Indoor | 15” Clear Ice Machine Square Cube:
Gravity Drain and Pump Models
15 Inch Clear Ice Machine Indoor Square Cube Ice Maker
| Model | Details |
| Control Type | Electronic Capacitative Touch with OLED Screen |
| Indoor or Outdoor | Indoor |
| Built-in Installation | Inset, Frameless / Overlay and Framed Cabinet Styles |
| Ice Size | 7⁄8″ x 7⁄8″ x 7⁄8″ |
| Ice Weight (g) per unit | 11 g / 0.024 lbs |
| Ice Quantity per cycle | 40 per Slab (1 lb) |
| Ice Production Capacity | 75 lbs |
| Ice Storage Capacity | 25 lbs |
| Refrigerant Type | R290 |
NOTE: For Gravity drain models, the drain hole cannot exceed 7 inches above the floor.
For Pump models, the drain hole should be no lower than 7 inches and no higher than 4 feet above the floor.
| Plumbing Water | Details |
| Water Inlet Adapter | 1⁄4″ OD Compression Fitting* |
| Water Pressure Operating Range (psi) | 20 psi – 80 psi |
| Integrated Water Filter System | Yes |
| Water Usage | 12 1⁄2 gallons per 100 lbs of ice |
| Factory Installed Drain Line | 10 feet |
| Drain Required | Yes (See manual for details) |
| Replacement Water Filter | Part No. 601503 |
*Water line not included
*Dimensions are the same for Panel Ready unit when 3⁄4” panel applied
| Electrical | Details |
| Electrical Requirements | 115 V / 60 Hz |
| Volt Range | 104 V ~ 127 V |
| Electrical Service | 15 amp |
| Running Amps | 1.9 amps |
| Approvals – Certifications | Details |
| Energy Star | Yes |
| ETL Sanitation | Yes |
| UL Commercial | Yes |
The Legacy Companies warrants to the original purchaser of its SAPPHIRE products that they will be free from defects in materials and workmanship for the following time periods from the date of purchase shown on the sales receipt:
Two (2) Years Parts & On-Site Labor | Five (5) Years Compressor Warranty (Parts Only)
See complete warranty for details.
SapphireAppliances.com | 1.866.754.6672
The Legacy Companies
3355 Enterprise Avenue, Suite 160, Fort Lauderdale, FL 33331
All specifications are subject to change without notice.
SAPSS02
072522
