EE-5302CWH Droplet Humidifier
Product Information
Product Name: Droplet 0.5 Gallon Ultrasonic
Cool Mist Humidifier
Model: EE-5302CWH
Manufacturer: Crane USA
Safety Instructions
- Always carry the filled Water Tank with two hands.
- Do not operate the humidifier outdoors; it is intended for
indoor use only. - Ensure there is always water in the Water Tank when operating
the unit. - Use clean, cool tap water to fill the Water Tank. Filtered or
distilled water is recommended to avoid white dust if tap water is
too hard. Do not use hot water. - Make sure the Water Tank Cap is firmly tightened on the Water
Tank.
General Safety Instructions
- This humidifier is not a toy. Keep it away from children and
ensure they are supervised to prevent them from playing with
it. - Follow all instructions provided in the manual to prevent
electric shock, fire, or personal injury. - The humidifier should be operated on a separate electrical
circuit from other appliances to avoid overload. - The AC/DC Adaptor included with the product is compatible with
100-240V 50/60Hz power supply and can be used worldwide. However,
an outlet adaptor may be required in some countries.
Sustainability
Crane USA is committed to environmental sustainability. The
product’s manual is made from recycled materials without any added
finishes or harmful dyes. If the humidifier becomes inoperable,
please dispose of it at a public collection point to ensure proper
environmental disposal.
Please contact Crane Customer Care at 1-888-599-0992 or
[email protected] for any further questions or
assistance.
DROPLET 0.5 GALLON
Ultrasonic Cool Mist Humidifier
FOR MODEL: EE-5302CWH
If you have any questions about the operation of your humidifier, please contact Crane Customer
Care. Toll Free: 1-888-599-0992 Email: [email protected]
PLEASE READ AND SAVE ALL INSTRUCTIONS TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS
HUMIDIFIER.
TABLE OF CONTENTS
Table of Contents & Sustainability Safety Instructions List of Main Parts Technical Specifications, Assembly & Use Maintenance & Storing Your Humidifier Customer Care & Trouble Shooting Warranty
P.1 P.2-3 P.4 P.5-6 P.7 P.8 P.9
CRANE & SUSTAINABILITY
Crane USA is dedicated to your environment both inside and outside your home. We know if cleaned and maintained properly, our products last for years helping to reduce unnecessary use of resources and emissions making new products.
The Halls manual you are holding is from recycled materials with no added finishes or Harmful dyes. If the humidifier should no longer operate, please be sure to dispose of the unit in an environmentally friendly way by taking it to a public collection point.
PLEASE DO NOT PLACE BROKEN HUMIDIFIERS WITH YOUR REGULAR HOUSEHOLD WASTE.
1
IMPORTANT SAFETY INSTRUCTIONS
WARNING! READ AND SAVE THESE INSTRUCTIONS. Failure to follow all of the instructions
listed below may result in electric shock, fire and/or serious personal injury.
1. It is advisable to carry filled Water Tank with two hands. 2. DO NOT operate outdoors. This humidifier is intended for indoor use only. 3. Always have water in the Water Tank when operating the unit. 4. Use only clean, cool tap water to fill the Water Tank (filtered or distilled water is
recommended to avoid white dust if tap water is too hard. DO NOT use hot water. 5. Be sure that the Water Tank Cap is firmly tightened on Water Tank. Always have the Mist
Lid in place while the unit is operating. Place the humidifier so the mist aims away from children, walls, furniture and electrical appliances. 6. Use only a 100-240VAC outlet. *ALWAYS plug and unplug unit with dry hands to avoid electric shock. 7. Never operate the unit with a damaged cord or plug. 8. Always place the unit on a smooth, flat, lint-free, non-metallic, waterproof and level surface and position unit away from direct sunlight. Keep the cord away from heated surfaces and areas where it could be walked on or tripped over. Unplug the unit when not in use and whenever you clean or move the unit. 9. Do not add medication or additives of any type into the Water Basin or Water Tank. Do not cover any opening on the unit or insert objects into any openings. ONLY use vapor pads and essential oils in the vapor tray of this humidifier. 10. The unit should not be left unattended in a closed room as the air could become saturated and leave condensation on walls or furniture. Leave room door partly open when humidifier is being operated. 11. When cleaning the inside of the humidifier, keep water away from the Fan Vent. Turn off and unplug the humidifier to wipe the exterior (except the electrical controls) with a damp cloth. Humidifier requires regular cleaning. Please refer to the CLEANING INSTRUCTIONS in this manual. 12. Do not tilt or tip the humidifier or attempt to empty o fill it while it is in operation. 13. Do not use a detergent to clean any parts of the unit that contain water. Detergent film dissolved in the water supply can interfere with the output of the unit. Instead, always use white vinegar mixed with water to clean the humidifier.
