Cub Cadet Gt 54 Fab Lawn Tractor User Manual

Welcome to high performance, premium quality, innovation and strength. Welcome to Cub Cadet.*

GT 54 FAB Lawn Tractor

Parts/Warranty Supplement

Models

GT 54 FAB, GX 50, GX 54 D, LT 42, LT 46, LT 50 FAB,
LX 42, LX 46, SLX 50, SLX 54, ST 54 FAB
S-shape center hole
FastAttach™ center hole
* — Requires installation : 918-07384
# — Requires installation: 918-07389

Customer Support

Please do NOT return the machine to the retailer or dealer without first contacting the Customer Support Department.
If you have difficulty assembling this product, have questions regarding the controls, operation, or maintenance of this machine, want to order replacement parts/attachments/accessories, or want to view an online How-To video; you can seek help from the experts. Have your full model number and serial number ready. Choose from the options below.

USA
◊ Web: www.cubcadet.com/equipment/cubcadet/service-and-parts
◊ Phone/ Teléfono/ Téléphone: (800) 965-4CUB
◊ Mail/ Correo/ Courrier: Cub Cadet LLC • P.O. Box 361131
Cleveland, OH • 44136-0019
CANADA
◊ Web: www.cubcadet.ca/equipment/en/cubcadetcanada/Parts
◊ Phone/ Teléfono/ Téléphone: 1-800 – 668-1238
◊ Mail/ Correo/ Courrier: P.O. Box 1386 • 97 Kent Avenue
Kitchener, Ontario, Canada • N2G 4J1

Replacement Parts

Part Number	Packaged Part No.	Description
954-05021	490-501-C062	Deck Belt : 13A6, 13AK, 13AP)
954-05022A	490-501-C063	Deck Belt : LT 46
954- 05087A		Deck Belt : LX 46
954- 04077A	OCC-754-04077	Deck Belt : 50”
954-05025A	490-501-C064	Deck Belt : 54”
954-05027B	490-501-C061	Drive Belt
954-05156A		Drive Belt : GX 54 D
742P05177	490-110-C191	Blade
742P05177A-X	490-110-C202	Blade: 42” (S-Blade)
742P05177-L	490-110-C198	Blade : 42” (S-Blade)
742P05573	490-110-C192	Blade : 46” (S-Blade/)
742P05510-X	490-110-C203	Blade : 46” (S-Blade)
742P05510-L	490-110-C199	Blade
742P05094	490-110-C193	Blade
742P05094-X	490-110-C204	Blade: LT 50 XTREME™ (S-Blade)
742P05094-L	490-110-C200	Blade: LT 50 (S-Blade)
742P05228		Blade : 50” FastAttach™
942-01050-X		Blade: 50” FastAttach™
942-01050-L		Blade: 50” FastAttach™
	490-110-C197	Blade : GX 50 * ,   SLX 50 * ,  GX54 D #  & SLX 54 # (FastAttach™)
742P05086	490-110-C194	Blade: 54” (S-Blade/)
742P05086-X	490-110-C205	Blade: 54” XTREME™ (S-Blade/)
742P05086-L	490-110-C201	Blade : 54” (S-Blade)
742P05164		Blade : 54” FastAttach™

Register your product at cubcadet.com/register to have parts, owner manuals, and warranty information at your fingertips.
Cub Cadet LLC, P.O. Box 361131, Cleveland, Ohio 44136-0019

Form No.769-26638 (August 30, 2022/ 30 de agosto de 2022/ 30 août 2022)

Replacement Parts, continued

Part Number	Packaged Part No.	Description
942-01054-X		Blade: 54″ FastAttacr
942-01054-L		Blade: 54″ FastAttacr attach'”
736-3088		S-Blade Flat Washer (if equipped)
618P09259		Deck Spindle:42″ (S-Blade)
618P09258		Deck Spindle: 46″ (S-Blade)
618P09255		Deck Spindle: LT 50″ (S-Blade)
918-07384A		Deck Spindle : 50″ FastAttacr
618P09236		Deck Spindle: ST 54″ &GT 54″ (S-Blade)
918-07389A		Deck Spindle : 54″ FastAttach”‘
734-06305A	490-325-0073	Ball Deck Wheel
734-06265		Narrow Deck Wheel: LT46″
731-05679B		Nose Roller : 50″ & 54″
751P15242A		Gas Cap

Attachments & Accessories

Part No.	Part/
19A30031100	Bagger :42″, 46″
19A30018100	Bagger :50″, 54″
19A30046100	Mulch Kit:42″, S-Blade/ Cuchilla de s/ Lames (Stamped)
19B30054100	Mulch Kit: 42″, S-Blade(FAB)
19A30047100	Mulch Kit :46″, S-Blade
19A30050100	Mulch Kit : 50′, S-Blade
19A30052100	Mulch Kit: SLX 50″ & GX 50″
19A30051100	Mulch Kit : 54″, S-Blade
19A30053100	Mulch Kit: SLX 54″ & GX 54″ D
19A30029100	Rear Cargo Carrier: FastAttacr
19A30028100	Rear Spreader : FastAttacr 100#
19B40026100	Hauler
19A30035100	Rear Cargo Carrier & Sprayer: FastAttachTM
19A300170EM	Snow Blade

