Otto Lightweight and Compact Stroller
Product Information
The product is the Otto stroller, model EC102, manufactured by
Edwards & Co.
Key Features:
- Suitable for children from 0kg to 20kg
- Independently safety tested for compliance with the Australian
and New Zealand Standard AS/NZS 2088:2013
Product Usage Instructions
Using the Otto Stroller
To use the Otto stroller, follow these steps:
- Unpack the contents of the box (refer to “What’s in the box”
section for details). - Attach the front wheels (refer to “Attaching the front wheels”
section). - Attach the rear wheels (refer to “Attaching the rear wheels”
section). - To unfold the stroller, follow the instructions provided in the
“Unfolding the stroller” section. - When not in use, fold the stroller using the steps outlined in
the “Folding the stroller” section.
Adjusting Seat and Harness
To adjust the seat and harness, follow these steps:
- Recline the seat using the instructions given in the “Reclining
the seat” section. - Adjust the footrest as needed (refer to “Adjusting the
footrest” section). - Use the harness buckle to secure your child in the stroller
(refer to “Using the harness buckle” section). - Adjust the shoulder strap height to ensure a proper fit (refer
to “Adjusting the shoulder strap height” section). - Adjust the harness straps to fit your child securely (refer to
“Adjusting the harness straps” section).
Additional Features and Maintenance
The Otto stroller also includes additional features such as a
parking brake and front wheel swivel lock. Instructions on how to
use these features can be found in the respective sections of the
user manual.
To care for and maintain your stroller, follow the guidelines
provided in the “How to care for and maintain your stroller” and
“How to service your stroller” sections.
It is recommended to inspect your stroller at least once a month
and service it at least once every 6 months.
Use + Care Guide
Otto
EC102
NZ AU
OTTO – USE + CARE GUIDE
IMPORTANT
· Keep these instructions for future reference. · Always follow the manufacturer’s instructions. · Read all instructions carefully before assembly and use of this stroller. · Check that all items are present and undamaged. · The correct use and maintenance of this product is essential.
Suitable for children from 0kg to 20kg
Independently safety tested for compliance with the Australian and New Zealand Standard AS/NZS 2088:2013
2
OTTO – USE + CARE GUIDE
Welcome
Thank you for choosing Edwards & Co; your family is now part of ours.
Edwards & Co started from humble beginnings in 2014 and has grown to include a team of people dedicated to bringing you the best for your baby. Our products are designed to impress, designed to last and designed to change. More importantly, they’re designed for real-life families. No gimmicks, just good quality products with useful, easy to use features. Otto is our compact stroller and, in true Edwards & Co fashion, isn’t designed with unnecessary frills and features. This makes it a lot easier for Grandparents and other caregivers to handle giving you a break in the meantime! To make sure you get the most out of Otto, please refer to this Use & Care guide when using your stroller. Because Otto will be your stroller for years to come, we hope to hear from you along the way, so feel free to contact us via any of the channels below if you’d like to get in touch. We’re so glad you came along for the ride. From the team at Edwards & Co.
EDWARDSANDCOBABY.COM
3
OTTO – USE + CARE GUIDE
Contents
Welcome
3
Warnings: Australia/New Zealand
5
General warnings and safety precautions
6
What’s in the box
8
Otto stroller components
9
Using the Otto stroller
10
Attaching the front wheels
11
Attaching the rear wheels
11
Removing the front wheels
12
Removing the rear wheels
12
Unfolding the stroller
13
Folding the stroller
14
Reclining the seat
16
Adjusting the footrest
16
Using the harness buckle
17
Adjusting the shoulder strap height
18
Adjusting the harness straps
19
Using the parking brake
20
Using the front wheel swivel lock
21
Carrying the stroller
22
How to care for and maintain your stroller
23
How to service your stroller
25
Inspect your stroller at least once a month
25
Service your stroller at least once every 6 months
26
WARRANTY
27
4
OTTO – USE + CARE GUIDE
WARNINGS Australia/New Zealand
TO AVOID INJURY OR DEATH
ALWAYS APPLY THE BRAKES WHEN THE STROLLER IS STATIONARY. DO NOT LEAVE CHILDREN UNATTENDED. SECURE THE CHILD IN THE HARNESS AT ALL TIMES. DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER. MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU ADJUST THIS STROLLER. USE THE HARNESS AT ALL TIMES. USE THE STRAP TO STOP THE STROLLER ROLLING AWAY.
5
OTTO – USE + CARE GUIDE
General warnings and safety precautions
TO AVOID INJURY OR DEATH
Maximum weight limits
Child using this stroller: 20kg Capacity of the storage basket: 2kg Capacity of the canopy pocket: 1kg
Minimum age limits
The stroller is suitable for a child from newborn.
