Xo Appliance Xogsbcartxlt Performance Grill Carts Instruction Manual

XOGSBCARTXLT Performance Grill Carts

Product Information: XO Performance Side Burner Cart

The XO Performance Side Burner Cart is a grill cart designed for
outdoor use. It is compatible with the XO Performance Grill model
XOGSBCARTXLT. The cart is pre-assembled at the factory, but some
assembly is required to attach the handles and casters and mount
the unit to the side of the grill cart. The cart is equipped with
handles, casters, locking casters, gas connection wye, electrical
connector, and necessary hardware.

Warning:

This product is heavy. Please read and follow all safety
instructions and warnings provided in the instruction manual before
assembling and using the appliance. The appliance is designed for
outdoor use only and should not be operated in any enclosed space.
Failure to follow safety instructions may result in property
damage, injury, or death.

Unpacking:

Refer to the next pages of the instruction manual for unpacking
instructions.

Tools Supplied or Needed:

• 1 x #2 Phillips head screwdriver
• 1 x Box Cutter

Spare Parts List:

Product Usage Instructions:

Assembly Instructions:

1. The primary cart cabinet is pre-assembled. To attach the
   handles and casters, remove the M5x10 bolts from the interior of
   the burner into the side walls of the cart. Lift the side burner up
   and out from the cart.
2. Lay the empty cart on its back and use the cardboard packaging
   as a working surface to prevent scratching. Attach the casters to
   each corner of the base using (16) M6x12 bolts (4 per caster).
   Install the locking casters on the right-hand side and the
   non-locking casters on the left-hand side.
3. Attach the handle assemblies to the lid and door using M6x60
   bolts.
4. Remove the right side shelf brackets and screw them into the
   right side panel and base using 6 M5x10 bolts.
5. Slide the side burner cart to the main cart, allowing the
   screws on the top and bottom to slide over the M5x10 bolts. Tighten
   them with the supplied screwdriver.
6. Reinstall the side burner into the cart using the removed M5x10
   bolts.

If You Smell Gas:

DANGER: If you smell gas, follow the instructions below:

1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open the lid.
4. If the odor continues, keep away from the appliance and
   immediately call your gas supplier or fire department.

Leak Testing Instructions:

Refer to the leak testing instructions in the instruction
manual.

Fixing a Gas Leak:

If you detect a gas leak, do not use the grill. Contact a
licensed gas professional to inspect and fix the leak before using
the grill.

Propane Gas Installation:

Note: Place the gas tank under the BBQ and not in the small
cart.

Propane Gas Cylinder Connections:

When not in use, place the dust cap on the cylinder valve outlet
to prevent leakage of propane. Only use the type of dust cap
provided with the cylinder valve.

XO PERFORMANCE SIDE BURNER CART ASSEMBLY INSTRUCTIONS
PERFORMANCE GRILL CARTS
MODEL: XOGSBCARTXLT
Warning: Heavy Weight Hazard!
ATTENTION:
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE. PLEASE READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS THAT ACCOMPANY BOTH THIS CART AND THE GRILL BEFORE ASSEMBLING AND USING THE APPLIANCE. THIS PRODUCT IS DESIGNED FOR OUTDOOR USE ONLY. DO NOT OPERATE IN ANY ENCLOSED SPACE. FAILURE TO FOLLOW ALL SAFETY INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, INJURY OR DEATH.

Unpacking
· · Remove all cardboard, foam packaging material and nylon bags. · Dispose / recycle all packaging materials. · Verify all the contents in the box and gather the required tools. See “Tools Needed” in the list on
next pages.

Tools Supplied or needed

1 x #2 Phillips head screwdriver

1 x Box Cutter

2

1 2

6 8

4

53

7 9

10

11
Spare Parts List

No. Part Number
1. XOPG64974 2. XOPG64975 3. XOPG64978 4. XOPG64976 5. XOPG64980 6. 7. XOPG64977 8. XOPG64979 9. XOPG64980 10. XOPG64995 11. XOPG64996 12. XOPG64997 13. XOPG64981

Handle
/ Base Casters Non-Locking
as

12
Description

3

13
Qty 2 1 1 1
1 1 1 1 2 1

What Comes In The Box

Handles (2 PCS)
SIDE BURNER CART ASSEMBLY
Hardware
(6 PCS)

Casters (2 PCS)

Locking Casters (2 PCS)

Gas Connection Wye (1 PC)
Electrical Connector Not Shown (1 PC)

Screwdriver (1PC)

4

ssembly Instructions
The primary cart cabinet is pre-assembled at the factory. You will still need to do some assembly to attach the handles and casters in addition to mounting the unit to the side of the grill cart. grate. You will see an attachment M5x10 bolt on either side that extends out from the interior of the burner into the side walls of the cart. Remove these two bolts. And lift the side burner up and out from the cart.
5

Lay the empty cart on it’s back. Use the cardboard packaging as a working surface to prevent scratching. Using (16) M6x12 bolts (4 per caster) attach the caster to each of the corners of the base as shown. The locking casters must be installed on the right hand side – the non-locking casters must be installed on the left.
Remove the (2) handle assemblies from the bag. Remove the M6x60 bolts and use them to attach one handle to the lid and the other handle to the door as shown.
6

Remove the right side shelf brackets for installation on the Side Burner Cart. Screw into the right side panel and base 6 – M5x10 bolts 2/3 of the way in as shown below. 7

Slide the side burner cart to the main cart and allow the 4 screws on the top and the two screws on the bottom to slide over the M5 x 10 bolts. Once in place tighten them witht he supplied screw driver.
8

Reinstall the side burner into the cart using the removed M5x10 bolts. 9

IF YOU SMELL GAS:

DANGER

Shut off gas to the appliance.

Extinguish any open flame.

Open the lid

.

If odor continues, keep away from the appliance and immediately call your gas

or your fire department.

10

Leak Testing Instructions

Fixing a Gas Leak
· · Turn all grill controls to the “ON” position to purge the grill of any gas build-up, then turn the
controls back “OFF”. · · Tighten the loose joint, or replace the faulty part with manufacturer-recommended replacement
parts. · Repeat the leak test to ensure that no leaks are present. ·
grill inspected by a licensed gas professional Do not use the grill until the leak has been corrected.
Propane Gas Installation

NOTE: Place gas tank under BBQ and NOT IN THE SMALL CART.
Propane gas Cylinder Connections
Dust Cap – Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.

Propane cylinder must include a collar to protect the cylinder valve

Cylinder Valve Coupling Nut

Pressure Relief Valve Valve Protection Collar

Propane Regulator

Propane Tank

(included)

Propane Dust Cap (not included)

(used when in storage

or transportation.)

Figure 1.

11

Figure 2.

Hand tighten to ensure proper

seal for correc

ow.

IMPORTANT
REFER TO YOUR GRILL OPERATING MANUAL FOR INFORMATION REGARDING THE GAS CONNECTION TO YOUR GRILL.
FAILURE TO FOLLOW ALL SAFETY GUIDELINES MAY RESULT IN PROPERTY DAMAGE, INJURY OR DEATH.

XO APPLIANCE | 120 EAGLE ROCK AVE. SUITE 303 | EAST HANOVER, NJ 07936

P. 973.403.8900

WWW.XOAPPLIANCE.COM

12