CUB CADET LLC — LIMITED WARRANTY

The limited warranty set forth herein is given by Cub Cadet LLC with respect to a new Cub Cadet® product (hereinafter “Product”) purchased and used in the United States and/or Canada to the Initial Purchaser (as defined herein). This limited warranty does not cover Emission Control Systems and is not a Federal Emission Control Warranty Statement, as defined by U.S. federal law. Please refer to the Federal Emission Control Warranty Statement in the operator’s manual for warranties covering Emission Control Systems.

Scope of the Limited Warranty
Cub Cadet LLC warrants that the Product (except with regard to the components and circumstances defined below as “Exclusions”) will be free from defects in materials and workmanship during the Warranty Period, as defined below. For purposes of this limited warranty, the “Initial Purchaser” is the first person/company to purchase this new Product from an authorized Cub Cadet dealer, distributor, and/or retailer of such products, including a party for whom said Product was purchased as a gift. This limited warranty is non-transferable. During the Warranty Period, Cub Cadet LLC will, at its option, either repair or replace any original part that is covered by this limited warranty and is determined to be defective in workmanship or material. “Commercial Use” shall be defined as any commercial, professional, agricultural, institutional, or income-producing use of the Product. See notes below as to Commercial Use Warranty.

Additional Warranty Notes

Lead-Acid Batteries: Are covered by a one (1) year prorated limited warranty against defects in material and workmanship, with 100% replacement during the first three (3) months, from the date of original purchase by the Initial Purchaser. After three (3) months, the battery replacement credit is based on the months remaining in the twelve (12) month period, dating back to the date of original purchase by the Initial Purchaser. Any replacement battery will be warranted only for the remainder of the original warranty period.
Frames: The frame, chassis, and front axle on all XT1, XT2, and XT3 products are covered for “Residential Use” by a five (5) year-limited warranty. The frame on all Ultima ZT and ZTX series products are covered for “Residential Use” by a seven (7) year Limited Lifetime Warranty.
Mowing Decks: 1) Cub Cadet LLC warrants the mowing decks under the warranty of the product it came with unless otherwise stated. 2) When so equipped, the optional fabricated cutting deck shell (excluding wear parts, etc. thereon) shall be warranted against defects in material and workmanship for the lifetime of the product, namely for as long as it is owned by its Initial Purchaser or the party for whom it was originally purchased as a gift, or seven (7) years from the date of its initial sale to an Initial Purchaser, whichever comes first. 3) The deck shell, deck spindles, and deck steel pulleys (collectively the “Deck Assembly”) on PRO Z 500 / 700 / 900 and PRO X-600 products only, shall also be warranted to be free from defects in material and workmanship for up to an additional two (2) years (a total of five (5) years from the date of purchase) or 1,750 cumulative hours of operation, whichever comes first. For purposes of clarity, no hour limitation applies during the initial three (3) year period described above.
Snow Blowers: Three-Stage and Two-Stage (excluding 2X 24 models) – Auger gearboxes have a five (5) year limited warranty.
L and S Series: RZT L/LX, Z-Force L/LX/SZ, PRO Z 100 L, Z-Force Commercial (LZ/SZ), and Tank (L/S): Please refer to warranty included with Operator’s Manual.
Attachments/Accessories: Please refer to warranty with Operator’s Manual.
*Limited Commercial Use Warranty: Handheld products – 90 days; Chipper-Shredder Vacuums, Blowers, Log Splitters, Snow Blowers – 1 year; Utility Vehicle – 6 month.
† No Commercial Use Warranty: Tillers, String Trimmers, Lawn Edgers, Pressure Washers, Battery Powered Product, Walk Behind Mowers, 60 Volt Max
Product Series, CC30 Riders, Enduro Series, RZT S/SX, Ultima ZT Series, and Z-Force.
The limited warranty is non-transferrable

How to Get Service Under This Limited Warranty
In order to qualify for the limited warranty, as set forth herein, the repairs made under this warranty must be performed by an authorized Cub Cadet service provider. To locate a Cub Cadet service provider, contact your authorized Cub Cadet dealer, distributor, or retailer, or contact Cub Cadet LLC at P.O. Box 368023, Cleveland, Ohio 44136-0019, or call 1-877-282-8684, or log on to our Website at www.cubcadet.com. For Canada, contact MTD Products Limited, 97 Kent Ave, Kitchener, ON N2G 3R2, or call 1-800-668-1238, or log on to our Website at www.cubcadet.ca. This limited product warranty is provided by Cub Cadet LLC and is the only product warranty provided by Cub
Cadet LLC for the Product. A COPY OF YOUR SALES RECEIPT IS REQUIRED FOR WARRANTY SERVICE.