Releasing a child quickly in an emergency
Make sure the buckle is easy to access. It is important that your child can be released quickly in an emergency.
Keeping fingers away from moving parts
Take care of fingers and NEVER let a child fold or unfold the stroller. Fingers may jam in moving parts when folding or unfolding the stroller.
Do not use the stroller as a substitute baby cot or bed
The stroller is only designed to transport children safely. The stroller is not a baby cot or bed.
Using the harness safely
To avoid serious injury, always use the safety harness when your child is in the stroller. Always adjust the straps to fit firmly to your child’s body size. A loose restraint or harness is DANGEROUS.
Never leave a harness connected when not fitted to a child in the stroller. The harness can form loops which may be a strangulation hazard.
Keeping the stroller stable
Do not place or attach weight on the handle or side of the stroller. Doing so may make the stroller’s frame unstable. Only use approved Edwards & Co accessories.
6
OTTO – USE + CARE GUIDE
Using the stroller on surfaces
Do not use this stroller on escalators, or on moving or mechanical conveyer belts. Always take your child out of the stroller when on stairs. This stroller is designed for use on flat and gentle sloping surfaces. Take care on higher sloping or uneven surfaces. These surfaces increase the risk of the stroller tipping.
Using the stroller on sand and near or in salt water
Store your stroller in a sheltered dry place and avoid beach use. Salt water or excessive moisture may cause corrosion on the fastenings and moving parts of this stroller. The manufacturer’s warranty does not cover corrosion caused by environmental factors such as salt water or sand. Never rinse the frame, wheels or housings with water. Water and/or debris can interfere with the internal mechanisms, including the brakes and damage your stroller.
Keeping the stroller away from fire and extreme heat
Do not store the stroller in areas where high temperatures may occur. Examples are a roof space, or beside shed walls that can get hot.
Approved accessories
Only use accessories approved by Edwards & Co.
7
OTTO – USE + CARE GUIDE
What’s in the box
Note: Check that all items are present and undamaged.
Use + Care Guide (this instruction manual)
2 x Rear Wheels
2 x Front Wheels
1 x Stroller Frame with Seat Unit and Canopy attached
1 x Travel Bag
8
OTTO – USE + CARE GUIDE
Otto stroller components
Folding Trigger
Shoulder Pads Harness Buckle
Storage Basket Front Wheel Release Button Swivel Lock Lever
Handle Bar Sun Canopy
Fold Lock Latch
Harness Straps Stroller Frame
Footrest
Brake Pedal Rear Wheel Fold Lock Catch
Rear Wheel Release Button
9
OTTO – USE + CARE GUIDE
Using the Otto Stroller
10
OTTO – USE + CARE GUIDE
Attaching the front wheels
1 . Locate the metal pin on the front wheel. Insert this into the front wheel housing on the stroller frame.
2 . Once installed, pull the wheel to confirm a secure connection.
You will hear a click when the wheel connects correctly.
Attaching the rear wheels
1 . Locate the metal pin on the rear wheel. Insert this into the rear wheel housing on the stroller axle.
You will hear a click when the wheel connects correctly.
2 . Once installed, pull the wheel to confirm a secure connection.
11
OTTO – USE + CARE GUIDE
Removing the front wheels
1 . Press the metal wheel release button located on the inner side of the front wheel housing.
2 . Pull the wheel downwards.
Inner side
Removing the rear wheels
1 . Press the wheel release button located under the rear wheel axle, alongside each rear wheel.
2 . Pull the wheel outwards.
12
OTTO – USE + CARE GUIDE
Unfolding the stroller
1 . Stand the folded stroller upright with the wheels on the ground and the storage basket closest to you.
2 . Locate the fold lock latch on the left side of the stroller frame. Lift this away from the catch.
3 . Pull the handle of the stroller upwards and back towards you.
4 . Move the stroller so the front wheels extend forward and the stroller frame clicks into place.
You will feel the stroller frame lock into place.
13
OTTO – USE + CARE GUIDE
Folding the stroller
Note: To fold the stroller, ensure the seat is in the most upright position, the
footrest is level and the canopy is closed.
1 . Engage the brake by pushing the red brake pedal down, towards you. Ensure the brake has locked both rear wheels. Push the stroller a little to make sure the brake is engaged.
2 . Locate the sliding fold trigger on the handlebar.
14
OTTO – USE + CARE GUIDE
3 . Press to release the trigger lock, slide the folding trigger to the right and simultaneously rotate the handle tubing downwards, towards the floor.
4 . Lower the handlebar towards the floor.
5 . Fold the seat-back forwards over the seat pad.
6 . Hold the bar crossing the storage basket and use this to pull the stroller backwards towards you.
7. The stroller will collapse into a folded unit. Ensure the fold lock latch on the left side of the stroller’s frame locks into place.
