SV – 01FC
Smartwatch
instructions
Installation and login of the application.
- Turn on Bluetooth before installing the app.
- Search for”FitCloudPro” in the App Store (iPhone) or in the Play Store (Android), download and install the App. Compatibility: iOS 9.0 or above / Android 5.0 or above
- After installation, please register and log in according to the instructions.
Charging instruction.
Put the magnetic charger cable into the watch’s charging port, it will automatically adsorb to charging. (Input voltage: 5V / 1A or 5V / 2A)
Bluetooth pairing
- Start App to set personal information.
- Click “Device”-“Add device”- Search
- “LW6″- Click”Pairing” 3.4. Done.
Operation Guidance.
 | Sports data Swipe the touch screen from right to left to enter the exercise data interface to view the day’s data: steps, distance, and calories. |  | Sleep monitor. It shows the sleep monitoring status of the day, the data is updated every day, when the app is synchronous, the data can be saved synchronously and the device recalculates the data of the new day. |
 | Message. The pop-up message, connect with the mobile phone app, synchronize new messages from the phone with the watch. Maximum of 15 unread messages saved on the watch. |  | Sport mode. Includes: walking, running, climbing, cycling, basketball, yoga, elliptical, jump rope. The last one is the recorder to see the detail of the sports data. |
 | Weather. Pop-up weather, connect to the phone APP, weather information sync to the watch. |  | Stopwatch Stopwatch timing, click the triangle image to start or exit, maximum 8 messages to be saved. |
 | Heart rate monitor. When switching to this interface, the green light at the bottom turns on to start the measurement, and the measurement is completed in about 30-60 seconds. The measured value is based on PPG technology. |  | Music. Connect to the App, start the music player to control music playing. |
 | Blood pressure monitor. When switching to this interface, the green light at the bottom turns on to start the measurement, and the measurement is completed in about 30-60 seconds. The measured value is based on PPG technology. |  | Brightness control. Enter the settings to find the brightness adjustment interface, rotate the knob to control. |
 | Blood oxygen monitor. When switching to this interface, the green light at the bottom turns on to start the measurement, and the measurement is completed in about 30-60 seconds. The measured value is based on PPG technology. |  | Watch faces option The dial can be selected, and the dial can be switched by long-pressing the dial, and it supports push dial (the watch has 4 built-in dials) |
 | Turn on/off Press the power button 3 seconds to turn on / off, auto power on when charging, click turn off image to power off. |  | System information. View the Bluetooth name, MAC address, firmware version, UI version, and other information. |
 | Language option. Connect to the phone, automatically recognized the phone language, select the language on the menu. |  | Restore factory. This setting will delete all personal data after validation. |
Product parameters.
- Read the manual before use.
- The data of this product is for health management reference only, it cannot be as medical data, if have abnormal data, should be subject to the hospital’s test data.
- IP68 waterproof means that it can be used normally in daily life environments, such as washing hands or in the rain. Do not put the watch into hot water, do not press the button underwater or go on the deep-diving activity, do not go near corrosive liquids that damage the watch.
Waterproof rate: IP68
Sensor: 3axis G-sensor
Battery capacity: 190 mAh
Sync mode: Bluetooth
Resolution: 240 x 240 pixels
Display: 1.09 inch TFT, capacitive full touch screen
Working time: about5-7 days
Operating temperature: -10°C – 50°C
Compatible system: iOS 9.0 or above/Android 5.0 or above