What This Limited Warranty Does Not Cover
This limited warranty does not cover the following (the “Exclusions”):

1. Product purchased outside of the United States or Canada.
2. Emission Control Systems. These items are subject to a separate warranty under the applicable Federal Emission Control Warranty Statement. Please refer to the applicable Federal Emission Control Warranty Statement for terms and conditions relating to Emission Control Systems.
3. Damage due to lack of maintenance and/or improper maintenance, as described in the operator’s manual.
4. Normal wear and tear resulting from use of the Product.
5. Normal Wear Parts (as defined herein) are warranted to be free from defects in material and workmanship for a period of thirty (30) days from the date of original purchase by the Initial Purchaser for residential use, and for 30 days or 100 hours (whichever occurs first) for Product used commercially. Depending on Product, Normal Wear Parts include but are not limited to items such as: belts, blades, blade adapters, grass bags, rider deck wheels, seats, shave plates, skid shoes, tines, filters, nozzles, hoses, O-rings, spray guns, wands, tires, spark plugs, fuses, bump knobs, outer spools, cutting line, inner belts, starter pulley, starter rope, drive belts, saw chains, guide bars, and other consumable items.
6. Log splitter pumps, valves, and cylinders are covered for a period of one (1) year.
7. Use of the product that is not consistent with the intended use thereof, as described in the operating instructions, including, but not limited to, abuse, misuse and/or neglect of the Product, or any use inconsistent with and/or non-compliant with instructions contained in the Operator’s Manual. This includes operation in sandy and/or corrosive environments.
8. Any Product that has been altered or modified in a manner not consistent with the original design of the Product or in a manner not approved by Cub Cadet LLC.
9. Paint repairs or replacements for defective paint (including materials and application) are covered for a period of three (3) months.
10. Wheel rims (when so equipped) are covered for a period of three (3) months for manufacturing defects.

This warranty does not cover, and Cub Cadet LLC disclaims any responsibility for, matters including, but not limited to, the following:

1. Loss of time or loss of use of the Product.
2. Transportation costs and other expenses incurred in connection with the transport of the Product to and from the authorized Cub Cadet service provider.
3. Any loss or damage to other equipment or personal items.
4. Damages caused by improper maintenance or the use of other than the specified fuel, oil, or lubricants, as approved in the operator’s manual.
5. Damage resulting from the installation or use of any accessory or part not approved by Cub Cadet LLC for use with the Product.

Limitations

1. THERE ARE NO IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. NO WARRANTY SHALL APPLY AFTER THE APPLICABLE WARRANTY PERIOD, AS SET FORTH ABOVE, AS TO THE PARTS AS IDENTIFIED. NO OTHER EXPRESS WARRANTY OR GUARANTEE, WHETHER WRITTEN OR ORAL, EXCEPT AS MENTIONED ABOVE, GIVEN BY ANY PERSON OR ENTITY, INCLUDING A DEALER OR RETAILER, WITH RESPECT TO ANY, PRODUCT SHALL BIND CUB CADET LLC. DURING THE WARRANTY PERIOD, THE EXCLUSIVE REMEDY IS THE REPAIR OR REPLACEMENT OF THE DEFECTIVE PART, AS SET FORTH ABOVE. (SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.)
2. THE PROVISIONS, AS SET FORTH HEREIN, PROVIDE THE SOLE AND EXCLUSIVE REMEDY ARISING FROM THE SALE. CUB CADET LLC SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL LOSS OR DAMAGES INCLUDING, WITHOUT LIMITATION, FOR TRANSPORTATION OR FOR RELATED EXPENSES, OR FOR RENTAL EXPENSES TO TEMPORARILY REPLACE A WARRANTED PRODUCT. (SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU.)
3. IN NO EVENT SHALL RECOVERY OF ANY KIND BE GREATER THAN THE AMOUNT OF THE PURCHASE PRICE OF THE PRODUCT SOLD. ALTERATION OF THE SAFETY FEATURES OF THE PRODUCT SHALL VOID THIS LIMITED WARRANTY. YOU ASSUME THE RISK AND LIABILITY FOR LOSS, DAMAGE, OR INJURY TO YOU AND YOUR PROPERTY, AND/OR TO OTHERS AND THEIR PROPERTY, ARISING OUT OF THE USE OR MISUSE OR INABILITY TO USE THE PRODUCT.
4. This limited warranty extends to the Initial Purchaser only and, except as otherwise stated herein, the applicable Warranty Period will begin on the original date of purchase of the Product. In the event that the original date of purchase of the Product is indeterminable, then the Warranty Period shall be established as beginning on the Product’s date of manufacture, as determined by Cub Cadet LLC, and ending six (6) months after the applicable Product Warranty Period, as defined above. In no event shall a Product’s warranty extend beyond the applicable Warranty Period.

How State Law Relates to This Warranty
This limited warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.

100016 Rev J (October 13, 2021)
