Serenelife Slgz48 2-wheel Golf Push Cart User Manual

SLGZ48 2-Wheel Golf Push Cart

Product Information

Product Usage Instructions

Assembly Steps

1. Pull the handle up and press the button to insert the rear
   wheels until you hear a ‘Click’ sound (refer to Fig.1)
2. Insert the front wheel into the trolley (refer to Fig.3 and
   Fig.4)

Note: The trolley is completely assembled when
all the steps are completed (refer to Fig.3).

Folding Step

To fold the cart, press the red button and fold it in the
direction of the arrow (refer to Fig.5). The folded position is
shown in Fig.6.

Swivel Front Wheel System

The front wheel can swivel 360 degrees when the handle brake is
pulled down (refer to Fig.7). When the handle brake is pulled up,
the front wheel will run in a straight line.

Using the Brake

To stop the rear wheel, push on the brake pedal. Pull off the
brake pedal to release the brake (refer to Fig.8 and Fig.9).

Using the Basket

Refer to the provided image for instructions on how to use the
basket.

Front Wheel Adjustable System

Note: The following instructions are based on
facing the cart.

• If the cart veers to the right:
  1. Use the Allen wrench/key to loosen the 2 screws (A) on the
     backside of the front wheel frame (refer to Fig.13).
  2. Adjust the front wheel to the center position by turning the
     screw (B) counterclockwise (refer to Fig.14).
  3. Tighten the 2 screws (A) after aligning the front wheel.
• If the cart veers to the left:
  1. Use the Allen wrench/key to loosen the 2 screws (A) on the
     backside of the front wheel frame (refer to Fig.13).
  2. Adjust the front wheel to the center position by turning the
     screw (B) clockwise (refer to Fig.14).
  3. Tighten the 2 screws (A) after aligning the front wheel.

SLGZ48
Foldable 3-Wheel Golf Push Cart
New Deluxe Scorecard Holder, Upper & Lower Brackets with Elastic Strap
Includes Cup Holder, Scorecard Holder, and Patented Bag Holder

WARNING:
· For your own safety, please read and understand these
warnings and keep this user guide for future reference.
· Always make sure the trolley is fully extended and locked
before use. Always make sure the trolley is folded and locked properly before lifting or transporting.
· Do not run while using this product. · Do not use accessories other than those designed for use
with this trolley.
· Keep all packing materials away from children and recycle
where possible or where required by law.
MAINTENANCE
· To clean the trolley, wipe with a soft, dry cloth. · Car polish may be used to maintain finish. · Lubricate moving parts every 6 months.
WARNING:
· Keep hands and fingers away from moving or sliding parts! · Always keep control of the buggy – Do not let it run down hills
without full control.
2 www.SereneLifeHome.com

PARTS LIST

A PVC handle B Umbrella holder base C Scorecard holder D Handle tube

X Bottom bracket bag

Y Push button system

Z Strap

Z1 Hook

B

E Umbrella holder storage rack

F Upper bag holder bracket

G Joint

F

H Connecting rods

I Main upper frame tube

J Leg bracket

G

K 2 holes leg frame

H

K1 4 holes leg frame

L Anti-splay wire

M Weight stabilizer

OR

N Right wheel locking mechanism

O Left wheel locking mechanism

P Rear wheel assembly

Q Main lower frame tube

R Slippery connecting rods

S Adjustable bag elastic rope

T Lower bag holder bracket

U Front wheel assembly

S

V Adjustable handle mechanism

W Handle brake for front wheel swivel

A W
C E
D

I

J

K

P

M K1

L Q
N T
U

X
Y V
Z Z1

www.SereneLifeHome.com 3

ASSEMBLY STEPS Fig.1

Button

Fig.3

Fig.4

Fig.2

Pull the handle up Press the button and insert until you hear the the rear wheels as in Fig.2 cart ‘Click’ as in Fig.1

FOLDING STEP

Press the red button and fold the cart in the direction of the arrow as in Fig.5

Fig.5

Insert the front wheel as in Completely assembled

Fig.3

trolley as Fig.4.

Fig.6 shows the folded position

Fig.6

4 www.SereneLifeHome.com

SWIVEL FRONT WHEEL SYSTEM The front wheel can 360 swivel when the handle brake pull down as Fig.7, and the handle brake is pull up, the front wheel will run straight line.
Fig.7
USING THE BASKET

USE THE BRAKE

Fig.8

Fig.9

Push on the brake pedal to stop the rear wheel and pull off to release as in Fig.8 and 9.

8

7

7

8

54

36

1 2
Point 1, First step: Fixed the velcro strap on the connecting rod, upper the plastic.
Check the two sides elastic strap the
same length.

1
2
6 3 4 5

www.SereneLifeHome.com 5

Point 2, Fixed the second velcro strap on the lower connecting rod, and only fix the velcro, so it can slide down and up when folding, do not fixed tightly, otherwise, it will affect folding the trolley.

Point 3 & 4, Fixed velcro strap on the 2 holes leg frame, then pull the elastic strap and click into Point 5 & 6 on the 2 holes leg frame.

Point 7 & 8, Click the elastic strap under the scorecard holder and check the elastic strap if the same.

6 www.SereneLifeHome.com

FRONT WHEEL ADJUSTABLE SYSTEM

Fig.12

B

Fig.11

Left

Right

Allen wrench/key

A Fig.13

Fig.14

WHEN FACING THE CART: If the cart veers to RIGHT: Use the Allen wrench (as shown in Fig. 12) to lose the 2 screws (A) on the backside of the front wheel frame as shown in Fig. 13. Then adjust the front wheel to center position by turning the screw (B) counterclockwise as in Fig. 14. Tighten the 2 Screws (A) after the front wheel alignment is done.

If the cart veers to LEFT: Use the Allen wrench (as shown in Fig. 12) to lose the 2 screws (A) on the backside of the front wheel frame as shown in Fig. 13. Then adjust the front wheel to center position by turning the screw (B) clockwise as in Fig. 14. Tighten the 2 Screws (A) after the front wheel alignment is done.

www.SereneLifeHome.com 7

FEATURES:
· 3-Wheel AI Frame Trolley · New Deluxe Scorecard Holder · Includes Foot Brake for Rear Wheel · With Handle Brake to Control 360° Swivel for Front Wheel · Upper and Lower Bracket with Elastic Strap · TPE Handle Grip · Push Button System · Ergonomic Padded Adjustable Handle · Includes Cup Holder, Scorecard Holder, and Patented Bag Holder · Simple Quick Braking System · Convenient Storage and Cooler · EZ Fold Mechanism · Durable and Compact Size for Easy Storage and Transportation · Easy to Fold and Unfold · Designed for Multiple Pushing Positions · Umbrella Holder Not Included · * Assembly Needed
8 www.SereneLifeHome.com

WHAT’S IN THE BOX:
· (1) 3-Wheel Golf Push Cart
TECHNICAL SPECS:
· Construction Material: Aluminum Frame · Max. Load Capacity: 33 lbs. · Front Wheel Size: 9.5” -inches · Rear Wheels Size: 11.5” -inches · Folded Product Dimension (L x W x H): 19.1” x 14.6” x 22.8” -inches · Unfolded Product Dimension (L x W x H): 44.7” x 28” x 47.8” -inches
Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: [email protected]
