JH-211 Bluetooth Audio Receiver

Product Information

The SIMOLIO JH-211 is a long-range, low latency Bluetooth audio
receiver. It supports various codecs such as SBC, aptX, aptX HD,
and aptX Low Latency. The receiver comes with multiple audio output
options including AUX and optical. It also features EQ modes for
different audio experiences and volume control buttons.

Package Contents

Simolio Bluetooth Optical Cable *1
Receiver *1
RCA Audio Cable *1
3.5mm AUX Audio Cable *1
Micro USB Charging Cable *1
User Instruction *1

Buttons and Functions

Button	Function
ON/OFF	Turn on the receiver (Switch off the receiver)
PAIR Button (MFB)	Enter pairing mode (Exit pairing mode)
EQ Switch	Select EQ mode (MUSIC, DIALOGUE, NORMAL)
VOL+	Volume up (Next track)
VOL-	Volume down (Previous track)

LED Indications

Flashes blue every few seconds: Bluetooth status indicator
Flashes red and blue alternately: Pairing mode
Turns solid blue: Bluetooth connected
Turns solid white: Optical, AUX, SBC, FS, aptX, LL, HD,
DIALOGUE, MUSIC, NORMAL codecs

Product Usage Instructions

Connect the SIMOLIO JH-211 Bluetooth receiver to your power
source using the included micro USB charging cable.
Turn on the receiver by sliding the ON/OFF switch to the ON
position.
To pair your Bluetooth device with the receiver, press and hold
the PAIR button for 3 seconds until the LED flashes red and blue
alternately. Then, select the receiver from your device’s Bluetooth
settings.
Once connected, you can play/pause audio by pressing the PAIR
button once.
To adjust the volume, use the VOL+ and VOL- buttons. Short
press VOL+ to turn up the volume and short press VOL- to turn down
the volume. You can also press and hold VOL+ for 2 seconds to skip
to the next track or press and hold VOL- for 2 seconds to go to the
previous track.
To select different EQ modes, press the EQ switch. Press it
once to select MUSIC mode for richer, more lively music streaming.
Press it again to select DIALOGUE mode for boosted dialogue clarity
in TV programs and films. Press it once more to select NORMAL mode
for well-balanced sound.
If you want to disconnect a paired device, simply press the
PAIR button twice in a row.

For any further assistance or inquiries, please contact SIMOLIO
customer service at [email protected] (NA/AU) or
[email protected] (UK). The average response time is 2-24
hours, excluding holidays.

View Fullscreen

Support Email: [email protected] (NA/AU) [email protected] (UK)

Long Range Low Latency Bluetooth Audio Receiver
MODEL: JH-211

PAIR

AUXOPT

SBC APTX
HD

NORMMUADSLIAICLOGUE

VOL+

O N

User Manual
Support Email: [email protected] (NA/AU) [email protected] (UK)

JH-211
Thank you for purchasing SIMOLIO JH-211 Bluetooth receiver. Please read this manual carefully before setup and keep it safe for future reference. For any questions, please contact SIMOLIO customer service at:
[email protected] (NA/AU) [email protected] (UK)
Response Time: 2-24h, excl. Holidays

AptX@ Low Latency and aptX@ HD
To take full advantage of the aptX Low Latency and/or aptX HD codec, the paired devices must support the aptX Low Latency and/or aptX HD codec as well. If the paired devices support only standard aptX or SBC, Simolio Bluetooth receiver would default to aptX or SBC codecs. Audio delay with different paired devices:

Paired devices supported codec aptX Low Latency codec aptX codec SBC codec(with most standard Bluetooth audio devices on the market)

The audio delay will be 40ms 70ms 220ms

JH-211
Table of Contents
1. Product Diagram …………………………………………………………………………………………. 01 2. Packaging Contents …………………………………………………………………………………….. 01 3. Buttons and Functions ………………………………………………………………………………….. 02 4. LED Indications ………………………………………………………………………………………….. 03 5. Power and Turn on Simolio JH-211 Bluetooth Receiver ………….. ……………………………. 03 6. Connect Simolio JH-211 Bluetooth Receiver to Bluetooth-enabled Device ………………….. 05 7. Disconnect and Reconnect ……………………………………………………………………………. 05 8. How to Clear Pairing History ………………………………………………………………………….. 06 9. Troubleshooting …………………………………………………………………………………………. 06 10. Product Specifications ………………………………………………………………………………. 08 11. Limited Warranty ………………………………………………………………………………………. 08

