CT22PEFCNT90SS Cleantray 90-Degree Elbo Perforated Without Tabs
Instructions
CLEANTRAY 90-DEGREE ELBO, PERFORATED WITHOUT TABS
Clean Tray 90-Degree Elbows are used for right-angle installations. The Clean Tray stainless steel system is designed to protect rated cabling in applications that require frequent washdown.
FEATURES & BENEFITS
Clean Tray 90-Degree Elbows are used for right-angle installations The Clean Tray stainless steel system is designed to protect rated cabling in applications that require frequent washdown
SPECIFICATIONS
Color Unpainted
Finish Brushed #3
| Catalog Number | Type | Height | Width | Protection Rating | Material | Thickness |
| CT22PEFCNT90SS | Elbow | 51 mm | 51 mm | Stainless Steel 304 | 1.27 mm | |
| CT33PEFCNT90SS | Elbow | 76 mm | 76 mm | Stainless Steel 304 | 1.27 mm | |
| CT44PEFCNT90SS | Elbow | 102 mm | 102 mm | NEMA Type 1 | Stainless Steel 304 | 1.27 mm |
| CT46PEFCNT90SS | Elbow | 102 mm | 152 mm | Stainless Steel 304 | 1.27 mm | |
| CT66PEFCNT90SS | Elbow | 152 mm | 152 mm | Stainless Steel 304 | 1.27 mm |
