BCS-329-GX200-Two-Wheel-Tractor-product-image

Service Bulletin 2-10: Cable Quick Reference Guide – 1995 & Newer BCS Tractors

300, 600 & 700 Series Tractors
ModelSerial NumberThrottleClutchOPC SafetyForward
Reverse		DifferentialSteering
Release		Brake R/L & Parking
329 GX2001037311 – ——-580.56815580.56899580.56898580.56848N/A580.57422580.56849 *7
329 GX2401044236 – ——-580.56815580.56899580.56898580.56848N/A580.57422580.56849 *7
339 GX3401037050 – ——-580.56815580.56899580.56898580.56848580.56848580.57422580.56849 *7
620ALL580.42067580.57302580.52304580.43223N/AN/AN/A
620 Max——- – 867449580.56812580.57357580.57415580.49670N/A580.57211580.56843
620 Max867450 – —–580.56812580.57357580.57407580.49670N/A580.57211580.56843
660 HY985938 – —–580.C0422580.56523580.56524580.C0368 (x2)N/A580.57211580.56580 (x3)
710100000 – 116637See IPL580.47629580.47568N/AN/AN/AN/A
710RS116638 – ——580.43219580.47629580.47568N/AN/AN/AN/A
710ES116638 – ——580.43219580.53035580.47568N/AN/AN/AN/A
710GX5ALL580.48012580.47629580.47568N/AN/AN/AN/A
710GX8ALL580.48012580.47629580.47568N/AN/AN/AN/A
710-SP170864752 ——580.48012580.47629580.47568580.57286N/AN/AN/A
710-CH270988033 —–580C1037580.56846580.56837580.57286N/AN/AN/A
712GX5——- – 748214580.48012580.53035580.57401N/AN/A580.57284N/A
712GX5748215 – 860516580.48012580.53035580.57401N/AN/A580.57284N/A
712GX5860517 – ——580.56815580.53035*3N/AN/A580.56193N/A
712GX8——- – 748214580.48012580.53035580.57401N/AN/A580.57284N/A
712GX8748215 – 860516580.48012580.53035580.57416N/AN/A580.57284N/A
712GX8860517 – 963639580.56815580.53035580.57416580.56848N/A580.56193N/A
712GX8963640 —-580.56815580.57285580.57416580.56848N/A580.56193N/A
716100000 – 109018SEE IPL580.47629580.47568580.49670N/AN/AN/A
716109019 -12466358057330580.47629580.47568580.57286N/AN/AN/A
716RS124664 – ——-58043219580.47269580.47568580.57286N/AN/AN/A
716ES124664 – ——-58043219580.53035580.47568580.57286N/AN/AN/A
718——- -748214580.43219580.53035580.57401**1 & * 2N/A580.57284N/A
718748215 – 860516580.48012580.53035580.57416580.57329N/A580.57284N/A
718860517 – 963639580.56815580.53035580.57416580.56848N/A580.56193N/A
718963640 – ——-580.56815580.57285580.57416580.56848N/A580.56193N/A
720100000 – 109018580.42486580.47629580.47568580.49670N/AN/AN/A
720109019 – 124663*4580.47629580.47568580.57286N/AN/AN/A
720RS124664 – ——580.43219580.47629580.47568580.57286N/AN/AN/A
720ES124664 – ——580.43219580.53035580.47568580.57286N/AN/AN/A
722——- -748214580.43219580.53035580.57401**1 & * 2N/A580.57284N/A
722748215 – 860516580.48012580.53035580.57416580.57329N/A580.57284N/A
722860517 – 963639580.56815580.53035580.57416580.56848N/A580.56193N/A
722963640 – ——580.56815580.57285580.57416580.56848N/A580.56193N/A
730100000 – 109018580.42486580.47629580.47568580.49670N/AN/AN/A
730109019 – 124663580.57335580.47629580.47568580.57286N/AN/AN/A
730RS124664 – ——580.57335580.47629580.47568580.57286N/AN/AN/A
730ES124664 – ——580.57335580.53035580.47568580.57286N/AN/AN/A
730GX11ALL580.57335580.47629580.47568580.57286580.57286N/AN/A
732GX11——- -753750580.48012580.53035580.57401580.57329580.57286580.57284N/A
732GX11753751 – 762215580.48012580.53035*3580.57329580.57286580.57284N/A
732GX11762216 – 863995580.48012580.53035*3580.57329**1 & * 2580.57284N/A
732GX11863996 – 870666580.56815580.57343580.57416580.57329580.57297580.57284N/A
732GX11870667 – 963639580.56815580.57343580.57416580.56848580.56848580.56193N/A
732GX11963640 – ——-580.56815580.57285580.57416580.56848580.56848580.56193N/A
732CH395 RS1025030 – ——580.C1037580.56844580.57416580.56848580.56848580.56193N/A
732CH395 ES1025030 – ——-580.C1037580.57343580.57416580.56848580.56848580.56193N/A
739 PS918324 – ——580.56815580.56899580.56898580.56848580.56848580.57422580.56849
740 PS898000 – ——580.56816580.56188580.56187580.56846580.56847580.57422580.56844 *6
580.56845 *7
749 PS918070 – ——580.56816 H*5

