EH631BEB6E Induction Hob
Product Information
The Induction hob EH…BE… is a high-quality kitchen appliance
manufactured by Siemens Home Appliances. It is designed to provide
efficient and safe cooking experiences. The hob features advanced
induction technology, which ensures fast and precise heat
distribution for optimal cooking results. The hob is equipped with
various safety features to prevent accidents and protect users from
potential hazards. It also offers a sleek and modern design that
will enhance the aesthetic appeal of any kitchen.
Product Usage Instructions
Safety
It is important to ensure the safe use of the Induction hob.
Follow these guidelines:- Children aged 8 or over and individuals with reduced physical,
sensory, or mental abilities can use the appliance under
supervision or after receiving proper instructions on safe
usage. - Do not allow children to play with the appliance or perform
cleaning or user maintenance unless they are at least 15 years old
and supervised. - Keep children under 8 years old away from the appliance and
power cable. - Avoid touching heating elements, especially the hob surround if
fitted. - Never use hob protective grilles.
- Allow the appliance to cool down before cleaning.
- Do not place metal objects (such as knives, forks, spoons, and
lids) on the hob. - Only trained specialist staff should carry out repairs, using
genuine spare parts.
- Children aged 8 or over and individuals with reduced physical,
Avoiding Material Damage
To prevent material damage while using the Induction hob, follow
these recommendations:- Ensure hotplates and saucepan bases are dry to prevent sudden
movements. - Avoid using icy-cold cookware from the freezer.
- When cooking in a bain marie, ensure the cooking container does
not directly touch the bottom of the water-filled pot. - Use only heat-resistant cookware.
- Do not use the appliance if it has a cracked or broken surface
to avoid cuts. - Keep packaging material and small parts away from children to
prevent suffocation.
- Ensure hotplates and saucepan bases are dry to prevent sudden
By following these product usage instructions, you can enjoy
safe and efficient cooking experiences with the Siemens Induction
hob EH…BE…
Induction hob
EH…BE…
en Information for Use Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome
The future moving in.
Siemens Home Appliances
enSafety
Futher information and explanations are available online:
Table of contents
1 Safety ………………………………………………………….. 2 2 Avoiding material damage…………………………….. 4 3 Environmental protection and saving en-
ergy …………………………………………………………….. 5 4 Suitable cookware………………………………………… 5 5 Familiarising yourself with your appliance …….. 7 6 Basic operation ……………………………………………. 7 7 Time-setting options…………………………………….. 8 8 powerBoost …………………………………………………. 9 9 Childproof lock…………………………………………….. 9 10 Basic settings………………………………………………. 9 11 Cookware test ……………………………………………. 10 12 Cleaning and servicing ……………………………….. 11 13 Troubleshooting…………………………………………. 11 14 Disposal…………………………………………………….. 12 15 Customer Service……………………………………….. 13 16 Test dishes ………………………………………………… 13
1Safety
Observe the following safety instructions. 1.1General information ¡ Read this instruction manual carefully. ¡ Keep the instructions, the appliance pass
and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit.
1.2Intended use Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under the warranty. The appliance can only be used safely if it is correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works perfectly at its installation location. Only use this appliance: ¡ To prepare meals and drinks. ¡ Under supervision. Never leave the appli-
ance unattended when cooking for short periods. ¡ In private households and in enclosed spaces in a domestic environment. ¡ Up to an altitude of max. 4000 m above sea level. Do not use the appliance: ¡ With an external timer or a separate remote control. This does not apply if operation with appliances included in EN 50615 is switched off. If you wear an active implantable medical device (e.g. a pacemaker or defibrillator), check with your doctor that it complies with Council Directive 90/385/EEC of 20th June 1990, EN 45502-2-1 and EN 45502-2-2, and that it has been chosen, implanted and programmed in accordance with VDE-AR-E 2750-10. If these conditions are satisfied, and if, in addition, non-metal cooking utensils and cookware with non-metal handles are used, it is safe to use this induction hob as intended. If these conditions are satisfied, and if, in addition, non-metal cooking utensils and cookware with non-metal handles are used, it is safe to use this induction hob as intended.
