Jmtek Wpc680 Wireless Charger Instruction Manual

WPC680 Wireless Charger

Product Information: 160mm Wireless Charger

The 160mm Wireless Charger is a compact and portable device that
allows for wireless charging of Qi-compatible devices. It comes
with a USB-C to USB-C fast charging cable and a user manual for
easy setup and usage. The charger has an input of DC 5V,2A/ DC
9V,2A and an output of 15W Max. It has a charging distance of 6mm
and can charge smartphones with non-metal protective case or
silicone cover that are no thicker than 6mm. The charger works with
all Qi-compatible devices, but for fast wireless charging mode, use
the QC or PD adapter and compatible smartphones.

Package Content:

• Wireless Charger
• USB-C to USB-C fast charging cable
• User Manual

Specifications:

• Input: DC 5V,2A/ DC 9V,2A
• Output: 15W Max
• Charging Distance: 6mm

General Information:

• This charger works with all Qi-compatible devices (please make
  sure your device is Qi-compatible)
• For normal operation, no weaker than DC 5V,2A adapter is
  required.
• For fast wireless charging mode, use the QC or PD adapter and
  compatible smartphones.
• This wireless charger can charge smartphones with non-metal
  protective case or silicone cover that are no thicker than
  6mm.

Product Usage Instructions

1. Connect the USB cable (included) to a power outlet rated at DC
   5V/2A or 9V/2A.
2. Connect the Type-C plug to the Type-C input of the wireless
   charger. The red LED light will light up.
3. Place your Qi compatible phone with inductive (wireless) charge
   feature onto the charger (back of phone to charger).
4. Wireless charging of the phone will start immediately and the
   blue/white LED lights will be illuminated.
5. Note: Only devices which support Qi wireless charge technology
   can be wirelessly charged from this charger. If your phone is
   compatible with wireless charging and you are unable to charge it
   wirelessly, please remove your phone case and retry.

Caution:

• Do not drop, disassemble or modify this product.
• Do not expose this product to fire or excessive heat.
• Do not expose this product to water or excessive humidity.
• Do not put any bare metal on the surface area of the wireless
  charger when it is operating.

FCC Statement:

This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
   interference that may cause undesired operation.

Warning:

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

Note:

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency. Increase
the separation between the equipment and receiver. Connect the
equipment into an outlet on a circuit different from that to which
the receiver is connected. Consult the dealer or an experienced
radio/TV technician for help.

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator & your body.

160mm

Wireless Charger Instruction Manual
Please read the following carefully before using the device to ensure safe and proper use.
Package Content
. Wireless Charger . USB-C to USB-C fast charging cable . User Manual
Specif ications
. Input: DC 5V,2A/ DC 9V,2A . Output: 15W Max . Charging Distance6mm
General information

. This charger works with all Qi-compatible devices (please make sure your device is Qi-compatible)
. For normal operation, no weaker than DC 5V, 2A adapter is required. . For fast wireless charging mode, use the QC or PD adapter and
compatible smartphones. . This wireless charger can charge smartphones with non-metal protective
case or silicone cover that are no thicker than 6mm.
Instructions
Connect the USB cable(included) to a power outlet rated at DC 5V/2A or 9V/2A, the Type-C plug to the Type-C input of the wireless charger, the red LED light will light up.
Place your Qi compatible phone with inductive (wireless) charge feature onto the charger (back of phone to charger), then wireless charging of the phone will start immediately and the blue/white LED lights will be illuminated.
Note-only devices which support Qi wireless charge technology can be wirelessly charged from this charger,if your phone is compatible with wireless charging and you are unable to charge it wirelessly, please remove your phone case and retry.
Caution: Do not drop, disassemble or modify this product. Do not expose this product to fire or excessive heat. Do not expose this product to water or excessive humidity. Do not put any bare metal on the surface area of the wireless charger when it is operating.

90mm

FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Warning:Changes or modifications not expressly approved
by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE:This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver . Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
