IMT7000 Shockwave 200 Wireless Party Speaker
Product Information
| Product Name | SHOCKWAVE 200 |
|---|---|
| Power | 180W |
| Item Number | IMT7100 |
| Brief Introduction | The Altec Lansing SHOCKWAVE 200 is a wireless party speaker that supports party-sync. It is equipped with various buttons on the top panel for easy control of power, playback, lighting modes, bass modes, and connectivity. |
Product Usage Instructions
Press and hold the power button for 3 seconds to power on or
power off the speaker.
In BT mode, short press the play/pause button to mute or unmute
the speaker.
Press the previous song button to play the previous song in the
playlist.
Press the next song button to play the next song in the
playlist.
Briefly press the light modes button to turn on the lighting.
Each press cycles through 9 different lighting modes and then back
to off.
Briefly press the FM mode button to enter into FM mode.
Briefly press the bass modes button to cycle through 3 bass
modes: Standard (flat), Bass Enhance 1, and Bass Enhance 2.
Briefly press the AUX mode button to enter into AUX mode.
Briefly press the BT & party-sync button to enter into
Bluetooth pairing mode. Press and hold the button to disconnect
from a paired Bluetooth device. Double-click the button to connect
or disconnect from party-sync mode.
Reset to Default Settings
Press and hold the bass button for 10 seconds to reset all
settings back to factory default.
Bluetooth Connection
- Go to the Bluetooth settings menu on your phone and make sure
Bluetooth is turned on. - Connect to the device listed as “AL Shockwave 200”.
Party-sync with AL SHOCKWAVE Family
The Altec Lansing SHOCKWAVE family consists of four members that
support party-sync. You can mix and match between these models to
set up one speaker as the primary unit connected to up to 100 other
speakers playing in sync.
- Connect one speaker to your Bluetooth device via
Bluetooth. - Double-press the BT button on the first speaker to enter
party-sync mode and make it the primary speaker. - Double-press the BT button on the next speaker to enter
party-sync mode. The speaker will find and connect to the primary
speaker. - Repeat step 3 for additional speakers you want to connect.
- To exit party-sync mode, double-press the BT button on the
speakers you wish to disconnect and return to normal
operation.
Lighting Control
Briefly press the lights button to switch between different
lighting modes. Some modes require music playing to be visible.
SHOCKWAVE 200
180W
IMT7100
IMT7100
SHOCKWAVE 200 180W
IMT7100
Quick Start Guide
UL Adaptor
Brief introduction to buttons on top panel
Power Button Press and hold button for 3 seconds to power on or power off speaker
Play/Pause (BT mode only), AUX mode: Short press MUTE
Previous song
Next song
Light Modes: Briefly press to turn on the lighting. Cycles through 9 modes and then back to off
FM Mode: Briefly press to enter into FM mode
Bass Modes: Briefly press to cycle through 3 bass modes, Standard (flat), Bass Enhance 1 and Bass Enhance 2
AUX mode: Briefly press to enter into AUX mode
BT & Party-sync Button: Briefly press to enter into Bluetooth pairing mode, Press and hold for Bluetooth disconnect, Double-click for party-sync connect or disconnect
Reset to default settings:
Press and hold the BASS button for 10S to reset all settings back to factory default.
Bluetooth Connection
Go to the Bluetooth settings menu on your phone. Make sure that Bluetooth is turned on. Connect to the device listed as “AL Shockwave 200″
AL Shockwave 200
If needed briefly press the BT button to enter into BT mode;
If you want to change to a different BT device when already paired press and hold the BT button, the speaker will disconnect from its paired device. A different device can now be paired.
Party-sync with AL SHOCKWAVE Family
AL Shockwave 200
A double press of the BT button is used to enter/exit party-sync mode on extra speakers if you have them as below.
