DP C07.CAN LCD Display CAN
Product Information
The DP C07.CAN is a display unit designed for use with a
pedelec. It provides important information and control options for
the pedelec system. The display features a clear and easy-to-read
screen, with various functions and settings available.
Specifications
- Display of battery capacity in real-time
- Kilometer stand, daily kilometers (TRIP), total kilometers
(TOTAL) - Indication of headlights/backlighting status
- Walking assistance feature
- Speed unit and digital speed display
- Speed mode options: top speed (MAXS) and average speed
(AVG) - Error indicator for troubleshooting
- Data display corresponding to the current mode
- Support level selection
Key Definitions
- Up: Increase value or navigate up
- Down: Decrease value or navigate down
- Light On/Off: Toggle headlights or backlighting
- System On/Off: Turn the system on or off
- OK/Enter: Confirm selection or enter menu
Product Usage Instructions
Switching the System ON/OFF
To turn on the system, press and hold the System On/Off button
on the display for more than 2 seconds. To turn off the system,
press and hold the System On/Off button again for more than 2
seconds. If the automatic shutdown time is set to 5 minutes, the
display will automatically turn off within that time when not in
use.
Selection of Support Levels
When the display is turned on, press and hold the button for 2
seconds to turn off the headlight and the display backlight. The
brightness of the backlight can be adjusted in the display
settings. If the display is turned on in a dark environment, the
display backlight and headlight will automatically be switched on.
If manually switched off, the automatic sensor function is
deactivated.
Battery Capacity Indication
The battery capacity is shown on the display with ten bars. Each
full bar represents a remaining capacity of the battery in
percentage. If the frame of the indicator blinks, it means the
battery needs to be charged.
Walk Assistance
The walk assistance feature can only be activated when the
pedelec is in a stationary position. To activate it, briefly press
the designated button.
7 USER MANUAL FOR DP C07.CAN
USER MANUAL FOR DISPLAY
CONTENT
7.1 Important Notice
2
7.6.2 Selection of Support Levels
5
7.2 Introduction of Display
2
7.6.3 Selection mode
5
7.3 Product Description
3
7.6.4 Headlights / backlighting
6
7.3.1 Specifications
3
7.6.5 Walk Assistance
6
7.3.2 Functions Overview
3
7.6.6 Battery capacity indication
6
7.4 Display
4
7.7 Settings
7
7.5 Key Definition
4
7.7.1 Setting
7
7.6 Normal Operation
5
7.7.2 View Information
8
7.6.1 Switching the System ON/OFF
5
7.8 Error Code Definition
12
BF-UM-C-DP C07-EN November 2019
1
7.1 IMPORTANT NOTICE
· If the error information from the display cannot be corrected according to the instructions, please contact your retailer.
· The product is designed to be waterproof. It is highly recommended to avoid submerging the display under water.
· Do not clean the display with a steam jet, high-pressure cleaner or water hose.
· Please use this product with care.
· Do not use thinners or other solvents to clean the display. Such substances can damage the surfaces.
· Warranty is not included due to wear and normal use and aging.
7.2 INTRODUCTION OF DISPLAY
· Model: DP C07.CAN BUS
· The housing material is PC and Acrylic, and the button material is made of silicone.
· The label marking is as follows:
Note: Please keep the QR code label attached to the display cable. The information from the Label is used for a later possible software update.
2
BF-UM-C-DP C07-EN November 2019
USER MANUAL FOR DISPLAY
7.3 PRODUCT DESCRIPTION
7.3.1 Specifications · Operating temperature: -20~45 · Storage temperature: -20~50 · Waterproof: IP65 · Bearing humidity: 30%-70% RH
7.3.2 Functional Overview
· Speed display (including speed in real time (SPEED), top speed (MAXS) and average speed (AVG), switching between km and miles)
· Battery capacity indicator · Automatic sensors explanation of the light-
ing system · Brightness setting for backlight · Indication of performance support · Walk assistance · Kilometer stand (including single-trip dis-
tance, total distance) · Display for the remaining distance.(Depends
on your riding style) · Motor output power indicator · Energy consumption indicator CALORIES
(Note: If the display has this function) · Error messages view · Service
BF-UM-C-DP C07-EN November 2019
3
7.4 DISPLAY
5
6
7
1 8
2
9
3
10
11
4
12
1 Display of battery capacity in real time.
2 Kilometer stand, Daily kilometers (TRIP) Total kilometers (TOTAL).
3 The display shows this symbol, if the light is on.
4 Walking assistance
.