1.3Restriction on user group This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge,
2
provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers. Do not let children play with the appliance. Children must not perform cleaning or user maintenance unless they are at least 15 years old and are being supervised. Keep children under the age of 8 years away from the appliance and power cable. 1.4Safe use
WARNING Risk of fire! Leaving fat or oil cooking on an unattended hob can be dangerous and may lead to fires. Never leave hot oil or fat unattended. Never attempt to extinguish a fire using wa-
ter; instead, switch off the appliance and then cover with a lid or a fire blanket. The cooking surface becomes very hot. Never place flammable objects on the cooking surface or in its immediate vicinity. Never place objects on the cooking surface. The appliance will become hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob. Hob covers can cause accidents, for example due to overheating, catching fire or materials shattering. Do not use hob covers. After every use, switch off the hob using the main switch. Do not wait until the hob turns off automatically as there are no longer any pots and pans on it. Food may catch fire. The cooking process must be monitored. A short process must be monitored continuously.
WARNING Risk of burns! The appliance and its parts that can be touched become hot during use, particularly the hob surround, if fitted. Caution should be exercised here in order
to avoid touching heating elements. Young children under 8 years of age must
be kept away from the appliance. Hob protective grilles may cause accidents. Never use hob protective grilles.
Safetyen
The appliance becomes hot during operation. Allow the appliance to cool down before
cleaning. Metal objects on the hob quickly become very hot. Never place metal objects (such as knives,
forks, spoons and lids) on the hob. WARNING Risk of electric shock!
Incorrect repairs are dangerous. Repairs to the appliance should only be
carried out by trained specialist staff. Only use genuine spare parts when repair-
ing the appliance. If the power cord of this appliance is dam-
aged, it must be replaced with a special connection cable, which is available from the manufacturer or his Customer Service. If the appliance or the power cord is damaged, this is dangerous. Never operate a damaged appliance. If the surface is cracked, you must switch off the appliance in order to prevent a possible electrical shock. To do this, switch off the appliance via the fuse in the fuse box rather than at the main switch. Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains. If the appliance or the power cable is damaged, immediately switch off the fuse in the fuse box. Call customer services. Page 13 An ingress of moisture can cause an electric shock. Do not use steam- or high-pressure cleaners to clean the appliance. The insulation on cables of electrical appliances may melt if it touches hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance. If metallic objects come into contact with the fan that is located on the underside of the hob, this may cause an electric shock. Do not store long, pointed metallic objects in the drawers below the hob.
3
enAvoiding material damage
WARNING Risk of injury! Saucepans may suddenly jump due to liquid between the saucepan base and the hotplate. Always keep hotplates and saucepan
bases dry. Never use icy-cold cookware that has been
in the freezer. When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie
must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
An appliance with a cracked or broken surface can cause cuts. Do not use the appliance if it has a cracked
or broken surface. WARNING Risk of suffocation!
Children may put packaging material over their heads or wrap themselves up in it and suffocate. Keep packaging material away from chil-
dren. Do not let children play with packaging ma-
terial. Children may breathe in or swallow small parts, causing them to suffocate. Keep small parts away from children. Do not let children play with small parts.
2 Avoiding material damage
This is where you can find the most common causes of damage and tips on how to avoid them.
Damage Stains Stains, blisters
Stains, blisters or fractures in the glass
Stains, discolouration
Cause Unsupervised cooking process. Spilled food, especially food with a high sugar content. Defective cookware, cookware with melted enamel or cookware with copper or aluminium base. Unsuitable cleaning methods.
Blisters or fractures in Knocks or falling cookware, cooking ac-
the glass
cessories or other hard or pointed objects.
Scratches, discolour- Rough cookware bases or moving the cook-
ation
ware on the hob.
Scratches
Salt, sugar or sand.
Damage to the appli- Cooking with frozen cookware. ance
Damage to the cook- Cooking without contents. ware or the appliance
Glass damage
Melted material on the hot cooking zone or hot pot lid on the glass.
Overheating
Hot cookware on the control panel or on the frame.
