QUICK REFERENCE GUIDE > DD60DI9
Integrated Double
DishDrawer™ Dishwasher
Series 9 | Integrated
Panel Ready
Integrating into your kitchen design seamlessly, each drawer fits a half load that you can load and wash independently.
- Knock to pause function is perfect if you miss a dish
- Six wash programs, as well as additional Quick wash, Sanitise and Extra Dry options
- Customize with your own front panel and handle to match your kitchen cabinetry
DIMENSIONS
| Height | 820 – 880mm |
| Width | 599mm |
| Depth | 571mm |
SPECIFICATIONS
Accessories
| Contemporary round handle | Part number 81645 |
| Contemporary square fine | Part number 82099 |
| Contemporary square handle | Part number 81794 |
| Cutlery basket | • |
| Kickstrip | • |
| Knife clip and multipurpose | • |
| Optional stainless steel door kit | 81253 |
Capacity and loading
| Accommodates round plates | 280mm |
| Adjustable height, foldable | • |
| Fold down tines | • |
| Pitch adjustable tines | • |
| Place settings | 14 |
Consumption
| Energy rating | 2 ticks |
| Energy usage | 136kWh/year |
| Water rating | 2 ticks |
| Water usage (per wash cycle) | 1.2L/place setting |
Controls
| Child lock | • |
| Electronic fault/Diagnostic | • |
| End of cycle beeps | • |
| Energy saving delay start | • |
| Internal wash selector | • |
| Knock to pause | • |
| Rinse aid indicator light | • |
Features
| Fan assisted drying | • |
| Flow through detergent | • |
| Quiet operation | • |
| SmartDrive™ technology | • |
| Noise on standard cycle top | 43dBA |
Power requirements
| Amperage | 8.5A |
Product dimensions
| Depth | 571mm |
| Height | 820 – 880mm |
| Width | 599mm |
Warranty
| Parts and labour | 2 years |
Wash Program Modifiers
| Extra Dry | • |
| Quick | • |
| Sanitise | • |
| Wash modifiers | 3 |
Wash Programs
| Delicate | • |
| Eco | • |
| Fast | • |
| Heavy | • |
| Medium | • |
| Rinse | • |
| Wash programs | 6 |
| SKU | 82367 |
The product dimensions and specifications in this page apply to the specific product and model. Under our policy of continuous improvement, these dimensions and specifications may change at any time. You should therefore check with Fisher & Paykel’s Customer Care Centre to ensure this page correctly describes the model currently available. ? Fisher & Paykel Appliances Ltd 2020