When the fold lock is in place, the stroller will not unfold when you carry it.
15
OTTO – USE + CARE GUIDE
Reclining the seat
1 . Locate the plastic toggle on the webbing strap at the rear of the seat.
2 . Press the button on the toggle and move this along the webbing strap to raise or lower the seat back into the desired position.
Adusting the footrest
1 . Locate the two circular buttons on the underside of the footrest.
2 . Press both buttons and simultaneously raise or lower the footrest to the desired position.
16
OTTO – USE + CARE GUIDE
Using the harness buckle
Locking the buckle
1 . Insert one harness tongue into the
2 . Repeat step one for each of the
harness buckle until you hear a click.
remaining three harness tongues.
Unlocking the buckle
1 . Push the button at the centre of the buckle.
2 . Remove the four harness tongues.
17
OTTO – USE + CARE GUIDE
Adjusting the shoulder strap height
Note: There are four height positions for the shoulder straps. As your child
grows, it is necessary to move the shoulder straps according to your child’s height. The shoulder straps should be positioned at about level or just above your child’s shoulders.
1 . Locate the black plastic harness plate at the rear of the seat back.
2 . Twist this and insert it through the slot in the seat back to the front of the seat.
3 . Locate the shoulder strap slot at the desired height.
4 3 2 1
4 . Insert the harness plate through this slot to the rear of the seat back. Ensure the harness plate sits flat against the rear of the stroller back.
5 . Repeat this for second shoulder strap.
18
OTTO – USE + CARE GUIDE
Adjusting the harness straps
Note: The harness should be firm but not too tight around your child.
It is adjusted correctly when you can fit two of your fingers between the harness and your child.
WARNING: Never leave a harness connected when not fitted to a child in the
stroller. A connected harness can form loops which may be a strangulation hazard.
Adjusting the hip and shoulder straps
1 . Pull the webbing straps through the toggle on the hip or shoulder straps and adjust to the desired length.
Loosen
Tighten
Adjusting the harness buckle strap
1 . Pull the webbing straps through the toggle on the harness buckle strap and adjust to the desired length.
Correct fit for harness
19
OTTO – USE + CARE GUIDE
Using the parking brake
Engaging the parking brake
1 . Push the red brake pedal down with your foot, towards you.
2 . Ensure the brake has locked both rear wheels. Push the stroller a little to make sure the brake is engaged and working.
Releasing the parking brake
1 . Push the red brake pedal down with your foot, away from you.
2 . Ensure the brake has unlocked both rear wheels.
20
OTTO – USE + CARE GUIDE
Using the front wheel swivel lock
Note: The swivel locks are used to lock the front wheels into position or to
release the front wheels to enable them to swivel freely.
Engaging the front wheel swivel lock
1 . Locate the swivel locks on the front wheel housing.
2 . Slide the black lock lever downwards on both front wheels.
3 . Swivel the front wheels until you hear the lock click into place.
4 . Push the stroller a little to make sure the front wheels are locked into position.
21
OTTO – USE + CARE GUIDE
Unlocking the front wheel swivel lock
1 . Slide the black lock lever upwards on both front wheels.
Carrying the stroller
1 . Hold the stroller by the bar positioned across the top of the stroller when folded. Check the fold lock latch is secure before you lift or carry the stroller.
22
OTTO – USE + CARE GUIDE
How to care for and maintain your stroller
Store your stroller and accessories carefully
Store inside in a well-ventilated, dry area. Do not store in a damp environment that is not well insulated (such as an unfinished basement or outdoor shed). Store when dry, not damp or wet. Store away from direct sunlight. Direct sunlight could cause fabric fading or damage. Store away from carpet. Rubber on the wheels could leave marks on carpet. Do not place heavy objects on top of your stroller or accessories. NEVER allow your stroller to come into contact with corrosive substances. Examples are battery acid or petroleum products. Corrosion is not covered under our warranty – see the Warranty in this Instruction Manual.
Clean your stroller carefully
Use a damp cloth to clean the seat fabric and/or sun canopy. To dampen a cloth, dip the cloth in a small amount of mild detergent (such as laundry liquid). NEVER fully soak the cloth in water. NEVER clean any part of the stroller with abrasive, ammonia-based, bleach-based or spirit-based cleaners. See care labels for specific instructions regarding machine washing.
Dry your stroller carefully
Dry the stroller thoroughly before storing it. NEVER tumble dry any part of the stroller. NEVER wring any stroller fabrics.
Replace damaged or worn wheels immediately
Stop using the stroller if any wheel becomes damaged or worn. Replace it immediately.
23
OTTO – USE + CARE GUIDE
Check regularly for wear and tear
Check regularly for wear and tear on all stroller parts.
