Etac 28642 Add On Foot Box Instruction Manual

28642 Add On Foot Box

Product Information

The product is a mounting kit that includes the following:

• 4 x Cross 6
• 4 x Cross 5
• 2 x L-shaped brackets (M and L)
• 1 x Prio bracket
• 1 x 6 mm screw
• Required screws and bolts for installation

The product is designed to be used for mounting purposes and can
hold up to a maximum weight of 2 kg.

Product Usage Instructions

1. First, determine the location where you want to mount the
   product and ensure that it is suitable for the weight of the
   product.
2. Assemble the Cross 6 and Cross 5 components to create a frame
   according to the diagram shown in the manual.
3. Attach the L-shaped brackets to the frame using the provided
   screws and bolts.
4. Attach the Prio bracket to the center of the frame using the
   provided screws and bolts.
5. Place the product onto the frame and secure it in place using
   the provided screw.
6. Attach the entire assembly to the wall using the required
   screws and bolts, ensuring that it is securely fixed in place.

Note: The minimum distance between the product and the wall
should be at least 60 mm.

Monteringsanvisning/Assembly instructions/Montageanweisung
28642 28643 Fotlåda 40-45/50-55 cm Footbox 40-45/50-55 cm Fußkasten 40-45/50-55 cm
x1 75423.3 2022-09-09
11

x4 x4
6 mm

AB CDE F G

GF EDCBA

AB CDE F G

Cross 6, Cross 5

M

L

GF EDCBA

Prio

M

L

B

C

40 cm

D

42.5 cm

E

45 cm

F

47.5 cm

47.5 cm 50 cm 52.5 cm

Etac Supply Center AB Långgatan 12 SE-334 33 Anderstorp www.etac.com

B

C

D

40 cm

E

F

45 cm

45 cm 50 cm 55 cm

2
Min 60 mm
