120V 50/60hz Dryer
Product Information:
The Swimsuit Dryer is a device designed to quickly remove water
from swimsuits, increasing user satisfaction with pool experiences.
It also serves as a low-cost maintenance solution for the
purchaser. The dryer should only be used to dry swimsuits and is
not intended for any other purpose.
Proper Usage and Liability:
It is important to follow the instructions provided to ensure
proper usage of the Swimsuit Dryer. Neither The Swimsuit Dryer
Company, the purchaser, nor the facility where the dryer is
installed will be liable for any damages to swimming costumes
resulting from improper usage. The appliance should not be used by
individuals with reduced physical, sensory, or mental capabilities,
unless they have been provided with supervision or instruction.
Identification & Certification:
For information regarding the Swimsuit Dryer’s serial number,
voltage and frequency, manufacturing date, and certification,
please refer to the label located on the bottom right-hand side of
the device.
Product Usage Instructions:
Items Supplied with the Swimsuit Dryer:
- Shipping Box and Packaging
- Securing Bracket
- User Manual
- Fixing Screws
- T30 Screwdriver
- Mounting Bracket
- Swimsuit Dryer Cleaning Brush
- Cleaning Towel & Cleaner
Location and Pre-Installation:
Before installing the Swimsuit Dryer, it is recommended to
consider the following:
- Choose a suitable location for installation.
- Ensure the transit bar underneath the dryer is removed.
Transit Bar:
It is crucial to remove the transit bar located underneath the
Swimsuit Dryer before use.
User Manual
120v 50/60hz models
(Metric Measurements)
Table of Contents
1 PURPOSE ……………………………………………………………………………………………………………………………………….3 1.1 PROPER USAGE AND LIABILITY………………………………………………………………………………………………………3 1.2 IDENTIFICATION & CERTIFICATION……………………………………………………………………………………………….3
2 THE SWIMSUIT DRYER INFORMATION ………………………………………………………………………………4 2.1 WHERE WOULD YOU EXPECT TO FIND THE SWIMSUIT DRYER ……………………………………………………….4 2.2 ITEMS SUPPLIED WITH THE SWIMSUIT DRYER ………………………………………………………………………………4 2.3 LOCATION AND PRE-INSTALLATION………………………………………………………………………………………………4
3 TRANSIT BAR ……………………………………………………………………………………………………………………………….5
1 WALL MOUNTED INSTALLATION (WALL & COUNTER TOP MODELS) ……………………….6 1.1 SECURE THE WALL PLATE …………………………………………………………………………………………………………….6 1.2 WALL MOUNTED MODEL INSTALLATION DIAGRAM ……………………………………………………………………..7 1.3 COUNTER-TOP MODEL WALL INSTALLATION DIAGRAM ………………………………………………………………8
2 COUNTER-TOP INSTALLATION ………………………………………………………………………………………………9 2.1 SURFACE PREPARATION ……………………………………………………………………………………………………………….9 2.2 COUNTER-TOP MODEL COUNTER-TOP……………………………………………………………………………………..10 2.3 CONNECTING THE SWIMSUIT DRYER TO A WASTE OUTLET ……………………………………………………………11
3 ELECTRICAL CONNECTION…………………………………………………………………………………………………….12 3.1 RECEPTABLE/ ELECTRICAL SOCKET …………………………………………………………………………………………….12 3.2 HARD WIRED …………………………………………………………………………………………………………………………….12
4 MAINTENANCE & CLEANING …………………………………………………………………………………………………13 4.1 CLEANING REQUIREMENTS …………………………………………………………………………………………………………13 4.2 CLEANING INSTRUCTIONS…………………………………………………………………………………………………………..13 4.3 WEEKLY CLEANING REQUIREMENTS…………………………………………………………………………………………….13 4.4 MONTHLY CLEANING REQUIREMENTS ………………………………………………………………………………………….14
5 MALFUNCTIONS/ TROUBLESHOOTING GUIDE……………………………………………………………….15 5.1 LEAKING ……………………………………………………………………………………………………………………………………15 5.2 OPERATIONAL MALFUNCTIONS ……………………………………………………………………………………………………15 5.3 WARRANTIES AND GUARANTEES …………………………………………………………………………………………………15
6 TECHNICAL SPECIFICATIONS ………………………………………………………………………………………………16
2
1 Purpose
The purpose of the Swimsuit Dryer is to give the user the facility to remove water from their Swimsuits quickly, thus increasing their satisfaction with the pool experience, encouraging the user to continue to use the pool, sauna, steam room and other wet facilities offered. The Swimsuit Dryer has been designed, not only to increase the user’s satisfaction, but to also offer a low-cost maintenance solution for the purchaser.