Action Monitor the cooking process. Remove immediately with a glass scraper.
Use suitable cookware that is in a good condition.
Only use cleaning agents that are suitable for glass ceramic, and only clean the hob when it is cold. When cooking, do not hit the glass or let objects fall onto the hob. Check the cookware. Lift the cookware when moving it. Do not use the hob as a work surface or storage space. Never use frozen cookware.
Never place or heat empty cookware on a hot cooking zone. Do not place greaseproof paper or aluminium foil nor plastic containers or pot lids on the hob. Never place hot cookware on these areas.
ATTENTION! A fan is located on the underside of this hob. If a drawer is located on the underside of the hob,
do not store any small or pointed objects, paper or tea towels in it. These objects may be sucked in and damage the fan or impair the cooling. There must be a clearance of at least 2 cm between the contents of the drawer and the fan entry point.
4
Environmental protection and saving energyen
3 Environmental protection and saving energy
3.1Disposing of packaging
The packaging materials are environmentally compatible and can be recycled. Sort the individual components by type and dispose
of them separately.
3.2Saving energy
If you follow these instructions, your appliance will use less energy. Select the cooking zone to match the size of your pan. Centre the cookware on the hob. Use cookware whose base diameter is the same diameter as the hotplate. Tip: Cookware manufacturers often give the upper diameter of the saucepan. It is often larger than the base diameter. ¡ Unsuitable cookware or incompletely covered cook-
ing zones consume a lot of energy. Cover saucepans with suitable lids. ¡ Cooking without a lid consumes considerably more
energy.
Lift lids as infrequently as possible. ¡ When you lift the lid, a lot of energy escapes.
Use a glass lid. ¡ You can see into the pan through a glass lid
without having to lift it. Use pots and pans with flat bases. ¡ Uneven bases increase energy consumption.
Use cookware that is suitable for the quantity of food. ¡ Large items of cookware containing little food need
more energy to heat up. Cook with only a little water. ¡ The more water that is contained in the cookware,
the more energy is required to heat it up. Turn down to a lower power level early on. ¡ If you use an ongoing power level that is too high,
you will waste energy. Product Information according (EU) 66/2014 can be found on the attached appliance pass and online on the product page for your appliance.
4 Suitable cookware
Cookware that is suitable for induction cooking must have a ferromagnetic base, i.e. it must be attracted by a magnet. The base must also match the size of the
cooking zone. If cookware is not detected on a cooking zone, place this on the cooking zone with the next smallest diameter.
4.1Size and characteristics of the cookware
To correctly detect the cookware, take the size and the material of the cookware into consideration. All cookware bases must be perfectly flat and smooth. You can use Cookware test to check whether your cookware is suitable. You can find more information about this under “Cookware test”, Page 10.
Cookware Recommended cookware
Suitable
Materials Stainless steel cookware in a sandwich design that distributes the heat well. Ferromagnetic cookware made of enamelled steel, cast iron or special induction cookware made of stainless steel. The base is not fully ferromagnetic.
Cookware bases with aluminium content.
Properties This cookware distributes the heat evenly, heats up quickly, and ensures that it can be detected easily. This cookware heats up quickly and ensures that it can be detected easily.
If the ferromagnetic area is smaller than the base of the cookware, only the area that is ferromagnetic heats up. As a result, the heat is not distributed evenly. These reduce the ferromagnetic area, which means that less power is emitted to the cookware. This cookware may not be sufficiently detected or may not be detected at all, and therefore does not heat sufficiently.
Not suitable
Cookware made from normal thin steel, glass, clay, copper or aluminium.
5
enSuitable cookware Notes ¡ Do not use adapter plates between the hob and the
cookware. ¡ Do not heat up empty cookware and do not use
cookware with a thin base, as this may become very hot.
6
Familiarising yourself with your applianceen
5 Familiarising yourself with your appliance
5.1Cooking with induction
In comparison to conventional hobs, induction technology brings with it a series of changes and has a number of benefits such as time savings when cooking and frying, energy savings as well as greater ease of cleaning and care. It also offers improved heat control as the heat is generated directly in the cookware.
