KA02 Stainless Steel 200W In 2U Rack Amplifier
Product Information: Kommander-KA02 Amplifier Unit
The Kommander-KA02 is an amplifier unit that can be mounted on
any surface with any orientation. It comes with a K-BRK assembly
mounting kit that includes screws and a bracket for easy
installation. The unit has lateral screws positioned at the center
for easy access to its internal components.
The following are the dimensions of the mounting kit:
- Distance between two holes: 70mm (2.8in)
- Torx T10 screw size
- Plate dimensions: 16mm (0.6in) x 32mm (1.3in)
- K-BRK bracket dimensions: 140mm (5.5in) x 18mm (0.7in)
Product Usage Instructions
- Identify a comfortable position for the amplifier on the
mounting surface and make two holes at a distance of 70 mm (2.8 in)
to each other. - Install the K-BRK bracket on the surface using the provided
mounting kit. - Focus on the Kommander-KA02 unit and unscrew the lateral screws
positioned at the center of the unit. - Remove the plates from the bottom of the amplifier and keep the
screws aside for further use. - Position the amplifier unit on the bracket and use the screws
to secure it.
Note: Use Torx T10 screwdriver to unscrew and secure the
screws.
Mounting Kits
The Kommander-KA02 amplifier is designed to be controlled remotely, with no need of direct access the unit. This makes the devices easy to install, either in a recess or on top of a shelf or inside of a rack cabinet. Two mounting kit are available: · K-BRK bracketing system for single KA02 unit · K-RACK2 rack mount 1U for three KA02 units.
K-BRK Assembly
Kommander-KA02
User Guide
Torx T10
16mm [0,6in] 32mm [1,3in]
70mm [2,8in] 140mm [5,5in]
18mm [0,7in]
1. The Kommander-KA02 amplifier unit can be mounted on any surface with any orientation. Identify a comfortable position for the amplifier on the mounting surface and make two holes at the distance of 70 mm (2.8 in) to each other. Install the K-BRK bracket on the surface with the provided mounting kit.
3. Position the amplifier unit on the bracket and use the screws to secure it.
Torx T10
2. Focus on the Kommander-KA02 unit: unscrew the lateral screws positioned at the center of the unit and remove the plates from the bottom of the amplifier. Keep the screws aside for further use.
17
