Better Bathrooms Arimb018 Black Click Clack Slotted Basin Waste User Manual (+ PDF)

Congratulations on your purchase! And welcome
to our growing gang of savvy shoppers. We’re on a mission to bring
you extraordinary bathroom products, for less. From modern to
traditional style ceramics, plus the gorgeous fixtures, fittings,
and furniture to match. So, you can fall in love with your space
every single day.

As one of the UK’s largest independent bathroom stores, we’ve
received countless awards; including the National Business Awards
UK, the Digital Entrepreneur Awards, and being placed on The Sunday
Times Fast Track 100.

We hope your new product goes above and beyond your
expectations. However, should any problems occur, please contact us
via betterbathrooms.com/content/contact-us.

Important Information:

Please read these instructions thoroughly and retain for future
reference. Installation must be carried out in compliance with The
Water Fittings Regulations and Scottish Water Byelaws. The system
must be flushed prior to installation, else it might clog the
filter and the parts.

Parts / Diagrams Dimensions:

No	Part Description
1	Clicker dome
2	O-ring
3	Piston kit
4	Drain body
5	Rubber Washer
6	Rubber Washer
7	Plastic gasket
8	Locknut

Tools required:

Seal tape
Spanner

Installation – Slotted/Unslotted Basin Waste:

Note: Silicone sealant can be used.

Unscrew the locknut(4) and remove the plastic gasket(3) and
rubber washer(2).
Insert the drain body(1) from above the basin.
For the slotted basin waste, make sure the slot lines up with
the overflow on the basin.
Install the rubber washer(2), plastic gasket(3), and tighten
with locknut(4).
To fill the basin, the Clicker mechanism requires pressing down
the clicker dome(1) and pressing it again to release the
water.
Check all the joints for leaks.

Troubleshooting:

Issues	Check
Loose of drain body	Is locknut(8) fully tightened?
Water leak	Is the clicker dome(1) fully tightened? Is there damage or dirt with the o-ring(2)? Is there damage or dirt with the rubber washers(5 or 6)?

Maintenance and Cleaning:

To maintain the surface of your product, wipe with a clean damp
cloth and wipe dry. Do not use any abrasive cleaning agents or
materials. If any harsh chemicals come into contact with the
surface of the product, rinse and wipe clean immediately.

View Fullscreen

Product
ARIMB018 – Matt Black Slotted Sprung Basin Waste ARIBB020 – Brushed Brass Slotted Basin Waste CHSBW001 – Chrome Slotted Basin Waste ARIMW005 – Matt White Slotted Basin Waste ARIVRG005 – Vapour Rose Gold Slotted Basin Waste ARIMB019 – Matt Black Unslotted Sprung Basin Waste ARIBB021 – Brushed Brass Unslotted Basin Waste CHUBW001 – Chrome Unslotted Basin Waste ARIMW006 – Matt White Unslotted Basin Waste ARIVRG006 – Vapour Rose Gold Unslotted Basin Waste
Single-person assembly We always recommend using professional
tradespeople to install your product
V2_3/9/2022

Congratulations on your purchase
And welcome to our growing gang of savvy shoppers
We’re on a mission to bring you extraordinary bathroom products, for less. From modern to traditional style ceramics, plus the gorgeous fixtures, fittings and furniture to match. So, you can fall in love with your space every single day.
As one of the UK’s largest independent bathroom stores, we’ve received countless awards; including the National Business Awards UK, the Digital Entrepreneur Awards and being placed on The Sunday Times Fast Track 100.
We hope your new product goes above and beyond your expectations. However, should any problems occur, please:
log in to your account and contact our customer services team via your self-serve portal betterbathrooms.com/CustomerAccount/Login
contact us via betterbathrooms.com/content/contact-us
Important information
Please read these instructions thoroughly and retain for future reference Installation must be carried out in compliance with The Water Fittings Regulations
and Scottish Water Byelaws. The system must be flushed prior to installation, else it might clog the filter and the
following phenomenon occurs: discharged water volume is small, or temperture cannot be controlled well. Pressures must be equal for optimum performance Please do not connect hot and cold water supply lines in reverse. This could result in hot water flowing from cold line and cause scalding. The feed-water temperature of water shall not exceed 85°C. Exceeding 85°may cause scalding, the service life of faucets might be shortened, or the faucet might be damaged. After installation, please make sure the faucet is securely mounted and checked for leaks.

Parts / Diagrams Dimensions

Part Description

Clicker dome

O-ring

Piston kit

Drain body

Rubber Washer

Plastic gasket

Locknut

Tools required
Seal tape Spanner

Installation

Slotted/Unslotted Basin Waste
Note: Silicone sealant can be used. Unscrew the locknut(4) , and remove the plastic
gasketr(3) and rubber washer(2). Insert the drain body(1) from above the basin.
For the slotted basin waste, make sure the slot lines up with the overlfow on the basin. Install the rubber washer(2), plastic gasket(3) and tighten with locknut(4)). To fill the basin, the Clicker mechanisam requires pressing down the clicker dome, and pressing it again to release the water. Check all the joints for leaks.

Troubleshooting
Issues
Loose of drain body
Water leak

Check
Is locknut(8) fully tighten Is the clicker dome(1) fully tighten
Is there damage or dirt with the o-ring(2) Is there damage or dirt with the rubber
washers(5 or 6)

Maintenance and Cleaning
To maintain the surface of your product, wipe with a clean damp cloth and wipe dry, do not use any abrasive cleaning agents or materials. If any harsh chemicals come into contact with the surface of the product, rinse and wipe clean immediately.