1.1 Proper usage and liability The Swimsuit Dryer is intended to dry Swimsuits ONLY, neither The Swimsuit Dryer Company, the purchaser, nor the facility where the Swimsuit Dryer is installed will not be liable or take responsibility for any damages to swimming costumes where the user has not properly followed the instructions given.
The appliance is not to be used by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have 0been given supervision or instruction
1.2 Identification & Certification Please see the label located on the bottom right-hand side of The Swimsuit Dryer for the following Information:
– Serial Number – Voltage and Frequency – Manufactured Date – Certification.
2 The Swimsuit Dryer Information
2.1 Where Would You Expect to Find the Swimsuit Dryer
The Facilities that a user could expect to find The Swimsuit Dryer installed in are: Health Clubs · Gyms · Public Swimming Pools · Hotels with Leisure Facilities · Spas · Holiday Resorts · Universities · Wellness Centers · Recreation Centers · Cruise Liners · Any Commercial Property with a pool or wet area. available and suitable for private use.
2.2 Items Supplied with the Swimsuit Dryer
The Swimsuit Dryer will be supplied with the following items. The items listed below
must be kept should the unit experience a fault in or out of warranty, and to carry out
any necessary maintenance.
Shipping Box and Packaging
Securing Bracket
User Manual
Fixing Screws
T30 Screwdriver
Mounting Bracket
Swimsuit Dryer Cleaning Brush
Cleaning Towel & Cleaner
2.3 Location and Pre-Installation.
We recommended all Next Generation Swimsuit Dryers are Installed:
· In a changing/Locker room, outside a changing/Locker room, in a corridor, or in an area where facility users have access, a dry or semi wet area, and a location where the wastewater can be removed.
The Swimsuit Dryer Must NOT be installed by anyone in any of the following locations: · Any location where local laws and regulations do not permit mains equipment to be installed.
4
3 TRANSIT BAR
MAKE SURE YOU REMOVE THE TRANSIT BAR FROM UNDERNEATH THE SWIMSUIT DRYER!
If the Transit Bar is not removed from underneath the Swimsuit Dryer, it will not work.
1 Wall Mounted Installation (Wall & Counter Top Models)
1.1 Secure the Wall Plate
· Please ensure the wall can support approximately 30kg/ 66lbs of weight. · Place the wall mount on the wall and ensure the top is 1 meter from the floor,
check with a spirit level to ensure the Mounting bracket is level. Mark your locating holes and drill the holes, insert wall fixings, then use the mounting screws to secure the bracket to the wall. After securing the mounting bracket to the wall ensure it is level and fastened to the
wall securely! · Place the Swimsuit Dryer onto the mounting bracket and connect it to the power
and drainage.
6
1.2 Wall Mounted Model Installation Diagram
1.3 Counter-Top Model Wall Installation Diagram
8
2 Counter-Top Installation
2.1 Surface Preparation
· Please ensure the countertop or tabletop can support approximately 30kg/ 66lbs of weight.
· Measure your surface using the dimensions shown on the installation diagram and cut this out.
· Place the Swimsuit Dryer into the hole and connect it to the power and drainage.