5 Service: please see the service section.
6 Menu.
7 Speed unit.
8 Digital speed display.
9 Speed mode , top speed (MAXS) – Average speed (AVG).
10 Error indicator .
11 Data: Display data, which corresponds to the current mode.
12 Support level
7.5 KEY DEFINITION
Up Down
Light On/Off System On/Off OK/Enter
4
BF-UM-C-DP C07-EN November 2019
USER MANUAL FOR DISPLAY
7.6 NORMAL OPERATION
7.6.1 Switching the System ON/OFF
Press and hold (>2S) turn off the system.
on the display to turn on the system. Press and hold (>2S)
again to
If the “automatic shutdown time” is set to 5 minutes (it can be set with the “Auto Off” function, See “Auto Off”), the display will automatically be turned off within the desired time when it is not in operation.
7.6.2 Selection of Support Levels
When the display is turned on, press (<0.5S) the or button to switch to the support level, the lowest level is 1, the highest level is 5. When the system is switched on, the support level starts in level 1. There is no support at level null.
7.6.3 Selection mode
Briefly press (<0.5s) the button to see the different trip modes. Trip: daily kilometers (TRIP) – total kilometers (TOTAL) – Maximum speed (MAXS) – Average speed (AVG) – Remaining distance (RANGE) – Output power (W) – Energy consumption (C (only with torque sensor fitted)).
BF-UM-C-DP C07-EN November 2019
5
7.6.4 Headlights / backlighting
Hold (>2S) the
button to activate the
headlight and the display backlight.
Hold (>2S) the
button again to turn
off the headlight and the display backlight.
The brightness of the backlight can be set
in the display settings “Brightness”. (If the
display /Pedelec is switched on in a dark
environment, the display backlight/head-
light will automatically be switched on. If
the display backlight/headlight has been
manually switched off, the automatic sensor
function is deactivated. You can only turn
on the light manually after switching on the
system again.)
7.6.6 Battery capacity indication
The battery capacity is showed in ten bars. Each full bar represents a remaining capacity of the battery in a percentage, if the frame of indicator blinks that means to charge. (as shown in the figure below):
7.6.5 Walk Assistance
The Walk assistance can only be activated with a standing pedelec.
Activation: Briefly press (<0.5S) the
button until to level null, and then press
(<0.5s) the button, the
symbol is
displayed. Now hold down the button
and the Walk assistance will activate. The
symbol will flashes and the pedelec
moves approx. 4.5 km/h. After releasing the
button, the motor stops automatically and
switches back to level null (if no any option
be activated in 5 second). If no speed signal
is detected, it shows 2.5km/h.
Bars 10 9 8 7 6 5 4 3 2 1 Blinking
Charge in Percentage 90%
80%C<90% 70%C<80% 60%C<70% 50%C<60% 40%C<50% 30%C<40% 20%C<30% 10%C<20% 5%C<10%
C5%
6
BF-UM-C-DP C07-EN November 2019
USER MANUAL FOR DISPLAY
7.7 SETTINGS
After the display is turned on, quickly press (<0.3S) the button twice to access the “MENU” interface. pressing the or button, you can select and reset the options. Then press (<0.3S) the button twice to confirm your selected option and to return to the main screen. If no button is pressed within 10 seconds in “MENU” interface, the display will automatically return to the main screen and no data will be saved.
7.7.1.2 Selection of unit in km/Miles
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “S7” appears on the display (as shown below). Now using the
or button, choose between “km/h” or “mile/h”.
Once you have chosen your desired selection, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to save and enter next item “Set light sensitivity”.
7.7.1 Setting
7.7.1.1 Reset mileage
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface and “tC” appears on the display (as shown below). Now using the or button, choose between “y”(YES) or “n”(NO). If choose “y”, the Daily kilometers (TRIP), Maximum speed (MAX) and Average speed (AVG) will be reset.
