Tissue Culture Flasks with Peel-off Foil
Product Information
The TPP Tissue Culture Flasks with Peel-off Foil are designed
for cell culture with sterile handling techniques, storage, and
microscopy. These flasks have an optomechanically activated growth
surface to optimize cell adhesion and proliferation. The angled
flask neck helps reduce the risk of medium contact with the inside
of the screw cap.
These flasks are available with filter screw caps only. It is
important to note that using a VENT screw cap may cause pressure
build-up, which could press open the peel-off foil.
The TPP Tissue Culture Flasks with Peel-off Foil are intended
for single-use only. It is recommended to follow national
regulations for handling biological material and use appropriate
protective clothing.
Product Usage Instructions
- Check the packaging material and the product for intactness.
Use only faultless packaging. - Open the packaging in a sterile environment and remove a
complete system for use. - Open the filter screw cap of the cell culture flask.
- Fill the flask with medium and inoculum according to your
standard laboratory routine. - Resuspend the cells well with the medium to avoid cell
lumps. - Avoid foaming during resuspension and seeding to prevent holes
in the cell layer. - Ensure an appropriate medium volume to avoid meniscus formation
and uneven growth of cells. Refer to the technical data for the
optimum filling volume. - If stacking multiple flasks in an incubator, air vents in the
bottom rim ensure optimum heat distribution. - When centrifuging the flasks, consider factors such as shape,
material, accuracy of fit in the centrifuge adapter, temperature,
centrifugation time, and g-number to maintain mechanical
strength.
Please note that TPP products are for research use only and not
intended for use in clinical, diagnostic, or therapeutic
procedures. TPP does not assume any guarantee for damages and
defects resulting from unregistered or improper use. These
instructions should be considered as guidelines, and TPP accepts no
responsibility for the topicality, accuracy, completeness, or
quality of this information.
Instruções de uso Frasco de cultura celular com
película removível TPP
Instructions for Use TPP Tissue Culture Flasks with
Peel-off Foil
Os frascos de cultura celular TPP com película removível são projetados para o cultivo e crescimento de células com um único acesso a partir do topo. Somente o fundo do frasco é opto-mecanicamente ativado para uma ótima aderência e crescimento celular. O gargalo angular da garrafa reduz o risco de contato médio com o interior da tampa rosqueável com filtro por derramamento.
Estes frascos de cultura celular TPP estão disponíveis apenas com tampa rosqueável com filtro. Ao utilizar uma tampa rosqueável com VENT, uma possível acumulação de pressão de 0,03 bar ou superior poderia pressionar a película removível. O frasco de cultura celular TPP com película removível é destinado a uso único.
TPP tissue culture flasks with peel-off foil are designed for cell culture with necessary sterile handling techniques, storage and microscopy in manual use and to meet the need for a large one-time access from the above to the cell culture. The growth surface is optomechanically activated to optimize cell adhesion and proliferation. The angled flask neck reduces the risk of medium contact with the inside of the screw cap.
TPP cell culture flasks with peel-off foil are available with filter screw caps only, when using a VENT screw cap a possible pressure build-up of 0.03 bar or higher could press open the peel-off foil.
The TPP tissue culture flask with peel-off foil is intended for single use only.
Dica:
Note:
Observar as regulamentações nacionais para o manuseio de material biológico, usar a roupa de proteção apropriada.
Follow national regulations when handling biological material, use appropriate protective clothing
Observar as regras do trabalho asséptico em todas as etapas.
Take note of the regulations of aseptic working during the work process.
Instruções:
Instructions:
Verificar o material de embalagem e o
Check the packaging material and the
produto quanto a danos. Usar somente
product for intactness. Use only faultless
material em perfeitas condições.
material.
Verificar a data de validade (EXP) no rótulo e Check the expiry date (EXP) on the label and
na embalagem. Utilizar somente produtos
packaging. Only use products with valid EXP
com EXP válido.