2.2 Counter-Top Model Counter-Top
10
2.3 Connecting the Swimsuit Dryer to a waste outlet
If you have not purchased our built-in water tank, the Swimsuit Dryer will need to be connected to you waste water outlet. This can be done by a professional tradesman. Simply connect the waste outlet to your external plumbing.
Example of Swimsuit Dryer plumbed into the wall.
Ensure there is sufficient ventilation underneath the unit.
3 Electrical Connection
Please consult with a qualified electrician and ensure he complies with the local regulations.
3.1 Receptable/ Electrical Socket
If you are in the USA, UK, EU, or country that has the same connections you can order your Swimsuit Dryer with a plug. Simply plug the Swimsuit Dryer in and you are ready to use.
** Weatherproof electrical enclosures must comply to all local Electrical Regulations.
3.2 Hard Wired
If you need to hard wire your Swimsuit Dryer into a Fused Socket or Receptable please contact a qualified electrician.
Representative images ONLY
12
4 Maintenance & Cleaning
The Swimsuit Dryer has been manufactured to be maintenance FREE.
4.1 Cleaning Requirements
Your Swimsuit Dryer should be cleaned weekly, or as required. Equipment Required:
· Cleaner and Disinfectant · Hand Towel · Screwdriver
DO NOT pour large amounts of water or cleaning solution directly into the Swimsuit Dryer.
4.2 Cleaning Instructions
To keep your Swimsuit Dryer clean and sanitized, we recommend you use a general disinfectant.
4.3 Weekly Cleaning Requirements
Step 1 Spray the outer body of the Swimsuit Dryer with the disinfectant and wipe it down with the cleaning towel.
4.4 Monthly Cleaning Requirements Step 1
– Lift the lid and remove the Top Cover. – Spray the cleaner inside the drum/ basket and down between the drum and liner. Step 2 – Re-fit the top ring cover making sure to tighten the security screws. – Operate the dryer for 10 seconds to remove any cleaner from inside the drum.
14
5 Malfunctions/ Troubleshooting Guide
5.1 Leaking
If the Swimsuit Dryer is leaking from the bottom of the unit, please resolve this immediately to prevent any damage to the motor:
· Remove the Top Cover, check and remove any blockages.
If your Swimsuit Dryer is still leaking check your external waste connection or contact us.
5.1 Service Life
To ensure continued reliability and safety we recommend the equipment is serviced is serviced at least every 5 years.
5.2 Operational Malfunctions
The Swimsuit Dryer has been designed and manufactured to be an exceptionally reliable and durable machine. Should the product malfunction, please contact us. [email protected], [email protected], [email protected],
5.3 Warranties and Guarantees
All Swimsuit Dryers are covered by our GLOBAL GUARANTEE protection warranty. This Guarantees you a minimum of 1-year Global warranty for all Factory refurbished Dryers and 2 years for all New Swimsuit Dryer. For full terms visit: www.swimsuitdryer.global.
6 Technical Specifications
Weight: Energy: Safety Details:
Voltage:
20kg / 44lbs free standing 25kg / 55lbs fully boxed
Standby: approximately 3 watts Per hour Running: approximately 0.97 watts per cycle.
5 Year Service Life GFI Installed Low Voltage LEDs Overload Protected Safety Brake
PAT Tested PTO Installed IP65 Enclosures IP54 Brake Motor UL 94
110-120 Volt 50/60 Hz local supply
Mounting: Waste Hose:
Basket Volume: Waste Outlet: Noise Emission: Warranty (FULL):
Extended warranty:
Wall Mounted or Counter-Top
60cm from the unit 23.62″ from the unit Custom Length Available
2 litres
Connects directly to waste outlet: 32mm / 1 1/4 Hose Internal Diameter 28.0mm / 1.10″ Hose Outside Diameter 33.5mm / 1.31″
Approximately 50 60dB when used correctly
2 Year Global Guarantee New 1 Year Global Guarantee Factory Refurbished ** Inclusive of shipping, parts, and labor.
3 Year Motor and Brake
16
