DW60UN2X2 Built-Under Dishwasher
Product Information
Product Name: DW60UN2X2 Built-under Dishwasher,
Sanitise
Series: 5 | Contemporary Stainless Steel
Dimensions:
- Height: 820 – 880mm
- Width: 597mm
- Depth: 574mm
Features & Benefits:
- Seamless Design: Install this dishwasher flush
under your benchtop with minimal gaps. Designed to match our
Contemporary family of appliances with a recessed handle for a
seamless finish in your kitchen. - Effortless Drying: Automatic door opening at
the end of the cycle to release excess steam, ensuring dry dishes
ready to use or store. - A Reliable Clean: Seven wash programs
including Auto, with a three-stage filtration system for a superior
clean. Rinse aid indicator reminds you to top up for clean
dishes. - Customize Your Wash: Half Load modifier for
faster turnaround, Sanitise for extra protection, and Dry+ modifier
for plastic dishes. - Efficient Performance: 4-star energy rating
and 5-star water rating for optimal water and energy consumption.
Eco wash program available.
Specifications:
- Accessories: Cutlery basket
- Capacity and Loading: Accommodates round
plates, Adjustable height, foldable Easy lift adjustable upper - Consumption: Energy rating: 4 stars, Energy
usage: 246kWh/year, Water consumption (per wash): 12.2L, Water
efficiency: 5 stars (WELS) - Controls: Child lock, Energy saving delay
start, Rinse aid indicator light, Time remaining LED display, Wi-Fi
connectivity - Features: Air curtain for bench, Aquastop,
Auto Door Open Dry, Flood protection, Half load option, Internal
tub material, Motor type: ThermoDry system, Three-stage filtration
system - Performance: Noise emissions: 46dBA
- Power Requirements: Amperage: 10A, Supply
frequency: 50Hz, Supply voltage: 230V - Product Dimensions: Depth: 574mm, Height: 820
– 880mm, Width: 597mm - Warranty: Parts and labour: 2 years
- Wash Programs: 60 min, Auto, Eco, Heavy,
Light, Medium, Rinse - Wash Program Modifiers: Dry+, Half-load,
Sanitise
Product Usage Instructions
To use the DW60UN2X2 Built-under Dishwasher:
- Ensure that the dishwasher is installed flush under your
benchtop with minimal gaps. - Load the dishwasher with dishes, making sure to follow the
loading instructions provided in the user manual. - Select the desired wash program based on your dishes’ cleaning
needs. The available wash programs are: 60 min, Auto, Eco, Heavy,
Light, Medium, and Rinse. - If needed, customize the wash using the available modifiers.
The Half Load modifier is ideal for washing a partial load, the
Sanitise modifier provides extra protection by killing 99.9% of
bacteria in the final rinse, and the Dry+ modifier is suitable for
plastic dishes. - If desired, you can delay the start of the cycle using the
Energy saving delay start feature. - Close the dishwasher door and ensure it is securely
latched. - Press the Start button to begin the selected wash program.
- During the cycle, you can monitor the time remaining using the
Time remaining LED display. - At the end of the cycle, the dishwasher will automatically open
the door to release excess steam and ensure dry dishes. Wait for
the door to open completely before unloading. - Unload the clean and dry dishes from the dishwasher.
Note: For more detailed instructions on installation, loading,
and operation, please refer to the user manual provided with the
product.
QUICK REFERENCE GUIDE > DW60UN2X2
Built-under Dishwasher, Sanitise
Series 5 | Contemporary Stainless Steel
Designed to fit flush under your benchtop for a seamless look, this dishwasher delivers extra wash options and Auto Door Open Dry.
Designed to be built under your benchtop, fitting flush with cabinetry for a seamless look Seven wash programs from Heavy to Light, including Auto, 60min and Eco Dry+, Sanitise and Half Load modifiers provide extra wash options Wi-Fi enabled and works with the SmartHQTM app for remote control and notifications
DIMENSIONS
Height Width Depth
820 – 880mm 597mm 574mm
FEATURES & BENEFITS
SEAMLESS DESIGN Install this dishwasher flush under your benchtop with minimal gaps. Designed to match our Contemporary family of appliances with a recessed handle for a seamless finish in your kitchen.
EFFORTLESS DRYING For beautifully dry dishes, this dishwasher features automatic door opening at the end of the cycle to release excess steam. Making unloading more convenient, the Auto Door Open Dry
Date: 06.07.2023 > 1
feature helps to ensure dishes come out dry and ready to use or store.
A RELIABLE CLEAN This dishwasher offers seven wash programs including Auto, which automatically senses the optimal wash settings for your dishes. The three-stage filtration system delivers a superior clean, while the rinse aid indicator reminds you to top up for beautifully clean dishes.
CUSTOMISE YOUR WASH The Half Load modifier is perfect for washing a partial load, for faster turnaround of dishes. Sanitise provides extra protection, killing 99.9% of bacteria* in the final rinse, while the Dry+ modifier is great for plastic dishes. *Certified to NSF/ANSI Standard 184
EFFICIENT PERFORMANCE With a 4 star energy rating and 5 star water rating, this dishwasher delivers a powerful wash. Use the Eco wash program for optimal water and energy consumption, or choose when the cycle begins with Delay Start.
FLEXIBLE LOADING Designed to fit 15 place settings with ease, adjustable racks help you to load and care for various items including a heightadjustable upper basket, and foldable cup holders and tines.
SPECIFICATIONS
Accessories
Cutlery basket
·
Capacity and loading Accommodates round plates Accommodates round plates Adjustable height, foldable Easy lift adjustable upper
320mm 250mm
· ·
QUICK REFERENCE GUIDE > DW60UN2X2
Fold down tines
·
Place settings
15
Consumption Energy rating Energy usage Water consumption (per wash Water efficiency
4 star 246kWh/year
12.2L 5 star (WELS)
Controls
Child lock
·
Energy saving delay start
·
Rinse aid indicator light
·
Time remaining LED display
·
Wi-Fi connectivity
·
Features Air curtain for bench Aquastop Auto Door Open Dry Flood protection Half load option Internal tub material Motor type ThermoDry system Three-stage filtration system
· · · · · Stainless Steel Asynchronous · ·
Performance Noise emissions
46dBA
Power requirements Amperage Supply frequency Supply voltage
Product dimensions Depth Height Width
Warranty Parts and labour
Wash Program Modifiers Dry + Half-load Sanitise Wash modifiers
Wash Programs 60 min Auto Eco Heavy Light Medium Rinse Wash programs
10A 50Hz 230V
574mm 820 – 880mm
597mm
2 years
Water connection Water pressure Water supply
Date: 06.07.2023 > 2
30kPa – 1000 kPa 3/4″ BSP (20mm) Connector
SKU
82429
The product dimensions and specifications in this page apply to the specific product and model. Under our policy of continuous improvement, these dimensions and specifications may change at any time. You should therefore check with Fisher & Paykel’s Customer Care Centre to ensure this page correctly describes the model currently available. ? Fisher & Paykel Appliances Ltd 2020
· · · 3
· · · · · · · 7
QUICK REFERENCE GUIDE > DW60UN2X2
Other product downloads available at fisherpaykel.com Service & Warranty Wash Program Data Dishwasher Energy & Water Label Dishwasher Installation Guide Built-Under Dishwasher Preliminary Specification Guide Dishwasher