Open the packaging in a sterile environment
Abra a embalagem em um ambiente estéril
and remove a complete system for use.
e remova um sistema completo para uso. Open the filter screw cap of the cell culture
Abra a tampa rosqueável com filtro do
flask and fill the flask with medium and
frasco de cultura celular e encha o frasco
inoculum according to your standard
com meio e inóculo de acordo com a rotina
laboratory routine.
normal do laboratório.
Source: TPP/literature
1 / 4
Version 01_2022
Note: TPP products are for research use only and not intended for use in clinical, diagnostic or therapeutic procedures. TPP does not assume any guarantee for damages and defects resulting from unregistered or improper use.
TPP recommendations are guidelines and do not represent an absolute value. TPP accepts no responsibility for the topicality, accuracy, completeness or quality of this IFU.
Feche completamente a tampa rosqueável Close the filter screw cap completely. A
com filtro. A membrana filtrante PTFE
continuous gas exchange takes place
hidrofóbica integrada 0,22 µm garante a
through the integrated hydrophobic
troca contínua de gás. Se a membrana ficar
membrane 0.22 µm. If the PTFE filter
molhada, a troca de gás é reduzida por um
membrane gets wet, the gas exchange is
curto período.
reduced for a short time.
Cultivar e colher as células de acordo com a Cultivate and harvest cells according to your
rotina laboratorial habitual.
common laboratory routine.
Para obter um crescimento uniforme na
superfície, os seguintes aspectos devem ser To achieve an uniform cell growth, the
observados:
following aspects must be observed:
o Resuspender bem as células com o meio
o Resuspend the cells well with the
para evitar grumos de células.
medium to avoid cell lumps.
o Evitar a formação de espuma durante a
o Avoid foaming during resuspension and
resuspensão e a semeadura para obter
seeding to avoid holes in the cell layer.
uma superfície uniforme de células.
o Low medium volume leads to meniscus
o O baixo volume médio leva à formação
formation and thus to uneven growth of
de menisco e, portanto, ao crescimento
the cells (cell clumps at the edge). Please
desigual das células (tufos de células nas
refer to the technical data for the
bordas). Consulte os dados técnicos para
optimum filling volume.
obter o volume ideal de enchimento. Air vents in the bottom rim ensure optimum
As aberturas de ar na borda da base
heat distribution in the incubator when
garantem uma ótima distribuição de calor
several flasks are stacked on top of each
na incubadora quando várias garrafas são
other.
empilhadas umas sobre as outras.
The mechanical strength of the flasks during
A capacidade de carga mecânica das
centrifugation is influenced by
garrafas durante a centrifugação é
o Shape and material
influenciada por:
o Accuracy of fit in the centrifuge adapter
o Formato e material
o Temperature, centrifugation time,
o Precisão de ajuste no adaptador da
g-number
centrífuga
o Chemical and physical properties of the
o Temperatura, tempo de centrifugação,
centrifuged material
força g
o Rotor type: fixed-angle or swing-out
o Propriedades químicas e físicas do
rotor
material centrifugado
Test the multitude of influencing factors
o Tipo de rotor: rotor de ângulo fixo ou
under routine conditions beforehand.
rotor basculante
Storage before use at room temperature,
Primeiro teste a multiplicidade de fatores de protect from UV light.
influência sob condições de rotina.
Armazenar à temperatura ambiente antes
de usar, proteger da luz UV.
Source: TPP/literature
2 / 4
Version 01_2022
Note: TPP products are for research use only and not intended for use in clinical, diagnostic or therapeutic procedures. TPP does not assume any guarantee for damages and defects resulting from unregistered or improper use.
TPP recommendations are guidelines and do not represent an absolute value. TPP accepts no responsibility for the topicality, accuracy, completeness or quality of this IFU.
