B85 Motherboard
Product Information:
The B85 motherboard is manufactured by SZ HUANAN SANXIAN
TECHNOLOGY CO.,LTD. It supports 16GB DDR3 1600/1333MHZ ECC CPUDRAM
and has 2 x SATA3.0(6GB/s), 2 x SATA3.0(3GB/s), 4 x USB2.0, 2 x
USB3.0, 1 x PS/2, 1 x RJ45, 1 x VGA, 1 x HDMI, and 1 x DVI ports.
It also has a Realtek 1000MB/S LAN port and a PCIe 3.0 x16 slot
along with a PCIe2.0 x1 and an M.2 NVME PCIe 2.0X4 (key
M)2242/2260/2280 slot.
Product Usage Instructions:
- Before handling the motherboard, discharge your body static by
touching other metal objects to prevent electrostatic discharge
(ESD) and damage to the product. - Make sure all parts are firmly connected and the motherboard is
held by its border when taking it out of the box to avoid touching
sensitive parts. - If not needed, put the motherboard in an anti-static container
or on an anti-static pad. - Install the motherboard inside the computer case and ensure all
parts are firmly connected without any loose screws or metal
components before turning on the computer. - Install the necessary drivers for the B85 chipset, Intel,
Realtek sound card, and LAN driver for win7/win10 operating
systems. - Configure the BIOS settings using the CMOS SETUP and CMOS SRAM
options to ensure proper system functioning.
User Manual
B85
SZ HUANAN SANXIAN TECHNOLOGY CO.,LTD.
WWW.HUANANZHI.COM
………………………………………………………. 2 ………………………………………………………. 3 ……………………………………………………………… 4 ………………………………………………………. 5 I/O …………………………………………………. 6 …………………………………………………. 7 …………………………………………. 11 BIOS …………………………………………………… 13
01
ESD
,
,
,,
,,
02
, , ,
1.B85 2.SATA1 3.I/O 4. 5.
03
CPU® LGA1150 I3/I5/I7 4 ® TM ® LGA1150 E3 V3 ® TM ® LGA1150 4 ® TM
RAM2*DIMM 16GB DDR3 1600/1333MHZ ECC CPUDRAM
I/O2 x SATA3.0(6GB/s) 2 x SATA3.0(3GB/s) 4 x USB2.0 2 x USB3.0 1 x PS/2 1 x RJ45 1 x VGA 1 x HDMI 1 x DVI
Realtek Realtek 5.1 /
1 x Realtek 1000MB/S 1 x PCIe 3.0 x16
1 x PCIe2.0 x1 1 x M.2 NVME PCIe 2.0X4 (key M)2242/2260/2280
04
8Pin CPU 3
DDR3*2 4
PS/2
VGA DVI(
24Pin
HDMI
USB2.0*2
USB3.0*2 USB2.0*2 PCI-E X16
PCI-E X1 AUDIO
RESET SW
POWER SW
HDD LED
USB2.0
USB3.0
POWER LED
1-1 B85
SATA3.0 SATA2.0
05
I/O
PS/2
VGA DVI
HDMI USB 2.0
LAN USB 2.0 USB 3.0
1-2 I/O
/
10 Mbps 100 Mbps 1 Gbps
1-3 LAN
1-4
I/O06
“1” 1
07
2-1 CMOS
9
1
10
2
1
MIC+ 2
Ground
3
Vbias 4 AuD_Vcc(AVCC)
5 L_R_Out 6 R_Out Back
7
N.C
8
Key
9 L_L_Out 10 L_Out Back
2-2
9
1
10
2
1 VCC 2 VCC
3 D- 4 D-
5 D+ 6 D+
7
GND
8
GND
9
N.C
10
KEY
2-3 USB
PCI-EX16 PCI-EX1
2-4 PCI
10
2
9
1
1
– 2 –
3
– 4 –
5
–
6 –
7
– 8 –
9
N.C
10
KEY
2-5 F_PANEL1
08
CPU LGA1150 CPU Pin1
2-6 CPU
1 2
4
3
30°
5
1. 2.
3. M.2M.2
4. M.230 M.2
5. M.2
09
2 -7 M.2
1
1.
2
2.
3 3.
2
2-8
1
1.
3 2
2. 3.
5
4.
4 5.
6.
6
2 -9
10
SATA 3.0
SATA 2.0
2 -10 SATA
1.
B85Chipset Driver
Intel
B85 Suond Card Driver Realtek
B85 LAN Driver
win7/win10 win7/win10 win7/win10
2.Intel
:—— “” :Internet — “”
11
3.
3.1 HD Audio /B85 SUOND/Realtek_Audio_XP_Win7_ 8/setup.exe “” “”
3.2 HD Audio WINDOWS “””/ ” / “” / ” “Realte High Definition Audio Driver”” / ”
4. Setup.exe “” “” “”
12
“” “” 5. B85 LAN/RTL810x_8111_win7/setup.exe “” “” “”
BIOS
CMOS SETUP CMOS SRAM CMOS SRAM BIOSPOST(Power On Self Test) “Delete”–AMI BIOSCMOS SETUP “F7″
13BIOS
1.
