CCS568AA15LG Compact Angle Adapter Plate
Product Information:
Product Name: Placa Para Adaptar Angulos
Model: 87567787
Revision: B
System Compatibility: 50, 60, 80, and 80/140
Dimensions:
- A: 4.72 in (120 mm), 4.72 in (120 mm), 4.72 in (120 mm), 7.48
in (190 mm) - B: 3.15 in (80 mm), 3.15 in (80 mm), 3.15 in (80 mm), 3.93 in
(100 mm)
Product Usage Instructions:
To use the Placa Para Adaptar Angulos, follow these steps:
- Identify the angle you want to adapt.
- Ensure you have the necessary components, including the tube
tragrohr, flange coupling, and system tubes. - If using System 50, 60, or 80, refer to the corresponding tube
tragrohr and tubes. - If using System 80/140, refer to the specific tube tragrohr for
this system. - Attach the flange coupling to the tube tragrohr.
- Connect the system tubes to the flange coupling.
- Repeat steps 5 and 6 for each angle you want to adapt
(4x).
Note: Make sure to refer to the product revision B for any
additional instructions or updates.
COMPACT® Angle Adapter Plate
Neigungsadapter Adaptateur de montage incliné
Placa Para Adaptar Angulos
Rev. B
© 2018 Hoffman Enclosures Inc.
PH 763 422 2211 · nVent.com/HOFFMAN P/N 21323001
87567787
System
50 60 80 80/140
A in. mm 4.72 120 4.72 120 4.72 120 7.48 190
B in. mm 3.15 80 3.15 80 3.15 80 3.93 100
Ø C in. mm .26 6.6 .26 6.6 .26 6.6 .34 8.6
Ø D in. mm 1.97 50 2.52 64 3.58 91 6.06 154
Angle
15° 30° 15° 30° 15° 30° 15°
1
2
3
(4x)
(4x)
(4x)
– 2 –
© 2018 Hoffman Enclosures Inc.
PH 763 422 2211 · nVent.com/HOFFMAN
87567787
Tube Tragrohr Tubes Tubo
Flange Coupling Flanch Kupplung Embout pivotant Acoplamiento de brida
Angle Adapter Plate Neigungsadapter Adaptateur de montage incliné Placa Para Adaptar Angulos
Flange Coupling Flanch Kupplung Embout pivotant Acoplamiento de brida
Tube Tragrohr
Tubes Tubo
System 50, 60, 80
87567787
© 2018 Hoffman Enclosures Inc.
System 80/140
PH 763 422 2211 · nVent.com/HOFFMAN
– 3 –
Rev. B
© 2018 Hoffman Enclosures Inc.
PH 763 422 2211 · nVent.com/HOFFMAN P/N 21323001
87567787