Once you have chosen your desired selection, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to save and enter next item “Selection of unit in km/Miles”.
7.7.1.3 Set light sensitivity
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “bL0” appears on the display (as shown below). And then press to increase or to reduce (light sensitivity for 0-5). Chose 0 means turn off the light sensitivity.
Once you have chosen your desired selection, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to save and enter next item “Set display brightness”.
NOTE: If the daily kilometers accumulate 99999km, the daily kilometers will be reset auto-
matically.
BF-UM-C-DP C07-EN November 2019
7
7.7.1.4 Set display brightness When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “bL1” appears on the display (as shown below). And then press to increase or to reduce (brightness for 1-5). Once you have chosen your desired selection, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to save and enter next item “Set Auto Off”.
7.7.1.5 Set Auto Off When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “OFF” appears on the display (as shown below). And then press to increase or to reduce (brightness for 1-9minute). Once you have chosen your desired selection, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to save and enter next item “Service Tip”.
or to choose between “0” or “1”. Chose 0 means turn off the notification.
Once you have chosen your desired selection, press (<0.3S) the button twice to save and return to the main screen.
NOTE: If the “Service” function switch on, every
5000 km (the mileage of more than 5000 km) the
indicator ”
” is displayed every time at
switch on.
7.7.2 View Information
All data in this item cannot be changed, only to be viewed.
7.7.2.1 Wheel Size
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “LUd” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to return to the main screen, or you can press (<0.3S) the button once to enter next item “Speed Limit”.
7.7.1.6 Service Tip
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “nnA” appears on the display (as shown below). And then press
8
7.7.2.2 Speed Limit
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “SPL” appears on the display (as shown below).
BF-UM-C-DP C07-EN November 2019
USER MANUAL FOR DISPLAY
Once you have viewed your desired information, press (<0.3S) the button twice to return to the main screen, or you can press (<0.3S) the button once to enter next item “Controller hardware info”.
can press (<0.3S) the button once to enter next item “Display hardware info”.
7.7.2.3 Controller hardware info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “CHc (Controller Hardware check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to return to the main screen, or you can press (<0.3S) the button once to enter next item “Controller software info”.
7.7.2.5 Display hardware info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “dHc (Display Hardware check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “Display software info”.
7.7.2.4 Controller software info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “CSc (Controller Software check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you
7.7.2.6 Display software info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “dSc (Display Software check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “BMS hardware info”.
BF-UM-C-DP C07-EN November 2019
9
7.7.2.7 BMS hardware info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “bHc (BMS Hardware check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “BMS software info”.
7.7.2.9 Sensor hardware info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the button until the “SHc (Sensor Hardware check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “Sensor software info”.
7.7.2.8 BMS software info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “dSc (Display Software check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “Sensor hardware info”.
NOTE: This information is not displayed, if there are no torque sensor in the drive system.
7.7.2.10 Sensor software info
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “SSc (Sensor Software check)” appears on the display (as shown below).
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “Battery info”.
10
BF-UM-C-DP C07-EN November 2019
USER MANUAL FOR DISPLAY
NOTE: This information is not displayed, if there are no torque sensor in the drive system.
7.7.2.11 Battery Information
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “b01” appears on the display (as shown below). You can briefly press (0.3s) to view all information of the battery.
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen, or you can press (<0.3S) the button once to enter next item “Message of Error Code”.
Content Explanation
b09
Relative SOC (%)
b10
Absolute SOC (%)
b11
Charging cycles (number)
b12
Maximum not charging time (Hr)
b13
Recently not charging time (Hr)
d00
Number of battery cell
d01
Voltage of cell 1 (m/V)
d02
Voltage of cell 2 (m/V)
dn
Voltage of cell n (m/V)
NOTE: If no data is detected, “–” is displayed.
7.7.2.12 Message of Error Code
When the system is on, quickly press (<0.3S) the button twice to access the “MENU” interface, repetitively press the
button until the “E00” appears on the display (as shown below). You can briefly
press
(0.3s) to view last ten Error Code
“EO0” to “EO9”. Error code “00” means that
there is no error.