SAVE THESE INSTRUCTIONS!
2
GENERAL SAFETY INSTRUCTIONS
WARNING! Read and understand all instructions. Failure to follow all instructions listed
below may result in electric shock, fire or serious personal injury. The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the user that common sense and caution are a factor which cannot be built into this product but must be supplied by the user.
THIS HUMIDIFIER IS NOT A TOY!
Do not let your child play with this humidifier. Serious injury and electrocution might
be possible. This humidifier has to be operated by an adult only. Children should be supervised to ensure that they do not play with the humidifier.
SAVE ALL INSTRUCTIONS!
CAUTION: A short Power Supply Cord is provided to reduce the risk of personal injury
resulting from becoming entangled in or tripping over a longer cord. Extension cords are available from local hardware stores and may be used if care is exercised in their use. If an extension cord is required, special care and caution is necessary. Also, the extension cord must be (1) marked with an electrical rating of 125 V and at least 13 A., 1625 W., and (2) the cord must be arranged so that it will not drape over the counter to portable top where it can be pulled on by children or accidently tripped over.
ELECTRIC POWER If the electric circuit is over loaded by other appliances, your humidifier and/or appliances may not operate properly. The humidifier should be operated on a separate electrical circuit from other operating appliances.
AC ADAPTOR
The AC/DC Adaptor included with the Crane Drop Cool Mist Humidifier with Sound Machine is 100-240V 50/60Hz and can be used worldwide. However, in some countries you may need to use an outlet adaptor.
SAFETY WARNING
Although your humidifier is easy to operate, for your safety, the below warnings must be followed: 1. Do not place the humidifier near a heat source. 2. Never leave the humidifier unattended while connected to the electrical outlet. 3. To avoid any accidents, never cover the Mist Lid when the humidifier is in operation. 4. Use the humidifier on a smooth, flat, lint-free, non-metallic, waterproof, and level
surface away from water. 5. Do not unplug from the wall socket by pulling on the supply cord. 6. The humidifier must be unplugged:
A. Before either filling or emptying the Water Basin and/or Water Tank. B. Before any cleaning or maintenance is performed. C. After each use. D. If it appears to be faulty.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
3
LIST OF MAIN PARTS
Fig.1 (Humidifier Base)
1. Nebulizer
2. Fan Outlet
3. Vapor Tray
4. Water Level Sensor Cap and
Float
5. Power Button & Indicator Light 6. Vapor Pad
1
7. Cord/AC Adaptor
4
Cap
Float
2
3
7
Fig. 2 (Water Tank)
8. Water Tank Handle 9. Mist Outlet Channel 10. Water Tank Cap
Fig. 3 (Mist Lid)
11. Mist Output Slot
6 8
TOP
5
9 10
BOTTOM
11
4
TECHNICAL SPECIFICATIONS
Rating Voltage Wattage Frequency Water Tank Capacity Run Time Per Tank Humidifying Capacity Noise Level
100-240V 24W 50/60Hz Approx. 0.5 Gallon/1.89 Liter Up to 15 hours Up to 250 sq. ft./23 m2 <37decibels from 3 ft away
BEFORE EACH USE:
CHECK HUMIDIFIER PLACEMENT:
Place the Humidifier on an elevated, non-metallic, lint-free, waterproof, level surface at least 2 feet above the floor.
· DO NOT PLACE ON CARPET OR TOWEL. The
fan vent is located on the bottom of the humidifier base. The fan vent MUST NOT be obstructed.
· DO NOT PLACE ON WOOD SURFACE or
near furniture that can be damaged by too much moisture.