Item Number
IMT7000 IMT7100 IMT7200 IMT7300
Item name
Shockwave Wireless Party Speaker Shockwave 200 Wireless party speaker Shockwave 300 Wireless Party Speaker Shockwave 400 Wireless Party Speaker
Pairing Name
AL Shockwave AL Shockwave 200 AL Shockwave 300 AL Shockwave 400
The Altec Lansing SHOCKWAVE family has four members that support party-sync. You can mix and match between any of these four models, setting up one speaker as the primary unit connected to up to 100 other speakers all playing in sync. 1. Connect one speaker to your Bluetooth device in the normal way via Bluetooth. 2. Double press the BT button on this first speaker to enter Party sync and
make it the primary speaker. 3. Double-press the BT button on the next speaker to enter Party-sync mode,
its BT LED will flashes slowly and it will find and connect to the first (primary) speaker. 4. Repeat No 3 if you have more speakers you want to connect. 5. To exit party-sync double press the BT button on the speakers you wish to disconnect and return to normal operation.
Notes: Playback volume is adjusted via the first (primary) speaker. The BT playback controls only operate on the first (primary) speaker. Turning off the first (primary) speaker turns off all speakers. All secondary speakers can be turned on/off individually and their light modes changed via their individual controls.
LIGHTING CONTROL
Briefly press the LIGHTS button to switch lighting mode. (Note: Some modes which use `sound-to-light’ need music playing to be visible)
Each press moves to the next mode and back round to off. Mode 1: Rotating ring in three colors Mode 2: Flashing to music Mode 3: `Spectrum’ Mode 4: `Stacking/re-stacking’ lights both sides Mode 5: Rotating lights in multi-colors Mode 6: Breathing on/off Mode 7: Flashing to music, solid lighting when no audio Mode 8: `Bar-graph’ in multi-colors Mode 9: Rotating `stacking/re-stacking’ lights
INPUT/OUTPUT PORTS
Descriptions about the various ports on the speaker
Knob to adjust the volume of microphone
Input socket for wired microphone
USB OUT: For charging your mobile devices LINE IN (AUX-IN): For connecting the line level output or headphone output of mobile devices or CD players etc. DC IN: charging your speaker from the PSU Charging-in indicator: Solid red when charging, will be off when fully charged RESET: Button is recessed inside. For use only in the unlikely case of a lock up. Use paperclip or pin to perform restart of the speaker.
Power Audio: 180W (Peak) Total Driver Units: 2 x 5.25″ Bass + 2″ Tweeter. S/N: 70dB Distortion: 0.5% 1K,1W) USB-A output: 5V 1A USB-C charging Input: 19V 1.5A Dimensions: L223*H465*D190 mm Length of UL Adaptor cable: 110cm
Supplier’s Declaration of Conformity 47 CFR § 2.1077 Compliance Information
Unique Identifier Trade Name: Altec Lansing Model No.: IMT7100 Responsible Party U.S. Contact Information US Company Name: SAKAR INTERNATIONAL INC. Address: Edison, NJ 08817 Telephone number or internet contact information: 855-292-4087
RF Exposure Compliance This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions All the safety and operating instructions should be read before this product is operated. 2.Keep these instructions The safety and operating instructions should be retained for future reference. 3.Heed all warnings All warnings on the appliance and in the operating instructions should be adhered to. 4.Follow all instructions All operating and use instructions should be followed. 5.Do not use this apparatus near water The appliance should not be used near water or moisture for example, in a wet basement or near a swimming pool, and the like. 6.Clean only with dry cloth. 7.Do not block any ventilation openings. Install in accordance with the manufacture’s instructions. 8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9.Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10.Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. 11.Only use attachments/accessories specified by the manufacturer. 12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13.Unplug the apparatus during lightning storms or when unused for long periods of time. 14.Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15.CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. 16.WARNINGTo reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. 17.WARNINGFor the terminals marked with symbol of ” ” may be of sufficient magnitude to constitute a risk of electric shock. The external wiring connected to the terminals requires installation by an instructed person or the used of ready-made leads or cords. 18. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth.
ATTENTION:RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR
19. – This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. – Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. – The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance.
