PHASE SHEFTER
LETH ARCY
Lethargy derives from the Greek word for forgetfulness, “Lethe”. It is a state of being drowsy and dull. The feeling of having little energy or of being unable or unwilling to do anything.
SPECIFICATIONS
– Buffered CMOS Bypass
– Mono TS 6,4mm jacks (unbalanced )
– Works with 9VDC center pin negative power supply
– Current draw: 65mA
– Dimensions: 14x10x5 cm
– Weight: 0,525 kg
A FEW PRESETS JUST TO START WITH LETH ARCY.
CASUAL PHASE SHIFT EFFECT
Adjust Rate as desired.
HEAVY S. SLOW PHASE SHIFT
Adjust Rate as desired. Manage Feedback at hot inputs
PITCH VIBRATO
Adjust Rate as desired
FM MODULATOR
Set Rate so as to match your base note. You can also use the triangle waveform
FIXED PHASE DEGREES
Adjust feedback to add color, and set Manual to desired degrees
EXTREME SHIFTING
Play around with different Rates
RHYTHMIC PHASING
ISO amount will determine each beat’s color. Adjust Rate as desired