CHECK WATER LEVELSENSOR:
Make sure the Water Level Sensor cap and float are secured properly in the base. The float is located under the cap and will move freely on the post. The cap is attached to the top of the post to ensure the float remains on the post. The cap will be firmly attached and will spin freely on the top of the post. (Page 4Fig.1)
CAUTION
· DO NOT attempt to operate the humidifier without water in the Water Tank. · DO NOT plug or unplug the Power Cord with wet hands as electric shock could occur.
5
ASSEMBLY & USE
ALWAYS use fresh cool water when operating the humidifier.
1. Turn Water Tank upside down, unscrew Water Tank Cap and fill with cool water only.
ALWAYS HOLD WATER TANK WITH TWO HANDS WHEN FULL.
DO NOT fill water all the way to the rim. DO NOT use hot water. DO NOT add any medication, essential oils, salt or vapor pad to the water tank. DO NOT pour water into Mist Lid.
2. Screw Water Tank Cap back on to Water Tank and turn the tank over to place on Humidifier Base, making sure it fits together securely.
Note: Do not attempt to move the humidifier while full Water Tank is placed on the Humidifier Base. Doing so may cause leakage of water and/or Humidifier Base to overfill.
3. Attach the AC Adaptor to the base of the unit and plug the other end into a wall outlet. Turn on the unit by using the Power Button. Press1x for low, 2x for medium, 3x for high and 4x to power off.
4. The Power Indicator Light will illuminate in green indicating that there is enough water in the Humidifier Base and mist will begin emitting through the Mist Lid. Note: After 20 seconds, the indicator light will turn off but product will continue to run.
SET THE CORRECT HUMIDITY OUTPUT: Adjust the mist output so the mist rises up to be absorbed by the room air. If mist drops quickly, use the lower output setting so the mist is rising up.
5. When the humidifier runs out of water, the Power Indicator Light will turn red and the mist output will stop. This is a safety feature to prevent the humidifier from possibly overheating and damaging the Nebulizer. Turn the humidifier off and unplug the unit before removing and refilling the water tank. When emptying the base, be sure to pour away from the fan outlet.
VAPOR TRAY: Remove the water tank. Place the Vapor Pads into the vapor tray or
add essential oils to the vapor tray as desired. Replace the water tank before running the humidifier.
VAPOR PAD PRECAUTION
Not recommended for children under the age of 13
6
VAPORPADS INGREDIENTS
Mentho-CherryTM Scent: Eucalyptus Oil, Menthol, Camphor, Peppermint Oil, Spearmint Oil, Cherry Fragrance & Others Mentho-Lyptus® Scent: Eucalyptus Oil, Menthol, Camphor, Peppermint Oil, Spearmint Oil & Others Mentho-LemonTM Scent: Menthol, Eucalyptus Oil, Camphor, Peppermint Oil, Spearmint Oil, Lemon Oil & Others
A NOTE ABOUT HUMIDITY
To reduce excessive humidity or condensation, especially in small rooms, leave the room door open and adjust mist intensity to the low output setting.
Too much humidity in the room may allow moisture to accumulate on surfaces where bacteria and fungi can grow. Moisture that gathers may also damage furniture and walls, especially wallpaper.
MAINTENANCE
Cleaning and disinfecting on a regular basis is important for maintaining the performance of your humidifier.
IMPORTANT: Water left in the tank or base when not in use may result in buildup of mineral deposits and bacteria which may inhibit the output efficiency as well as void the warranty. If water remains in the Water Tank for more than a day or two, bacterial growth is possible.
DAILY MAINTENANCE
1. Turn off, unplug from outlet and empty water from tank & base daily. 2. Allow tank & base to air dry. 3. Leave cap off the tank until ready for next use.
WEEKLY MAINTENANCE
1. Turn off, unplug from outlet and empty water from tank & base. 2. Fill the water tank halfway warm water and add 2 Table spoons of white vinegar.
Shake vigorously and lets it for 30 minutes. Empty tank and rinse with plain water. 3. Fill base with warm water, add 1 table spoon of white vinegar and let sit for 30
min. Empty base & rinse with plain water. Make sure to pour water away from the fan outlet when emptying. TIP: Clean the nebulizer with a damp cloth or cotton swab after soaking 4. Allow tank & base to air dry and leave cap off the tank until the next use.
NEVER IMMERSE HUMIDIFIER BASE IN WATER.