JH-211

O N O N OFF

1. Product Diagram

-ON/OFF Switch

-POWER IN

-OPTICAL

Output to Speaker

-AUX

Output to Speaker

-ANTENNA

POWER IN DC 5V

OUTPUT TO SPEAKER AUX

OPTICAL

2. Packaging Contents

OPT

SBC

DIALOGUE

AUX

APTX

MUSIC

NORMAL

PAIR

VOL+

Simolio Bluetooth Optical Cable *1 Receiver *1

RCA Audio Cable *1

3.5mm AUX Audio Cable *1

PAIR

OPT AUX

SBC APTX
HD

MUDSIAICLOGUE

NORMAL

VOL+

-PAIR (BT Button/MFB Button)
– EQ Switch -VOL+
-VOL-
-Bluetooth Status Indicator
-Audio Connection Indicators -Codec Indicators 3 -EQ Mode Indicators

Micro USB Charging Cable *1

User Instruction*1

Long Range Low Latency Bluetooth Audio Receiver
MODEL: JH-211

OPT

SBC

AUX

APTX

PAIR

HD EQ

FS LL

DIALOGUE MUSIC

NORMAL

VOL+

VOL-

User Manual

Sales & Support Email: [email protected] (NA/AU) [email protected] (UK)

JH-211

3. Buttons and Functions

Button

Function

ON/OFF Turn on the receiver Switch Turn off the receiver

PAIR Button (MFB)

Enter pairing mode Exit pairing mode

Operation Slide “ON/OFF” Switch to “ON” Slide “ON/OFF” Switch to “OFF” Press and hold the “PAIR” button for 3 seconds, then the receiver will enter pairing mode with RED and BLUE flashing alternately Press “PAIR” once when receiver is in pairing mode

EQ Switch
VOL+ VOL-

Play/Pause audio

Press the “PAIR” button once when connected

Disconnect paired device Short press the “PAIR” button twice in a row

For richer, more lively music streaming

Press “EQ” button to select “MUSIC” mode

For boosted dialogue clarity in TV programs and films,etc

Press “EQ” button to select “DIALOGUE” mode

For well-balanced sound

Press “EQ” button to select “NORMAL” mode

Volume UP

Short press “VOL+” to turn up volume

Next track

Press and hold “VOL+” for 2 seconds for next track

Volume DOWN Previous track

Short press “VOL-” to turn down volume Press and hold “VOL-” for 2 seconds for previous track

JH-211

4. LED Indications
LED Status ” ” flashes BLUE every few seconds ” ” flashes RED and BLUE alternately ” ” turns solid BLUE OPT LED turns solid white AUX LED turns solid white SBC LED turns solid white FS LED turns solid white aptX LED turns solid white LL LED turns solid white HD LED turns solid white DIALOGUE LED turns solid white MUSIC LED turns solid white NORMAL LED turns solid white

Status Indication No connection or disconnected In pairing mode Connected with Bluetooth audio device Working with optical connection Working with RCA/3.5mm AUX connection Connected using SBC codec
Connected using FS codec Connected using aptX codec Connected using aptX LL codec Connected using aptX HD codec DIALOGUE mode selected MUSIC mode selected NORMAL mode selected

5. Power and Turn on Simolio JH-211 Bluetooth Receiver Step 1: Connect Simolio JH-211 Bluetooth receiver to a power source using the supplied USB
cable.(Ref. Fig1)
03

JH-211

POWER IN DC 5V

OUTPUT TO SPEAKER AUX

Speaker AUX Input

Speaker RCA Input

Speaker OPTICAL
Input

OPTICAL

USB port on a PC/ a 5V/1A power adapter
Fig 1

USB cable

Option A AUX cable
Option B RCA cable
Option C Optical cable Fig 2

Step 2: Connect your speaker to Simolio JH-211 Bluetooth receiver using one of the three audio cables provided (optical/RCA/3.5mm AUX). (Ref. Fig 2)
Step 3: Switch the “ON/OFF” switch to “ON” position. You will hear “Power on” from your speaker. Please note: The receiver will automatically power off if there is no connection for 10 minutes.
To use it again, switch the receiver off first, and then on again.

JH-211

6. Connect Simolio JH-211 Bluetooth Receiver to Bluetooth-enabled Device

Step 1: Activate Bluetooth on your phone, PC, Tablet, etc. The following paths are popular: (Ref. Fig 3) iPhone: Settings>Bluetooth>Bluetooth: On; Andriod: Settings>Bluetooth: On>Scan for devices (Operation may vary slightly across devices. For more details, please refer to your device’s user manual)
Step 2: Select “Joan C” from the available devices on your phone, PC, Tablet, etc. (You may confirm the pairing status on your phone)
Step 3: Once successfully paired, you will hear “Connected”. The Bluetooth indicator will turn solid blue.

