Insignia Ns-pnk5011 Wireless Keyboard User Guide

NS-PNK5011 Wireless Keyboard

Product Information

Product Usage Instructions

Installing the keyboard batteries:

1. Take the battery cover off.
2. Insert two AAA batteries (included) into the battery
   compartment, ensuring that the + and – signs match the symbols in
   the compartment.
3. Replace the cover.

Setting up the connection between the nano receiver and
keyboard:

1. Plug the nano receiver into the USB port on your computer.
2. The computer will automatically detect your keyboard, and you
   can immediately begin using it.

Cleaning your keyboard:

Use a soft, lint-free cloth to clean the keyboard. Avoid using
liquid cleaners or abrasive materials that may damage the keys or
the surface.

Troubleshooting:

If you encounter any issues with the keyboard, refer to the
troubleshooting section in the user manual or contact Insignia
customer support.

Specifications

Legal Notices

One-year limited warranty. For complete warranty details, visit
www.insigniaproducts.com.

INSIGNIA is a trademark of Best Buy and its affiliated
companies. Registered in some countries.

Distributed by Best Buy Purchasing, LLC, 7601 Penn Ave South,
Richfield, MN 55423 U.S.A.

Contact Insignia: 1-877-467-4289 (U.S. and Canada) or
01-800-926-3000 (Mexico).

NS-PNK5011_NS-PNK5011-C_14-1345_QSG_V4_EN.ai 1 12/2/2014 4:47:38 PM
Package contents
· Wireless keyboard · Nano receiver · AAA alkaline batteries (2) · Quick Setup Guide
System requirements
· Windows® 8, Windows® 7, Windows Vista®, Windows® XP, or Mac OS 10.X or higher
· One available USB port

Final flat size: 314.33 x 148.08 mm Final fold size: 104.78 x 148.08 mm
Keyboard features

V4
FINAL FOR PRINT
Quick Setup Guide Wireless Keyboard | NS-PNK5011/NS-PNK5011-C

# Icon Function Description

1

Play/Pause Press to play or pause media.

2

Stop

Press to stop playing media.

3

Previous

Press to select the previous media track.

4

Next

Press to select the next media track.

5

Volume down Press to decrease the computer’s volume.

6

Volume up Press to increase the computer’s volume.

7

Mute

Press to turn off your computer’s sound.

8

Calculator Press to start Microsoft calculator.

9 LED indicator

Low battery and pairing indicator. See”LED indicator”for more information.

10 Connect button

Press to initiate pairing with your computer.

11 Battery cover

Remove to install or replace the batteries.

Installing the keyboard batteries
1 Take the battery cover off. 2 Insert two AAA batteries (included) into the battery compartment.
Make sure that the + and – signs match the symbols in the compartment. 3 Replace the cover.
2 AAA batteries

Before using your new product, please read these instructions to prevent any damage.

Before using your new product, please read these instructions to prevent any damage. NS-PNK5011_NS-PNK5011-C_14-1345_QSG_V4_EN.ai 2 12/2/2014 4:47:38 PM

Setting up the connection between the nano receiver and keyboard
1 Plug the nano receiver into the USB port on your computer. 2 The computer automatically detects your keyboard and you can
immediately begin using it.

If the keyboard does not work: · Move your computer and keyboard closer together. · Re-plug the nano receiver into the USB port on your computer, then press
the connect button on the keyboard. The LED indicator on the keyboard flashes steadily while in pairing mode (10 seconds). After pairing successfully, the LED indicator lights solid for 10 seconds, then turns off. · Check the batteries in your keyboard. The LED indicator blinks for 10 seconds when the batteries are low.

LED indicator
LED indicator

Function Description

Power ON Red LED is on for 10 seconds, then turns off.

Low battery Red LED blinks for 10 seconds. warning

Pairing

Red LED blinks for 10 seconds after pressing the Connect button.

Pairing failed After pressing the Connect button, the LED blinks, then lights solid for 10 seconds.

Paired

After pressing the Connect button, the LED

successfully blinks for 10 seconds, then turns off.

Cleaning your keyboard
· Wipe the keyboard with a damp, lint-free cloth.
Specifications
Keyboard: · Dimension (L×W×H): 17.1 × 5.6 × .8 in. (43.4 × 14.3 × 2.06 cm) · Weight: 16.9 oz. (.5 kg) · Radio frequency: 2.4Ghz · Operating distance: 33 feet (10 meters) · Key number: 104 keys (US) · Battery: 2 × AAA alkaline batteries · Battery life: 6 months (based on average usage) Nano receiver: · Dimension (L×W×H): .7 x .6 x .2 in. (1.8 × 1.4 × .6 cm) · Weight: .04 oz. (.001 kg) · Interface: USB 1.1, 2.0 , 3.0
Troubleshooting
My keyboard is not working. · Move your keyboard closer to your computer. · Make sure that your computer meets the system requirements. · If your keyboard stops working:
· Make sure that your keyboard and nano receiver are paired by pressing the connect button on the keyboard.
· Replace the keyboard batteries. · Try connecting your nano receiver into a different USB port on your
computer.

Legal notices
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RSS-Gen and RSS-210 statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. RSS-102 statement This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme à l’exposition aux rayonnements Industry Canada limites établies pour un environnement non contrôlé.

One-year limited warranty
For complete warranty, visit www.insigniaproducts.com.

Contact Insignia
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) www.insigniaproducts.com

INSIGNIA is a trademark of Best Buy and its affiliated companies. Registered in some countries.

Distributed by Best Buy Purchasing, LLC

7601 Penn Ave South, Richfield, MN 55423 U.S.A.

©2014 Best Buy. All rights reserved. Made in China

V4 ENGLISH 14-1345