5.2Control panel
Individual details, such as colour and shape, may deviate from the figure.
¡ Do not place any cookware near the indicators or sensors. The electronics may overheat.
5.3Distribution of the cooking zones
The specified power has been measured with the standard pots, which are described in IEC/EN 60335-2-6. The power may vary depending on the size of the cookware or cookware material.
A
B
b
Touch fields
Sensor /
Function Main switch Selecting the cooking zone Selecting settings powerBoost Time-setting options Childproof lock
Displays
Display – /
Function Operating status Power levels Residual heat powerBoost Time-setting options
Touch fields and displays Touch a symbol to activate the function it represents. ¡ Always keep the control panel clean and dry. Mois-
ture impairs the function.
6 Basic operation
6.1Switching the hob on and off
Switch the hob on and off using the main switch . If all of the cooking zones are switched off for longer than 20 seconds, the hob is automatically switched off.
A
C
Area 18 cm dia-
meter 14.5 cm
diameter 21 cm dia-
meter
Highest power level Power level 9 powerBoost Power level 9 powerBoost Power level 9 powerBoost
1800 W 3100 W 1400 W 2200 W 2200 W 3700 W
5.4Cooking zone
Before you start cooking, check whether the size of the cookware fits the cooking zone that you want to use for cooking:
Area
Cooking zone type Single-circuit cooking zone
5.5Residual heat indicator
The hob has a residual heat indicator for each cooking zone. Do not touch the cooking zone if the residual heat indicator is lit.
Display
Meaning The cooking zone is hot. The cooking zone is warm.
reStart If you switch the appliance on within four seconds of
switching it off, the hob operates with the settings that were previously set.
7
enTime-setting options
6.2Setting the cooking zones
To choose the required selectable power level, touch or . Each power level has an intermediate level. This is marked with a dot.
Power level
Lowest power level Highest power level
Selecting the cooking zone and power setting 1. Touch to select the cooking zone. 2. Within the next 10 seconds, select the required
power level: Touch to call up power level . Touch to call up power level . a The power level has been set. Note: If no cookware is placed on the cooking zone or the pot is not suitable, the selected power level flashes. After a certain period of time, the cooking zone switches itself off.
quickStart If you place cookware on the hob before you switch
it on, the cookware is detected when you switch on and the corresponding cooking zone is selected automatically. Select the power level in the next 20 seconds, or the hob switches itself off.
Changing the power level and switching off the cooking zone 1. Select the cooking zone. 2. Touch or until the required power level ap-
pears. To switch off the cooking zone, set .
Switching off the cooking zone quickly Touch and hold the symbol for the cooking zone for three seconds. The cooking zone switches itself off.
6.3Cooking recommendations
The table shows which power level ( ) is suitable for
which food. The cooking time (
) may vary de-
pending on the type, weight, thickness and quality of
the food. To preheat, set power level 89.
Melting Butter, honey, gelatine Heating and keeping warm 1 Without lid 2 Preheat to power level 8 – 8.
1 – 2
–
7 Time-setting options
Your hob has various functions for setting the cooking time: ¡ Switch-off timer ¡ Timer
Boiled sausages1 Defrosting and heating Spinach, frozen Poaching, simmering Potato dumplings 1 Whisked sauces, e.g. Béarnaise sauce, Hollandaise sauce Boiling, steaming, braising Rice, with double the volume of water Unpeeledboiled pots Pasta 1 Soups Vegetables Stew in a pressure cooker Stewing Pot roast Goulash 2 Braising/frying with a small amount of fat 1 Escalope, plain or breaded Steak (3 cm thick) Poultry breast (2 cm thick) Hamburgers (2 cm thick) Fish and fish fillet, breaded Prawns and scampi Sautéing fresh vegetables and mushrooms Frozen dishes, e.g. stir-fries Omelette (cooked one after the other) Deep-frying, 150200 g per portion in 12 l oil, deep-fat fried in portions1 Frozen products, e.g. chips, chicken nuggets Vegetables, mushrooms, breaded, beer-battered or tempura Small baked items, e.g. doughnuts, battered fruit 1 Without lid 2 Preheat to power level 8 – 8.