Joan C

JH-211

PAIR

OPT AUX

SBC APTX
HD

DIALOGUE

NORMMUASL IC

VOL+

O N

Fig 3

7. Disconnect and Reconnect
Disconnect To disconnect, you may either turn off Simolio Bluetooth receiver, or the Bluetooth on the transmitting device like cell phone, PC, etc…
Reconnect Turn it on again, and Simolio will automatically reconnect with last paired device. If not, please reboot the Simolio receiver.
To connect Simolio to a second transmitting device like phone, PC, iPad, etc, re-enter the Simolio into pairing mode by pressing and holding the “PAIR” button for 5 seconds until the RED and BLUE LED flashing alternately quickly.
05

JH-211

8. How to Clear Pairing History

To clear the pairing history of Simolio JH-211 Bluetooth receiver, please first disconnect your phone, PC, Tablet, etc. Then long press and hold the “PAIR” and “EQ” button simultaneously for 10 seconds until the Bluetooth indicator flashed out BLUE and RED alternatively with two beeps. After the pairing history is cleared, the receiver will automatically go into pairing status.
9. Troubleshooting

Phenomena Audio delay when watching TV Not working in HD codec
No sound

Causes
Bluetooth transmitting device is not aptX LL supported.
Bluetooth transmitting device is not aptX HD supported.

Solutions
Please make sure the Bluetooth transmitting device supports aptX LL codec. For certified device list, please go and check on www.aptx.com.
Please make sure the Bluetooth transmitting device supports aptX HD codec. For certified device list, please go and check on www.aptx.com.

Volume is zero or too low.

Turn up the volume.

Simolio is not set as the default playback device when Simolio is connected to PC.

Right click speaker icon on taskbar>playback devices>select Joan C and set as default.

The analog audio cable is plugged into the AUDIO IN jack of the receiver when connecting with the optical cable.

Unplug the analog audio cable from the receiver.

JH-211

Phenomena Not connected
Sound cuts in and out Receiver cannot be powered successfully

Causes
Either Simolio or Bluetooth transmitting device is not in pairing mode, or is connected to other device.
Short working range of Bluetooth transmitting device.
Unstable Bluetooth connection. Physical obstacles or wireless signal interference. Faulty USB cable.
Faulty Power source.

Solutions Turn off Bluetooth on other device, clear pairing history of Simolio receiver and your Bluetooth transmitting audio device, then repair.
Check by connecting to another phone, iPad, tablet, Bluetooth PC, etc… Check your Bluetooth transmitting deviceby pairing it to another Bluetooth headset.
Move Simolio receiver closer to your Bluetooth transmitting device. Please note that work range is decided by both devices on both ends. You may test the work range of your Bluetooth phone/ PC/tablet with another Bluetooth headset.
Reset Simolio and Bluetooth transmitting device like cell phone, PC, etc…/ Clear pairing history and repair.
Remove obstacles. Put Simolio receiver away from interference sources, including Router/ smart WiFi TV/ TV sticks/WiFi TV box…, if any.
Check by using another workable USB cable.
Check by using another power source like PC USB port, socket, different USB charger(5V/500mA-2A).

JH-211

10. Product Specifications

BT Version Supported Profiles Carrier frequency
Range
Audio Codec Supported Input Voltage

5.0 A2DP, AVRCP 2.4GHz ISM Up to 197ft line-of-sight in open air Up to 50-70ft indoors with no obstacles or interference SBCFSaptXaptX LLaptX HD
DC 5V 1A

11. Limited Warranty
Simolio offers a 12-month limited warranty for brand-new purchases from authorized sellers. The 12 month warranty will cover defects in manufacturing and product failure for a period of 12 months from the original date of purchase. The warranty period is not extended if we repair or replace a warranted product. This warranty is provided at the discretion of Simolio Ltd. And does not cover cosmetic damage or damage due to acts of nature, accident, misuse, abuse, negligence, commercial use, or modification of or to any part of the product. Accessories such as cables are not covered under this warranty. Please contact: [email protected] (for NA/AU) or [email protected] (for UK) and provide your Amazon order ID to register the warranty. Response Time: 2-24h, excl. Holidays
