EB-530
This versatile projector is ideal for delivering high-quality presentations in classrooms and small meeting rooms
The EB-530 delivers superior-quality images and a host of additional features as standard to give users more for their money. Ideal for classrooms or small meeting rooms, this projector can be wall or ceiling mounted or placed on a table close to the wall to free-up more workspace.
High-quality image
Complete with our 3LCD technology, the EB-530 displays superior-quality, bright images with more accurate colours. The image can be seen even in brightly-lit rooms thanks to an equally high white and colour light output. Image detail is clear thanks to a high contrast ratio and our new short throw lens means sharper images and improved focus.
More value for your money
The lamp in the EB-530 now lasts up to 10,000 hours in eco mode. The projector even conserves power during presentations by automatically adjusting the light output depending on the content. The A/V mute function pauses the presentation and dims the lamp by 70% to conserve energy while the projector is not in use. The projectors’ built-in 16w speaker means audio content can be played directly through the projector, without the need for additional external speakers. The microphone input transforms the projector into a PA system, meaning presenters can be easily heard in a classroom environment.
Easy to set up and use
The EB-530 has both horizontal and vertical keystone correction to achieve a perfectly shaped image and help avoid distortion. When setting up several projectors, the OSD settings can be copied from one projector to many others meaning you don’t need to set up projectors individually. Multi-PC projection software allows content from four devices, including PC’s, tablets, smart phones, to be displayed simultaneously.
DATASHEET / BROCHURE
KEY FEATURES
- Exceptional image quality
Epson’s 3LCD technology displays brighter images and more accurate colours - Equally high white and colour light output
Projected image can be seen clearly even in brightly-lit rooms - Clearer detail
Increased contrast ratio of 16,000:1 - Longer lamp life means low TCO
10,000 hours in eco mode / 5,000 hours in normal mode - Flexible installation options
Horizontal and vertical keystone correction for off-centre and uneven placement
PRODUCT SPECIFICATIONS
| TECHNOLOGY | |
| Projection System | 3LCD Technology |
| LCD Panel | 0.55 inch with MLA (D8) |
| IMAGE | |
| Color Light Output | 3,200 Lumen- 1,800 Lumen (economy) In accordance with ISO 21118:2013 |
| White Light Output | 3,200 Lumen – 1,800 Lumen (economy) In accordance with ISO 21118:2013 |
| Resolution | XGA, 1024 x 768, 4:3 |
| Aspect Ratio | 4:3 |
| Contrast Ratio | 16,000 : 1 |
| Light source | Lamp |
| Lamp | 215 W, 5,000 h durability, 10,000 h durability (economy mode) |
| Keystone Correction | Manual vertical: ± 15 °, Manual horizontal ± 15 ° |
| Colour Video Processing | 10 Bits |
| 2D Vertical Refresh Rate | 50 Hz – 85 Hz |
| Colour Reproduction | Upto 1.07 billion colours |
| OPTICAL | |
| Throw Ratio | 0.55:1 |
| Zoom | Digital, Factor: 1 – 1.35 |
| Lens | Optical |
| Screen Size | 50 inches – 108 inches |
| Projection Distance Wide | 0.5 m ( 50 inch screen |
| Projection Distance Tele | 1.3 m ( 108 inch screen |
| Projection Lens F Number | 1.6 |
| Projection Lens Focal Length | 6.4 mm |
| Projection Lens Focus | Manual |
| Offset | 10 : 1 |
| CONNECTIVITY | |
| USB Display Function | 3 in 1: Image / Mouse / Sound |
| Interfaces | USB 2.0 Type A, USB 2.0 Type B, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11b/g/n (optional), VGA in (2x), VGA out, HDMI in, Composite in, Component in (2x), S-Video in, Stereo mini jack audio out, Stereo mini jack audio in (2x), Microphone input, Cinch audio in |
| Epson iProjection App | Ad-Hoc / Infrastructure |
| ADVANCED FEATURES | |
| Security | Kensington lock, Security bar, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Other features | Built-in speaker, Customizable user logo, Digital zoom, Dynamic lamp control, Horizontal and vertical keystone correction, Long lamp life, Microphone input, Wireless LAN capable |
| Video Color Modes | Blackboard, Dynamic, Presentation, sRGB, Theatre |
EB-530
WHAT’S IN THE BOX
| • Computer cable | • Setup guide |
| • Main unit | • Software (CD) |
| • Power cable | • User manual (CD) |
| • Remote control incl. batteries | • Safety Cable |
PRODUCT SPECIFICATIONS
| GENERAL | |
| Power consumption | 298 Watt, 221 Watt (economy), 0.28 Watt (standby) |
| Supply Voltage | AC 100 V – 240 V, 50 Hz – 60 Hz |
| Product dimensions | 344 x 315 x 94 mm (Width x Depth x Height) |
| Product weight | 3.7 kg |
| Noise Level | Normal: 37 dB (A) – Economy: 29 dB (A) |
| Supported Temperature | Operation 5° C – 35° C, Storage -10° C – 60° C |
| Supported Humidity | Operation 20% – 80%, Storage 10% – 90% If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance. |
| Included Software | EasyMP Monitor, iProjection, EasyMP Network Projection |
| Options | Connection and control box, Document camera, Quick wireless USB key, Short throw wall mount, Soft carry case, Wireless LAN unit |
| Loudspeaker | 16 Watt |
| Colour | White / Grey |
| TCO Certified | For further information relating to TCO Certified please visit https://tcocertified.com/files/certification/Information-document-for-end-users.pdf |
| OTHER | |
| Warranty | 60 months Carry in, Lamp: 60 months or 1,000 h Optional warranty extension available |
EB-530
WHAT’S IN THE BOX
| • Computer cable | • Setup guide |
| • Main unit | • Software (CD) |
| • Power cable | • User manual (CD) |
| • Remote control incl. batteries | • Safety Cable |
OPTIONAL ACCESSORIES
- Air Filter – ELPAF47
V13H134A47 - Wall Mount – ELPMB45
V12H706040 - Wireless LAN Adapter – ELPAP10
V12H731P01 - Ceiling Mount (White) – ELPMB23
V12H003B23 - Ceiling Pipe (450mm) – ELPFP13
V12H003P13 - Ceiling Pipe (700mm) – ELPFP14
V12H003P14 - Soft Carry Case – ELPKS66 – EB-52x/53x series
V12H001K66 - Lamp – ELPLP87
V13H010L87 - Active Speakers (2 x 15W) – ELPSP02
V12H467040DA
LOGISTICS INFORMATION
| SKU | V11H673041 |
| EAN code | 8715946541495 |
| Country of Origin | China |
| Layer | 4 Units |
| Layer Block | 6 Units |
EB-530
For more information please contact:
Home users: 0343 90 37766
Business users*: 0871 42 37766
Republic of Ireland: 01 436 7742 Or
visit us at https://www.epson.co.uk/contactus
* 10p per minute plus network extras.
Web: www.epson.co.uk www.epson.ie
Trademarks and registered trademarks are the property of Seiko Epson Corporation or their respective owners. Product information is subject to change without prior notice. Last extracted: 2020-04-16