3 – 4
3 – 4
4. – 5. 3 – 4
2. – 3. 4. – 5. 6 – 7 3. – 4. 2. – 3. 4. – 5.
4 – 5 3 – 4
6 – 7 7 – 8 5 – 6 6 – 7 6 – 7 7 – 8 7 – 8 6 – 7 3. – 4.
8 – 9 6 – 7
4 – 5
–
15 – 25
20 – 30 8 – 12
15 – 30 25 – 35 6 – 10 15 – 60 10 – 20 –
60 – 100 50 – 60
6 – 10 8 – 12 10 – 20 10 – 20 8 – 20 4 – 10 10 – 20 6 – 10 3 – 10
–
–
8
7.1Switch-off timer
Allows you to programme a cooking time for a hotplate and its automatic switch-off once the set time has elapsed. Programming the cooking time 1. Select the cooking zone and the required power
level. 2. Touch . a The display lights up in the cooking zone. 3. Use or to select the cooking time. a The time begins to count down. Note: You can automatically set the same cooking time for all cooking zones. You can find more information about this under “Basic settings”, Page 9. Changing or deleting the cooking time 1. Select the cooking zone. 2. Touch .
8 powerBoost
Allows larger volumes of water to be heated more quickly than with the power level . This function is available for all cooking zones, provided the other cooking zone in the same group is not in use. Otherwise, and flash in the display for the selected cooking zone. is then set automatically without activating the function.
powerBoosten
3. To change the cooking time, touch or or set it to .
7.2Timer
Enables the activation of a timer of 099 minutes. This function can be used independently of the cooking zones and other settings. It does not automatically switch off the hotplates. Setting the kitchen timer 1. Select the hotplate and touch twice. a beside lights up. 2. Use or to select the required time. a The time counts down. Changing or deleting the timer duration 1. Touch repeatedly until the display beside
lights up. 2. To change the cooking time, touch or or set it
to .
Press to switch on or off.
9 Childproof lock
The hob is equipped with a childproof lock. This prevents children from switching on the hob. To switch the function on, switch the hob off. Touch for four seconds to switch on or off.
If you want to activate the childproof lock automatically every time the hob is switched off, you can find further information under Basic settings Page 9.
10 Basic settings
You can configure the basic settings for your appliance to meet your needs.
10.1Overview of the basic settings
Display
Setting Childproof lock
Audible signals
Automatic switch-off of the cooking zones.
1 Factory setting
Value – Manual.1 Automatic. Switched off.
Confirmation and fault signals are switched off. Only the fault signal is switched on. Only the confirmation signal is switched on. All signal tones are switched on 1. switched off.1 – – minutes until the appliance switches off automatically.
9
enCookware test
Display
Setting Duration of the timer end signal tone
Power limitation
Enables the total power of the hob to be lim-
ited, if necessary, based on the conditions of
your electrical installation. The available set-
tings depend on the maximum power of the
hob. You can find precise information on the
rating plate. If the function is active and the
hob has reached the set power limit, is dis-
played and you cannot select a higher power
level.
Time for selecting the cooking zone
Cookware test
You can use this function to test the quality
of the cookware.
Restoring factory settings
1 Factory setting
Value 10 seconds 1 30 seconds – 1 minute – Switched off. Maximum power of the hob 1. – 1000 W. Lowest power setting. . – 1500 W. … – 3000 W. Recommended for 13 A. . – 3500 W. Recommended for 16 A. – 4000 W. . – 4500 W. Recommended for 20 A. … – Maximum power of the hob.
– Unlimited: You can adjust the last selected cooking zone without having to select it again.1 Limited: You can adjust the last selected cooking zone within 10 seconds after selecting it. After this time, you must select the cooking zone again before adjusting it.
– Not suitable. – Not optimal. – Suitable. – Individual settings 1. – Factory settings.
10.2To go to the basic settings
Requirement: The hob must be switched off. 1. To switch on the hob, touch . 2. Within the next 10 seconds, press and hold for
four seconds.