END-OF-SEASON MAINTENANCE & STORING YOUR HUMIDIFIER
1. Turn off, unplug from outlet, and empty water from tank & base. 2. Follow instructions for weekly maintenance above. 3. Let all parts dry completely. 4. Store humidifier in a cool, dry place.
7
CRANE CUSTOMER CARE
CALL US: 1-888-599-0992 (Mon-Fri 9:00am4:00pm CST) EMAIL US: [email protected] LIVE CHAT: available at www.crane-usa.com
TROUBLE SHOOTING
DO NOT attempt to repair the motor yourself.
If the humidifier continues to not operate, please contact Crane Customer Care.
Problem
Indicator Light is Staying Red:
Humidifier Does Not Have Any Power:
Solution
Ensure the cap is secured properly to the tank allowing water to pass through to the base.
Clean the Water Level Sensor cap and float: Pull of the plastic cap from the peg. Remove the water level sensor float and clean with warm sudsy water. Replace parts by first putting the float on to the peg, then replacing the plastic cap on the peg and pressing down until it “snaps” back on. (Page 4Fig.1)
Ensure unit is properly plugged into a power outlet/try another power outlet.
Check the Control Knob is turned to the ON position. If Power On indicator light does not come on,
contact Customer Care.
There is a Strange Odor:
Indicator Light is Green, But There’s No Mist:
White Dust Appears & Settles Outside the Humidifier:
Clean the Water Tank with a water & white vinegar solution and rinse with clean water. (Page 7)
Leave the empty Water Tank open in a cool place for12 hours without the Water Tank Cap attached.
Complete the weekly maintenance. (Page 7) Humidifier should be placed on a hard flat surface &
fan vent should not be blocked. The base might be over filled: Remove the tank, empty the
base & replace the filled tank on the empty base. Try turning the control knob up to MAX and let it run for10
minutes.
Are a tap water may have too many minerals. Change to filtered or distilled water, or use with a Crane Demineralization Filter cartridge.
Humidifier is Leaking:
From MIST LID: Turn control knob down From TANK: Check for possible cracks in the tank or around
the seam of the tank From BASE: Call Customer Care
NOTE: Spare Parts can also be purchased online at www.crane-usa.com
8
CRANE WARRANTY
For more information regarding the warranty policy, please visit our website: www.crane-usa.com/customer-service
LIMI TED WARRANTY
Thank you for purchasing a Crane product which has been tested to meet our stringent quality standards. This product is warrantied to be free from manufacturing defects under normal use and conditions for 1 year.
PLEASE CONTACT US BEFORE RETURNING THIS PRODUCT TO THE STORE. CALL CRANE CUSTOMER CARE FOR PROBLEMS AND QUESTIONS. WE CAN HELP.
WARRANTY REQUIRES A DATEDPROOF OF PURCHASE.
This warranty is void if the defect is due to accidental damage, misuse, abuse, neglect, improper repair or alteration by unauthorized persons, or a failure to follow operating instructions provided with the product including the use of essential oils or vapor pads directly into the tank. This warranty does not apply to normal wear and tear or commercial use.
In no event shall liability exceed the purchase price paid by the purchaser of the product. Under no circumstances shall there be liability for any loss direct, indirect or incidental or consequential damage arising out of, or in connection with the use of this product.
This warranty is valid only in the 48 contiguous states plus the District of Columbia and excludes Puerto Rico and the Virgin Islands. This warranty is effective only if the product is purchased and operated in the United States of America.
Any instructions or warranty included in this manual may be subject to change without notice. For the most up-to-date instructions and warranty information, please contact us or visit our website.
SAVE YOUR DATEDPROOF OF PURCHASE!
TO RECEIVE WARRANTY INSTRUCTIONS AND RETURN AUTHORIZATION, PLEASE CALL OR EMAIL CRANE CUSTOMER CARE.
CRANE USA, INC.
1015 Hawthorn Dr., Itasca, IL 60143
Toll Free:1-888-599-0992 (Monday- Friday 9:00am – 4:00pm CST) Email: [email protected] Website: www.crane-usa.com
9
HALLS, the HALLS Design, BREATHE IT IN, MENTHO-LYPTUS, MENTHO-CHERRY and MENTHO-LEMON are trademarks of Mondelz International group, used under license.
10
