it from the frame first.
Pull the lock in the middle of the seat area, and the rollator will
fold. Continue folding the rollator by reversing the order as
described in the section Set Up Deploy Rollator.

USER MANUAL
WA01086

PRODUCT CODE WA01086
PRODUCT SPECIFICATION
Handgrip Adjustable Parking / Service Brake
Height Adjustment of the Handles Rear Wheels

Back Support Belt
Sitting Area with Drawstring Shopping Bag

Front Wheels
BEFORE USE
· Carefully remove all packaging. Avoid using any knives or other sharp instruments as this may damage the surface of the product.
· Check the product for any visible damage. If you see any damage or suspect a fault, do not use your product, but contact your supplier for support.
INTENDED USE
This aluminium Rollator has been designed to assist persons with reduced mobility, as a walking aid and seating for a temporary period of rest. The shopping bag accessory is intended for the transport of lightweight goods and objects and the weight of any objects placed in this bag, should be taken into consideration of the overall maximum carry weight for this product of 136kg. This rollator should only be used on firm and even ground. Using this device in any other way other than what it is intended, could cause damage or injury.
· For Indoor & Outdoor Use i
· Multiple Users & Multiple Use product
P. 2

PRODUCT CODE WA01086
SAFETY INSTRUCTIONS
Do not hang bags on the handles – danger of tipping! On downhill roads, use the service brake (pull the brake levers up). Use the rollator only on firm, level ground. If you lean too much against the handles, the rollator can tilt backwards. Caution needed when folding and unfolding the rollator.
CLEANING
Cleaning and disinfection should be carried out at regular intervals. Use a mild soapy solution without abrasives. Disinfection can be carried out using commercially available means. Do not use steam jet equipment or scouring or corrosive cleaning agent.
MAINTENANCE
Check regularly whether all screws and nuts are tightened. Loose screws and nuts must be tightened again. Self-locking nuts must be replaced after loosening because they have lost their self-locking effect. If you have a slackening of the brakes, binding of the wheels or other functional restrictions are found, please contact your local dealer.

WARNING!
Before commencing any use of the rollator, make sure that the locking screws are tightened as shown in fig. 4.

fig. 1

SET UP / DEPLOY ROLLATOR
1. Apply the parking brake as described in fig. 6. Then pull the rollator apart as shown in fig. 1.

fig. 2

2. With both hands, push down the side tubes of the seat area on the left and right until the folding mechanism engages (fig. 2). Do not touch under the seat, otherwise you could pinch your fingers.

3. Insert the back strap into the rails from above and lock with the screws (fig. 3).

fig. 3
P. 3

PRODUCT CODE WA01082
TYRE PRESSURE!
Your rollator has pneumatic tyres. In order not to damage the tyres and to ensure a safe stand of the rollator, the correct tyre pressure of approx. 2.4 bar should always be used. Check this before starting any use!

fig. 5

ADJUST HANDLE HEIGHT
4. The handles of the rollator can be adjusted in height to fit the size of the user. Loosen the locking screw (fig. 4) and set the handles to the desired height. Please make sure that both handgrips are set at the same height and locked securely. Then tighten the locking screw again.
Locking screw height adjustment
fig. 4

fig. 6

BRAKE
5. Service brake (when pushing): Pull the brake levers upwards (fig. 5).
6. Parking Brake (when parking): Push the brake levers down (fig. 6).

CLIMBING AID
Use your foot to step down on the extended frame to help lift the front wheels to mount curbs and other obstacles.

FOLD ROLLATOR
If the shopping bag is filled, remove it from the frame first. Pull the lock in the middle of the seat area and the rollator will fold. Continue folding the rollator by reversing the order as described in the section “Set Up Deploy Rollator”.
P. 4

PRODUCT CODE WA01082
TECHNICAL SPECIFICATIONS
Min height Max height Length Width Folded width Folded height Folded length Min / Max seat height Seat width Seat depth Total weight (kg) Carry weight (kg) Rear wheel size Front wheel size Max user weight (kg) Frame material Wheel material Handle material Suspension Bag depth Bag width Bag length

84cm / 840mm 96.5cm / 965mm 71cm / 710mm 65cm / 650mm 20.5cm / 205mm 88cm / 880mm 71cm / 710mm 62.5cm / 625mm 44.5cm / 445mm 22.5cm / 225mm 9
29 x 4cm / 290 x 40mm 29 x 4cm / 290 x 40mm 136 Aluminium PP rim+Rubber tyre PA6+30%GF No 24cm / 240mm 17cm / 170mm 40cm / 400mm

P. 5

PRODUCT CODE WA01086
WARRANTY
This product carries a 2 year warranty from the date of purchase against manufacturing defects. Misuse, damage or worn spare parts are not covered as part of this warranty. This does not affect your statutory rights.

SEE PRODUCT LABEL SEE PRODUCT LABEL

5 056059 113715