Product information Directory for the technical after-sales service (TK) Production number Production number 1 Production number 2
Display
. .
a The first four displays provide the product information. Touch or to view the individual displays.
3. Touch to access the basic settings. a and light up alternately as well as as a preset
value. 4. Touch repeatedly until the desired setting ap-
pears. 5. Use or to select the required value. 6. Touch and hold for four seconds. a The settings are saved.
10.3Exiting the basic settings
To exit the basic settings and and switch off the hob, touch .
11 Cookware test
The quality of the cookware has a major influence on the speed and the result of the cooking process. You can use this function to test the quality of the cookware. Before the test, ensure that the size of the cookware base corresponds to the size of the cooking zone being used. Access is via the basic settings. Page 9
11.1Carrying out Cookware test
1. At room temperature, place the cookware with approx. 200 ml water in the centre of the cooking zone that best fits the base of the cookware in terms of size.
2. Call up the basic settings and select .
3. Touch or . The display flashes in the cooking zones.
a The function has been activated. a After 10 seconds, the result appears in the cooking
zone displays.
11.2Checking the result
You can see what the result means for the quality and speed of the cooking process in the following table.
Result The cookware is not suitable for the cooking zone and therefore does not heat up.
10
Cleaning and servicingen
The cookware is taking longer to heat up than expected and cooking is not progressing as well as it ought to. The cookware is heating up correctly and cooking is progressing well.
Note: If you have any unfavourable results, reposition the cookware on a smaller cooking zone, if available. Touch or to activate the function.
12 Cleaning and servicing
To keep your appliance working efficiently for a long time, it is important to clean and maintain it carefully.
12.1Cleaning products
You can obtain suitable cleaning products and glass scrapers from customer service, a retailer or the online shop siemens-home.bsh-group.com . ATTENTION! Unsuitable cleaning products may damage the surfaces of the appliance. Never use unsuitable cleaning products. Do not use cleaning products while the hob is still
hot. This may cause marks on the surface.
Unsuitable cleaning products ¡ Undiluted detergent ¡ Detergent intended for dishwashers ¡ Abrasive cleaning products ¡ Aggressive cleaning products such as oven spray
or stain remover ¡ Abrasive sponges ¡ High-pressure or steam jet cleaners
12.2Cleaning the hob
Clean the hob after every use to stop cooking residues from getting burnt on. Requirement: The hob must be cold. Do not allow the hob to cool down if it has sugar stains, plastic or aluminium foil on it. 1. Remove heavy soiling using a glass scraper. 2. Clean the hob with a cleaning agent for glass
ceramic. Follow the cleaning instructions on the packaging of the cleaning agent. Tip: You can achieve good cleaning results using a special sponge for glass ceramic.
12.3Cleaning the hob surround
If the hob frame is dirty or stained after use, clean this. Note: Do not use a glass scraper. 1. Clean the hob frame with hot soapy water and a soft
cloth. Wash new sponge cloths thoroughly before use. 2. Dry with a soft cloth.
13 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-sales service. This will avoid unnecessary costs.
WARNING Risk of injury! Improper repairs are dangerous. Repairs to the appliance should only be carried out
by trained specialist staff. If the appliance is defective, call Customer Service.
WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out
by trained specialist staff. Only use genuine spare parts when repairing the
appliance. If the power cord of this appliance is damaged, it
must be replaced with a special connection cable, which is available from the manufacturer or his Customer Service.
13.1Warnings
Notes ¡ If appears in the displays, press and hold the
sensor for the respective cooking zone and read the fault code. ¡ If the fault code is not listed in the table, disconnect the hob from the power supply and wait 30 seconds before reconnecting it. If this display appears again, contact the technical after-sales service and specify the exact fault code. ¡ If an error occurs, the appliance does not switch to standby mode. ¡ In order to protect the appliance’s electronic parts from overheating or surge currents, the hob may temporarily reduce the power level.
13.2Information on the display panel
Fault No displays light up.
Cause and troubleshooting
The power supply has been disconnected. Use other electrical appliances to check whether there has been a power failure.
11
enDisposal
Fault No displays light up.
