Product Overview
The Elo 1715L 17-inch standard format touchscreen monitor is designed, developed and built to provide a space-saving and cost-effective touch solution. The 17-inch touchscreen monitor can function as a desktop or wall mounted unit and includes a VESA mounting option. The touchscreen is factory-sealed against dirt, dust, and liquids and with controls on the sid rather than the front, the touchscreen can be locked-out for public use.
Available with AccuTouch® five-wire resistive and IntelliTouch® surface acoustic wave (SAW) with an antiglare display and Dual/Serial USB
____________________________________________________________________________
Touchscreen sealed from
dirt, dust and liquid
___________________________________________________________________________
Removable base and VESA mounting option
1715L 17-inch LCD Desktop Touchmonitor
| Specifications | |
| Model | 1715L |
| Color | Dark gray |
| Active Display Area | 13.3″ x 10.6″ (338mm x 270mm) |
| Monitor Dimensions | 15.4″ x 14.4″ x 8.0″ (391mm x 366mm x 203mm) |
| LCD Technology | Active Matrix TFT LCD with LED backlighting |
| Diagonal Size | 17″ |
| Native Resolution | 1280 x 1024 |
| Other Supported Resolutions | 1280 x 1024 @ 60 or 75 Hz; 1280 x 960 @ 60 Hz; 1152 x 864 @ 75 Hz; 1024 x 768 @ 60, 65 Hz, 70 or 75 Hz; 832 x 624 @ 75 Hz; 800 x 600 @ 56, 60, 72 or 75 Hz; 720 x 400 @ 70 Hz; 720 x 350 @ 70 Hz; 640 x 480 @ 60, 66 Hz, 72 or 75 Hz |
| Number of Colors | 16.7 million |
| Number of Touches | Single-touch |
| Brightness (typical) | LCD panel: 250 nits; IntelliTouch: 225 nits; AccuTouch: 200 nits |
| Response Time – Total (typical) | 5 msec |
| Viewing Angle (from center) | Horizontal: ±85° or 170° total; Vertical: ±80° or 160° total |
| Contrast Ratio (typical) | 1000:1 |
|
Video | Input Connector: 15-pin female D-sub Sync Format: Separate H&V syncs, Composite sync, and Sync-On-Green Displayable horizontal scan frequency range: 31.5 – 80 KHz Displayable vertical scan (frame rate) frequency range: 56.3 – 75 Hz |
| Power | AC Input – Input Connector: IEC 60320 C6; Input voltage range: 100-240VAC 50/60Hz DC Input – Input Connector: Coaxial power jack (Barrel inner diameter: 6.4 +/- 0.3mm. Pin outer diameter: 2.0 +0.0 -0.1mm. Barrel depth: 8.8 +/- 0.3mm); Input Voltage range: 12V +/- 5% |
| Power Consumption (Typical): | Monitor only: ON: 10.52 W; SLEEP: 1.34 W; OFF: 0.46 W |
| Shipping Dimensions | 17.99″ x 11.42″ x 17.32″ (457mm x 290mm x 440mm) |
| Temperature | Operating: 32°F to 104°F (0°C to 40°C); Storage: -4°F to 122°F (-20°C to 60°C) |
| Humidity | Operating 20%–80%; Storage 10%–90% noncondensing |
| Weight | Actual: 15.2lb (6.9kg); Shipping: 21.2lb (9.6kg) |
| Regulatory Approvals and Declarations | UL, cUL , FCC, CE, UKCA, VCCI, IC, RCM |
| User’s Controls | Digital OSD. OSD buttons: menu, up, down, select, power; OSD: contrast, brightness, H/V position, RGB (color temp), clock, phase, recall, Language (English, German, Spanish, Japanese, French); OSD disable/enable: power, OSD menu |
| Mounting Options | Removable base, 100 mm VESA mount; threaded-through mounting holes under base |
| Warranty | 3 years |
|
Extended Warranty | 4 year warranty coverage – Elo P/N: E898247 5 year warranty coverage – Elo P/N: E898449 3 year warranty coverage + AUR – Elo P/N: E898648 4 year warranty coverage + AUR – Elo P/N: E894921 5 year warranty coverage + AUR – Elo P/N: E895125 |
| MTBF | 50,000 hours demonstrated |
| What’s in the Box | QIG, User Manual CD, VGA cable, serial cable (attached if support combo), power cord, USB cable |
Ordering Information
| Model | Part Number | Technology | Interface | Surface Treatment | Color | Availability |
| 1715L | E603162 | AccuTouch | Serial/USB | Antiglare | Dark Gray | Americas, EMEA |
| E719160 | IntelliTouch | Serial/USB | Antiglare | Dark Gray | Americas, EMEA |
