OH02A1S Medical RGB-IR Image Sensor Reduces Endoscope Size Cost Power and Heat
Product Information:
The OH02A1S is a 1080p medical RGB-IR image sensor that offers a
range of benefits, including reducing endoscope size, cost, power,
and heat by half. It features a programmable memory on-chip and
consumes only 90 milliwatts at full power, resulting in less heat
generation for enhanced patient comfort. The image sensor is
currently available in an RW package, and the chip-scale package
will be made available based on project demand.
For more information, visit www.ovt.com.
Product Usage Instructions:
Ordering Information:
To order the OH02A1S image sensor or inquire about its
availability, please contact the manufacturer or visit their
website.
Applications:
The OH02A1S image sensor is suitable for various applications in
the medical field and beyond.
Product Features:
- 1080p resolution
- Reduces endoscope size, cost, power, and heat by half
- Programmable memory on-chip
- Consumes only 90 milliwatts at full power
- Enhances patient comfort
- Available in RW package
- Chip-scale package availability based on project demand
Technical Specifications:
The technical specifications for the OH02A1S image sensor are
not provided in the text extract. Please refer to the product
documentation or contact the manufacturer for detailed technical
specifications.
Functional Block Diagram:
The functional block diagram of the OH02A1S image sensor
includes various components such as the image sensor core, column
sample/hold, image sensor processor, image array, AMP, 10-bit ADC,
image interface, MCP/N MDP/N[1:0], row select ISP FIFO, MIPI TX,
gain control, control register bank, PLL timing generator and
system control logic, SCCB interface, and XVCLK XSHUTDN2 XSHUTDN TM
GPIO FSIN PWDNB STROBE SCL SID SDA.
Contact Information:
For further inquiries or assistance, you can contact OmniVision
Technologies, Inc. using the following details:
4275 Burton Drive Santa Clara, CA 95054 USA
Tel: + 1 408 567 3000
Fax: + 1 408 567 3001
Website: www.ovt.com
OMNIVISION reserves the right to make changes to their products
or to discontinue any product or service without further notice.
OMNIVISION, the OMNIVISION logo, and PureCel are registered
trademarks of OmniVision Technologies, Inc. All other trademarks
are the property of their respective owners.
OH02A1S
1080p product brief
Medical RGB-IR Image Sensor Reduces Endoscope Size, Cost, Power and Heat by Half
OMNIVISION’s OH02A1S is the world’s first RGB-IR medical image sensor, providing simultaneous white-light RGB captures and infrared monochrome captures in a single CMOS sensor for cancer diagnosis and treatment. While endoscopic precancer and cancer detection procedures are performed using IR light, surgeons also need RGB light to confirm any abnormalities detected using infrared. Previously, this could only be accomplished by integrating two independent imager sensors, which resulted in endoscopes with a larger size, higher cost and higher power consumption, thereby excessively heating the tip of the endoscope.
Built on OMNIVISION’s PureCel® pixel architecture, the OH02A1S offers 4×4 binning for the highest image quality, high quantum efficiency for excellent low-light performance, and a high dynamic range for clarity in scenes with widely contrasting bright and dark areas. The sensor can provide 1080p (1920 x 1080) resolution at 60 frames per second (fps) or 720p (1280 x 720) at 90 fps, via a 2-lane MIPI serial output. The OH02A1S also integrates 2 kilobits of one-time
programmable memory on-chip. It consumes just 90 milliwatts at full power, generating less heat for greater patient comfort.
With the OH02A1S, both IR and RGB images can now be captured using a single chip, allowing the surgeon to switch between high quality RGB and IR in real time, or to display both images simultaneously on one (overlay) or two (side-by-side) monitors. Additionally, the smaller size and reduced heat allow the endoscope to reach much farther into the body than was previously possible with larger-outerdiameter, two-imager designs. Alternatively, designers can use the extra space to add more or larger illumination (fiber or LED), or a larger working channel for endoscopic tools.
The OH02A1S image sensor is available today in an RW package and the chip-scale package will be available based on project demand.
Find out more at www.ovt.com.
OH02A1S
Ordering Information
· OH02A1S-GA5A (RGB-Ir, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
Applications
· medical endoscopes · veterinarian endoscopes
· dental equipment · industrial endoscopes
Product Features
· 1.4 µm x 1.4 µm pixel
· optical size of 1/6″
· programmable controls for: – frame rate – mirror and flip – cropping – windowing
· supports output formats: 10-bit RGB-Ir RAW
· supports images sizes: – 1080p (1920 x 1080) – 720p (1280 x 720)
· standard serial SCCB interface
· up to 2-lane MIPI serial output interface (supports maximum speed up to 1000 Mbps/lane)
· embedded 2 kilobits of one-time programmable (OTP) memory for customer use
· add staggered HDR raw data output
· interleave row high dynamic range (iHDR) output
· programmable I/O drive capability
Technical Specifications
· active array size: 1920 x 1080
· maximum image transfer rate: – 1080p: 60 fps – 720p: 90 fps
· power supply: – core: 1.2V – analog: 2.8V – I/O: 1.8V
· power requirements: – active: 90 mW – standby: 210 µA – XSHUTDN: 0.6 µA
· output format: 10-bit RGB-Ir RAW
· lens size: 1/6″
· temperature range: – operating: -30°C to +85°C junction temperature – stable image: 0°C to +60°C junction temperature
· lens size: 1/6″
· lens chief ray angle: 33° non-linear
· scan mode: progressive
· pixel size: 1.4 µm x 1.4 µm
· image area: 2728.8 µm x 1549.8 µm
· die dimensions: – COB: 3825 µm x 2889 µm – RW: 3875 µm x 2939 µm
Functional Block Diagram
OH02A1S
image sensor core
column sample/hold
image sensor processor
image array
AMP
10-bit ADC
image interface
MCP/N MDP/N[1:0]
row select ISP FIFO
MIPI TX
gain control
control register bank
PLL PLL timing generator and system control logic
SCCB interface
XVCLK XSHUTDN2
XSHUTDN TM
GPIO FSIN PWDNB STROBE SCL
SID SDA
Version 1.4, June 2023