The displays flash. , , , , + power level and
audible signal and signal tone
/ /
Cause and troubleshooting The appliance has not been connected as shown in the circuit diagram. Connect the appliance in accordance with the circuit diagram. Electronics fault If you are unable to rectify the fault, inform the technical after-sales service. The control panel is wet or an object is covering it. Dry the control panel or remove the object. The electronics have overheated and one or all of the cooking zones have been switched off. Wait until the electronics have cooled down sufficiently. Then touch any button on the
control panel.
There is hot cookware in the vicinity of the control panel. This may cause the electronics to overheat. Remove the cookware. The fault display goes out shortly afterwards. You can continue to
cook.
There is hot cookware in the vicinity of the control panel. The cooking zone has been switched off to protect the electronics. Remove the cookware. Wait a few seconds. Touch any button. When the fault display
goes out, you can continue cooking.
The cooking zone has overheated and has been switched off to protect the work surface. Wait until the electronics have cooled down sufficiently before switching the cooking
zone back on.
The cooking zone has been operating continuously for an extended period. Individual safety switch-off is switched on. Touch any button to switch off the display so
that you can set the cooking zone again.
The operating voltage is incorrect and outside of the normal operating range. Contact your energy supplier. The hob is not connected correctly. Disconnect the hob from the mains. Connect the hob in accordance with the circuit dia-
gram.
Demo mode is activated. Disconnect the hob from the mains. Wait for 30 seconds and connect the hob. Touch
any sensor in the next three minutes. Demo mode is deactivated.
13.3Normal noises from your appliance
An induction hob may sometimes cause noises or vibrations, such as buzzing, crackling, hissing noises, fan noises or rhythmic noises.
14 Disposal
14.1Disposing of old appliance
Valuable raw materials can be reused by recycling. 1. Unplug the appliance from the mains. 2. Cut through the power cord. 3. Dispose of the appliance in an environmentally
friendly manner. Information about current disposal methods are available from your specialist dealer or local authority.
This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment – WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.
12
15 Customer Service
Function-relevant genuine spare parts according to the corresponding Ecodesign Order can be obtained from Customer Service for a period of at least 10 years from the date on which your appliance was placed on the market within the European Economic Area. Note: Under the terms of the manufacturer’s warranty the use of Customer Service is free of charge. Detailed information on the warranty period and terms of warranty in your country is available from our aftersales service, your retailer or on our website. If you contact Customer Service, you will require the product number (E-Nr.) and the production number (FD) of your appliance. The contact details for Customer Service can be found in the enclosed Customer Service directory or on our website.
16 Test dishes
These recommended settings are intended for test institutes to facilitate the testing of our appliances. The tests were carried out using our cookware sets for induction hobs. If required, these accessory sets can be purchased at a later point from specialist retailers, or through our technical after-sales service or our online shop.
16.1Melting the chocolate coating
Ingredients: 150 g dark chocolate (55% cocoa). ¡ 16 cm saucepan without lid
Boiling: Power level 1.
16.2Heating and keeping lentil stew warm
Recipe in accordance with DIN 44550 Initial temperature 20 °C Heating up without stirring ¡ 16 cm saucepan with lid, amount: 450 g
Heating up: Duration 1 min. 30 sec., power level 9
Simmering: Power level 1. ¡ 20 cm saucepan with lid, amount: 800 g
Heating up: Duration 2 min. 30 sec., power level 9
Simmering: Power level 1.
16.3Heating and keeping lentil stew warm
E.g.: Lentil diameter 57 mm. Initial temperature 20 °C Stir after heating for 1 minute ¡ 16 cm saucepan with lid, amount: 500 g
Heating up: Duration approx. 1 min. 30 sec., power level 9
Simmering: Power level 1. ¡ 20 cm saucepan with lid, amount: 1 kg
Heating up: Duration approx. 2 min. 30 sec., power level 9
Simmering: Power level 1.