Once you have viewed your desired information, press (<0.3S) the button twice to save and return to the main screen.
Content Explanation
b01
Current temperature (°C)
b04
Voltage (V)
b06
Discharge (A)
b07
Remaining Capacity (A/h)
b08
Total Capacity (A/h)
BF-UM-C-DP C07-EN November 2019
11
7.8 ERROR CODE DEFINITION
The display can show the errors of a pedelec. If an error is detected, the wrench icon appears on the display and one of the following error codes will be displayed. Note: Please read the description of the error code carefully. If you see the error code, restart the system first. If the problem is not resolved, please contact your dealer.
Error
Declaration
Troubleshooting
04
The throttle has fault.
1. Check the connector of throttle whether they are correctly connected.
2. Disconnect the throttle, If the problem still occurs, please contact your retailer.
(only with this function)
Check the throttle can adjust back into its
05
The throttle is not back in its correct correct position, if the situation does not
position.
improve, please change to a new throttle.(only
with this function)
07
Overvoltage protection
1. Remove the battery. 2. Re-Insert the battery. 3. If the problem persists, please contact your retailer.
08
Error with the hall sensor signal inside the motor
Please contact your retailer.
09
Error with the Engine phase’s
Please contact your retailer.
1. Turn off the system and allow the Pedelec
The temperature inside the engine
to cool down.
10
has reached its maximum protection
value
2. If the problem persists, please contact your
retailer.
11
The temperature sensor inside the
Please contact your retailer.
motor has an error
12
Error with the current sensor in the controller
Please contact your retailer.
13
Error with the temperature sensor inside of the battery
Please contact your retailer.
12
BF-UM-C-DP C07-EN November 2019
USER MANUAL FOR DISPLAY
Error
Declaration
Troubleshooting
1. Turn off the system and let the pedelec cool
The protection temperature inside
down.
14
the controller has reached its maxi-
mum protection value
2. If the problem persists, please contact your
retailer.
15
Error with the temperature sensor
Please contact your retailer.
inside the controller
21
Speed sensor Error
1. Restart the system
2. Check that the magnet attached to the spoke is aligned with the speed sensor and that the distance is between 10 mm and 20 mm.
3. Check that the speed sensor connector is connected correctly.
4. If the error persists, please contact your retailer.
25
Torque signal Error
1. Check that all connections are connected correctly.
2. If the error persists, please contact your retailer.
1.Check the connector from the speed sensor
to make sure it is connected correctly.
26
Speed signal of the torque sensor has 2.Check the speed sensor for signs of damage.
an error
3.If the problem persists, please contact your
retailer.
27
Overcurrent from controller
Please contact your retailer.
30
Communication problem
1. Check all connections are correctly connected.
2. If the error persists, please contact your retailer.
Brake signal has an error 33
(If brake sensors are fitted)
1. Check all connectors.
2. If the error continues to occur, please contact your retailer.
BF-UM-C-DP C07-EN November 2019
13
Error
Declaration
Troubleshooting
35
Detection circuit for 15V has an error Please contact your retailer.
36
Detection circuit on the keypad has an error
Please contact your retailer.
37
WDT circuit is faulty
Please contact your retailer.
41
Total voltage from the battery is too high
Please contact your retailer.
42
Total voltage from the battery is too low
Please contact your retailer.
Total power from the battery cells is
43
too high
Please contact your retailer.
44
Voltage of the single cell is too high Please contact your retailer.
Temperature from the battery is too
45
high
Please contact your retailer.
46
The temperature of the battery is
Please contact your retailer.
too low
47
SOC of the battery is too high
Please contact your retailer.
48
SOC of the battery is too low
Please contact your retailer.
61
Switching detection defect
Please contact your retailer. (only with this function)
62
Electronic derailleur cannot release. Please contact your retailer. (only with this
function)
71
Electronic lock is jammed
Please contact your retailer. (only with this function)
Please contact your retailer. (only with this
81
Bluetooth module has an error
function)
14
BF-UM-C-DP C07-EN November 2019