Retirar a película removível:
Peel-off the Peel-Off Foil:
A colheita das células pode ser feita de cima The cell harvest from chamber can be
para baixo através da película removível.
carried out from above when the peel-off foil
Posicione o polegar e o localizador central
is removed.
nos campos de etiquetagem da garrafa T. Position thumb and middle finger on the
Estabilize a garrafa com seu dedo indicador,
inscription fields on both sides of the neck of
colocando-a sob a aba da película removível
the T-flask. Use your index finger to press
e pressionando a garrafa sobre a superfície.
the flask onto the surface by placing the
Segure a aba da película com sua outra mão
fingertip underneath the foil flab, thus
e puxe a aba para trás com um leve puxão.
stabilizing the flask. Grab the foil flap with
Não é possível fechar novamente a película
the other hand and pull the foil back with a
removível.
gentle pull.
It is not possible to reclose the foil.
Comentários e recomendações:
Advice and Recommendations:
Há campos de rotulagem em ambos os lados For labelling there are inscription fields on
para marcação.
both sides of the flask.
A graduação serve como uma indicação da The graduation serves as a reference for the
quantidade de enchimento e não é um valor
filling quantity and is not an absolute value.
absoluto.
The stacking rim allows a stable stacking of
O aro de empilhamento permite uma
several flasks on top of each other, also in
estabilidade segura de várias garrafas
combination with other TPP flasks of the
empilhadas umas sobre as outras, também
same size.
em combinação com outros frascos de
For a homogenous cultivation of the cells,
cultura de células TPP do mesmo tamanho.
levelling of the incubator and continuous
Para o cultivo uniforme das células, é
supply of medium is essential.
essencial o nivelamento da base e o
Avoid and/or eliminate vibration sources
fornecimento regular do meio nutriente.
near the incubator to ensure uniform cell
Evite fontes de vibração perto da
growth
incubadora para garantir o crescimento
uniforme das células.
Nota: A barreira limita a área de crescimento a 115 cm2.
Note: The barrier limits the growth area to 115 cm2.
Source: TPP/literature
3 / 4
Version 01_2022
Note: TPP products are for research use only and not intended for use in clinical, diagnostic or therapeutic procedures. TPP does not assume any guarantee for damages and defects resulting from unregistered or improper use.
TPP recommendations are guidelines and do not represent an absolute value. TPP accepts no responsibility for the topicality, accuracy, completeness or quality of this IFU.
Dados técnicos:
Materiais Frasco Tampa rosqueável Membrana
Película
PS PE PTFE tamanho dos poros 0.22 µm Sem toxinas
Technical Data:
Materials Flask Screw cap Membrane
Foil
PS PE PTFE pore size 0.22 µm
toxin-free foil
Dimensões Película removível Barreira Comprimento mm Largura mm Altura mm Área de crescimento cm2 Volume Recom. mL Abertura mm Volume máximo mL
Measurement Peel-off foil Barrier Length mm Width mm Heights mm Growth area cm2
Recom. volume mL Opening mm Max volume mL
90028 –92 51 31
25
3 8 38 x 45
15
90078 –155 87 45
75
8 22 87 x 92
65
90153 –210 122 50
150
15 45 100 x 128
100
90303 –275 170 55
300
30 – 85 140 x 185
200
90653 210 122 50
115
15 33 100 x 128
100
Adicional:
Additional:
Instruções de uso, listas de resistência química, certificados de qualidade dos respectivos produtos estão disponíveis para download na homepage www.tpp.ch.
Instructions for use, chemical resistance lists, and quality certificates of the respective products are available for download on the homepage www.tpp.ch .
Source: TPP/literature
4 / 4
Version 01_2022
Note: TPP products are for research use only and not intended for use in clinical, diagnostic or therapeutic procedures. TPP does not assume any guarantee for damages and defects resulting from unregistered or improper use.
TPP recommendations are guidelines and do not represent an absolute value. TPP accepts no responsibility for the topicality, accuracy, completeness or quality of this IFU.