Customer Serviceen
15.1Product number (E-Nr.) and production number (FD)
You can find the product number (E-Nr.) and the production number (FD) on the appliance’s rating plate. The rating plate can be found: ¡ on the appliance certificate. ¡ on the lower section of the hob. The product number (E no.) can also be found on the glass ceramic. You can also display the customer service index (KI) and the production number (FD) in the basic settings. Page 9 Make a note of your appliance’s details and the Customer Service telephone number to find them again quickly.
16.4Béchamel sauce
Milk temperature: 7 °C ¡ 16 cm saucepan without lid, ingredients: 40 g but-
ter, 40 g flour, 0.5 l milk with 3.5% fat content and a pinch of salt Preparing Béchamel sauce 1. Melt the butter, stir in the flour and salt, and heat up the mixture. Heating up: Duration 6 min., power level 2 2. Add the milk to the roux and bring to the boil, stirring continuously. Heating up: Duration 6 min. 30 sec., power level
7 3. Once the Béchamel sauce comes to the boil, leave
it on the cooking zone for a further two minutes. Simmering: Power level 2
16.5Cooking rice pudding with the lid on
Milk temperature: 7 °C 1. Heat the milk until it starts to rise up. Heat up without a lid. Stir after heating for 10 min. 2. Set the recommended power level and add rice, sugar and salt to the milk. The cooking time, including heating up, is approx. 45 minutes. ¡ 16 cm saucepan, ingredients: 190 g short-grain
rice, 90 g sugar, 750 ml milk with 3.5% fat content and 1 g salt Heating up: Duration approx. 5 min. 30 sec.,
power level 8. Simmering: Power level 3 ¡ 20 cm saucepan, ingredients: 250 g short-grain rice, 120 g sugar, 1 l milk with 3.5% fat content and 1.5 g salt Heating up: Duration approx. 5 min. 30 sec.,
power level 8. Simmering: Power level 3, stir after 10 minutes
13
enTest dishes
16.6Cooking rice pudding without a lid
Milk temperature: 7 °C 1. Add the ingredients to the milk and heat the mixture up while stirring continuously. 2. Once the milk has reached approx. 90 °C, select the recommended power level and leave it to simmer on a low heat for approx. 50 minutes. ¡ 16 cm saucepan without lid, ingredients: 190 g
short-grain rice, 90 g sugar, 750 ml milk with 3.5% fat content and 1 g salt Heating up: Duration approx. 5 min. 30 sec.,
power level 8. Simmering: Power level 3 ¡ 20 cm saucepan without lid, ingredients: 250 g short-grain rice, 120 g sugar, 1 l milk with 3.5% fat content and 1.5 g salt Heating up: Duration approx. 5 min. 30 sec.,
power level 8. Simmering: Power level 2.
16.7Cooking rice
Recipe in accordance with DIN 44550 Water temperature: 20 °C ¡ 16 cm saucepan with lid, ingredients: 125 g long-
grain rice, 300 g water and a pinch of salt Heating up: Duration approx. 2 min. 30 sec.,
power level 9 Simmering: Power level 2 ¡ 20 cm saucepan with lid, ingredients: 250g longgrain rice, 600 g water and a pinch of salt Heating up: Duration approx. 2 min. 30 sec.,
power level 9 Simmering: Power level 2.
16.8Roasting a pork loin
Initial temperature of the loin: 7 °C ¡ 24 cm pan without lid, ingredients: 3 pork loins,
total weight approx. 300 g, 1 cm thick, and 15 g sunflower oil Heating up: Duration approx. 1 min. 30 sec.,
power level 9 Simmering: Power level 7
16.9Preparing crêpes
Recipe in accordance with DIN EN 60350-2 ¡ 24 cm pan without lid, ingredients: 55 ml batter per
crêpe Heating up: Duration 1 min. 30 sec., power level
9 Simmering: Power level 7
16.10Deep-fat frying frozen chips
¡ Pot dia. 20 cm without lid: ingredients: 2 l sunflower oil. For each frying time: 200 g frozen chips, 1 cm thick. Heating up: Power level 9, until the oil temperature reaches 180 °C. Simmering: Power level 9
14
BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY siemens-home.bsh-group.com
Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom
Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG
*9001651549*
9001651549(020706) en
Welcome to Siemens Home Appliances International