580.56815 D*5

580.56838580.56839580.56846580.56847580.57369580 56844 *6
580.56845 *7
750 PS898000 – —–580.56816580.56838580.56839580.56846580.56847580.57369580.56842 *6|580.56841 *7
770 HY1027889 – —–580.56811580.C1710580.C1711580.C1714580.C1713580.57422580.56842 *6
580.C1712 *7
779 HY1077280 – —–580.56816580.C1755580.C1756580.C1714580.C1713580.57369580.56897 *6

580.56896 *7

800 & 900 Series Tractors
ModelSerial NumberThrottleClutchOPC SafetyReverseDifferentialSteering ReleaseBrake R/L & Parking
8301000 – 3162580.42486580.47647580.47568580.43216580.43223580.47702580.49663 *6
8303163 – 6663580.57336580.47647580.47568580.43216580.43216580.47702580.49663 *6
830 ES6664 – 700000580.48012580.57343580.47568580.43216580.43216580.47702580.49663 *6
830 RS6664 – 700000580.48012580.47647580.47568580.43216580.43216580.47702580.49663 *6
8501000 – 3162580.48012580.47647580.47568580.43216580.43223580.47702580.49663 *6
8503163 – 6663580.48012580.47647580.47568580.43216580.43216580.47702580.49663 *6
850 ES6664 – 700000580.57336580.57343580.47568580.43216580.43216580.47702580.49663 *6
850 RS6664 – 700000580.57336580.47647580.47568580.43216580.43216580.53049580.49663 *6
852710340 – 783461580.57336580.57343580.57401580.57289580.57289580.47702580.52301 *6
852783462 – 963589580.57355580.57354580.57418580.43216580.43216580.57369580.57205 *6
852963590 – 981377580.57355580.57354580.57418580.56846580.43216580.57369580.57205 *6
852 ES981378 – —580.57355580.57354580.57418580.56846580.43216580.57369580.57205 *6
852 RS981378 – —580.57355580.C1018580.57418580.56846580.43216580.57369580.57205 *6
853710340 – 783461580.57336580.57343580.57401580.57289580.57289580.53049580.43253 *6
853783462 – 963589580.57355580.57354*3580.43216580.43216580.53049580.57205 *6
853963590 – 981377580.57355580.57354580.57418580.56846580.43216580.57369580.57205 *6
853 ES981378 – —580.57355580.57354580.57418580.56846580.43216580.57369580.57205 *6
853 RS981378 – —580.57355580.C1018580.57418580.56846580.43216580.57369580.57205 *6
853D783462 – 874156580.48012580.57354580.57421580.43216580.43216580.57369580.57205 *6
853D874157 – 963589580.48012580.57354580.57421580.43216580.43216580.57369580.57205 *6
853D963590 – 981377580.48012580.57354580.57421580.56846580.43216580.57369580.57205 *6
853D981378 – —580.48012580.57354580.57421580.56846580.43216580.57369580.57205 *6
945All580.43219580.49663580.49501N/A580.49670N/A580.49663 *6
946All580.48012580.47647580.47568580.57328580.43223580.47702580.49663 *6
948700007 – 717605580.57336580.57343580.57401580.57289580.57289580.53049580.52301 *6
948717606 – 783461580.57355580.57354580.57401580.57289580.43216580.53049580.43523 *6
948783462 – ——580.57355580.57354*3580.43216580.43216580.53049580.57205 *6
* Numbers listed are for the wiring harness that goes from OPC (red lever) to the engine ignition system.
*1 & *2 Cables changed during production with no serial number breaks available.
Measure the cable to find the appropriate length. (The majority of units marked as *2 will use 580.57297 cable.)
Reference          Cable Part #                     Sheath Cable/Wire
*1                      580.57286                               39.75”     48.5”
*1                      580.57329                               38.5”       44.5”
*2                      580.57297                               39.5”       49.5”
*2                      580.57287                               42.25”     52”
*3 On early models, the safety switch was top-mounted. Later units use a safety switch that is a mid-mounted, cable-activated switch. Part numbers for Mid-Mount system:|
Description             Cable Part #
Mid-Mount Safety Switch:                 580.57415
Safety Switch Cable GX160/GX240:    580.57416
Safety Switch Cable GX390:            580.57418
Wire Harness (Engine to Kill Switch):     580.57401
*4 Units will have one of the following types of throttle controls:
Type  Cable Part #
Plastic Control / Horizontal Movement:     580.57331
Standard Metal Throttle Lever:    580.57344
*5 Units may have a Honda Gas or Kohler Diesel engine on the 749 Power Safe Model
580.56816 Honda
580.56811 Diesel
*6 Units with Right and Left brakes. These will require 2 cables with the same part number (one cable for each brake).
*7 Units that have a designated parking brake and will only require one cable.
*8 In the event you cannot find the specific cable listed here or in the serial number specific IPL, please refer to SB 2-11.