Get your stroller inspected regularly
Get your stroller inspected regularly to maintain it. Regular inspection ensures the locking devices are working correctly and essential components are secure. Please read How to service your stroller in this Instruction Manual.
Use your stroller in sunlight for short periods
Always park your stroller in a shaded area. Only use your stroller in direct sunlight for short periods. This will help reduce fabric fading and damage.
Read our Servicing Guide before using the stroller on the beach or near salt water
If you live within 3kms of the sea, take extra care to park/store your stroller indoors and away from wind. Salt water carries in strong winds and is extremely corrosive. Do not use your stroller on the beach. Salt and moisture can damage moving parts. Even salty atmospheric conditions can affect the stroller’s mechanisms. If you use your stroller in coastal areas, please read How to service your stroller in this Use & Care Guide.
24
OTTO – USE + CARE GUIDE
How to service your stroller
Just like your car, regular service extends the life of your Edwards & Co stroller.
Inspect your stroller at least once a month
We recommend that you fully inspect your stroller at least once a month. Here are some helpful tips to inspect your stroller at home. Inspect all the rivets and screws that connect your stroller together · Make sure all rivets and screws are clean, tight and secure. · If corrosion is forming on any rivet or screw: Wipe the rivet or screw with a
damp cloth. Leave the rivet or screw to dry overnight. Spray a rag with some WD-40. This applies an extra coating over the rivets and screws to help protect against corrosion. Inspect the wheels · Remove the front and back wheels. · Wipe the wheels with a clean rag to remove any dirt, sand or other debris. · Wipe out the wheel housing. · Rear wheels only: Spray the wheel pins with some WD-40. Spraying will help to keep the wheel release mechanism operating smoothly. Inspect the fold joints · Make sure the fold joints are free of dirt and debris. · Wipe the fold joints clean with a damp cloth. · Clean the fold joints when the stroller frame is folded. · Apply some WD-40 or silicone spray (available at Bunnings, Mitre 10 or your local supermarket) to the moving hinges.
25
OTTO – USE + CARE GUIDE
Inspect the metal components to help prevent rust · Rinse the frame, wheels and housing with fresh water after the stroller has been:
· on a beach · in the rain · in windy and exposed areas. · If you live or use the stroller within 3kms of the beach or sea: Spray a rag with WD-40 and wipe down all screws and rivets. This applies an extra coating over the rivets and screws to help protect against corrosion. Repeat this process monthly.
WARNING: Do not use the stroller on the beach. Sand and salt will
interfere with moving parts.
Service your stroller at least once every 6 months
We recommend you get your stroller serviced at least once every 6 months. To get your stroller serviced, contact us at [email protected] Our customer service team will offer assistance or make an appointment for you to visit our service team at our main office in Silverdale, Auckland. We also host service days at retailers throughout New Zealand multiple times a year. You will find the list of service days on our Events page: edwardsandco.nz/pages/events
26
OTTO – USE + CARE GUIDE
Warranty
All Edwards & Co products are guaranteed for two years from the date of shipping against defects in material and workmanship.
If we determine that the product has a manufacturing fault, we will repair or replace it free of charge to you. The decision to repair or replace is solely at the discretion of Edwards & Co Proof of purchase must be provided.
The warranty is “return to base” and not a free in-home service. This means the customer is responsible for any inwards freight charge to return the product to an Edwards & Co representative for warranty or service.
Our warranty excludes claims resulting from misuse, abnormal use, overloading, general wear and tear (including scratches), child outgrowing the product, not following instructions, transportation damage (including airline or freight damage), poorly maintained product, dropped goods, negligence, second-hand product, modified product, colour fading, over inflation, mould, damage to handle foam in use or fabric cuts and tears. Our warranty also does not cover tyre punctures or corrosion to frames or fasteners as a result of atmospheric or environmental conditions.
Any replacement will not give the right for the warranty period to be extended.
Edwards & Co does not cover warranty if the product has been purchased second hand or from an unauthorised reseller.
For the complete terms and conditions of our warranty, please visit our website — edwardsandco.nz/pages/warranty
Edwards & Co New Zealand
Edwards & Co Australia
Unit 5 30 Foundry Road Silverdale 0932 NEW ZEALAND
C/O – G&S Logistics Unit 1, 96-112 Gow Street Padstow NSW 2211 AUSTRALIA
NZ: (09) 869 8950
AU: (02) 9066 6702
27
Designed with love
Watch helpful instructional videos
youtube.com/c/EdwardsCo
Come along on the journey
@edwardsandcobaby
Visit our comprehensive support centre online edwardsandcobaby.zendesk.com/hc/en-us
EDWARDSANDCOBABY.COM
Events | Edwards and Co
Baby products designed by parents with love | Edwards and Co
Edwards & Co (@edwardsandcobaby) • Instagram photos and videos