Main Advanced Chipset
Boot
Security Save
Exit
Main System Overview() Advanced Advanced Settings(BIOS) BIOS
Chipest Advanced Chipest Settings() Boot Boot Settings()
Security Security Settings(BIOS)
Save Save Setting()
Exit Exit Options() // /
BIOS14
DIRECTORY
Safety Precautions ……………………………………………….. 2 Packing ……………………………………………………………… 3 Brief Introduction …………………………………………………. 4
Motherboard Diagram ………………………………………… 5
Rear I/O panel ……………………………………………………… 6
Installation and Settings ………………………………………. 7
Drivers Installation
…………………………………………… 11
BIOS Settings ………………………………………………………. 13
0011DDIIRREECCTTOORRYY
SAFETY PRECAUTIONS
Products could probably be damaged due to electrostatic discharge(ESD). Please follow these steps below for a successful computer assembly. Make sure all parts are firmly connected; otherwise, it might lead to the failure of recognizing components or starting the computer. In order to prevent products from being damaged by ESD, please make sure to discharge your body static by touching other metal objects before taking the motherboard out of box.
Hold the border of motherboard when taking it out. Do not touch the sensitive parts of motherboard. Please put the motherboard in an anti-static container or on anti-static pad if not needed. Before turning on the computer, make sure all parts inside the case are firmly connected without any loose screws or metal components. Do not start the computer before installation finished, otherwise it might result in permanent damage to the computer parts or even injury to the user.
If you need any assistance in the process of installationplease contact our after-sales customer service or reach us on HUANANZHI official E-mail:[email protected] for professional technical support. Prior to installation or disassembly, please switch off the power and pull the power cable from the socket.
SSAAFFEETTYYPPRRECEACUAUTITOIONSNS 0022
Keep the motherboard away from moisture. Keep the user manual for future reference. Before plugging the power supply, please make sure the socket provides the corresponding voltage. In any of the following situations, please keep the motherboard and power cable in a safe place. Do not put anything onto the power cable. In the event of any of the following conditions, have the board checked by a service technician: Liquid penetrated into the computer. Motherboard is exposed to moisture. Motherboard does not work even if you follow the instructions on user manual. Motherboard fell off to the ground and got damaged. Motherboard has clear signs of damage.
PACKING
Please confirm that the motherboard is properly packaged upon purchase of the product. If there is any damage to packaging or lack of accessories, contact us as soon as possible.
1.1*HUANANZHI B85 Motherboard 2.1*SATA Data Cable 3.1*I/O Shield Back Plat 4.1* User Manual 5.1*Warranty Card
0033PaPcakcikningg
BRIEF INTRODUCTION
Features
CPUIntel ® LGA1150 processor I3/I5/I7 4th Intel ® Core TM Intel ® LGA1150 processor E3 V3 Series Intel ® Xeon TM Intel ® LGA1150 processor 4th Intel ® pentium TM
RAM2*DIMM supports up to 16GB DDR3 1600/1333MHZ Non-ECCmemory Two-Channel Memory Architecture Actual memory data rate depends on CPU type and DRAM module
I/O effects2 x SATA3.0 (maximum transfer speed up to 6GB/s) 2 x SATA3.0 (maximum transfer speed up to 3GB/s) 4 x USB2.0 interface 2 x USB3.0 ports 1 x PS/2 Mouse and Keyboard port 1 x RJ45 Network card interface 1 x VGA 1 x HDMI-Compatible 1 x DVI
Audio: Realtek Audio Transcoder Realtek 5.1 Channel High Fidelity Audio Audio output:Front Out/Front Speaker Out Audio input:Microphone inputAudio input
Ethernet: 1 x Realtek PCle 1000MB LAN Expansion slot1 x PCIe 3.0 x16
1 x PCIe 2.0 x1 1 x M.2 NVME PCIe 2.0X4 (key M)2242/2260/2280
BrBierifeIfnItnrotrdoudcuticotnion0044
THE MOTHERBOARD DIAGRAM
8Pin CPU Power SuppIy 3 Pin Fan Interface
PS/2
DDR3*2 Slot 4 Pin Fan Interface
Rear I/O Panel
PS/2
VGA DVI
USB 2.0 HDMI-compatible
LAN USB 2.0 USB 3.0
Audio Port
VGAon DVI Under
HDMI-compatible
24Pin power Interface
1-2 Overall Rear I/O Panel Display
USB2.0*2
USB3.0*2 Gigabit Ethernet(On)
USB2.0*2(Under) Audio Port
PCI-E X16 Interface
SATA 3.0
Connection/Work Light
Status Description Turn Off Network Not Connected Yellow Network Connected Flicker Network In Use
Speed Signal
Status Turn Off Green Orange
Description Transmission rate 10 Mbps Transmission rate 100 Mbps Transmission rate 1 Gbps
1-3 LAN Port Status Table
PCI-E X1 Interface JAUDI
RESET SW
HDD LED
JUSB3.0 JUSB2.0
POWER SW
POWER LED
1-1 B85 MotherBoard Illustration
SATA 2.0
Audio Port Audio Input Audio output/ Front speaker output Microphone input
1-4 Audio Port Configuration
05 Motherboard Diagram
Rear I/O Panel 06
Installation And Settings
NOTICE please check the motherboard where all pins marked with number”1″or white bold line are position”1″.
2-1 Clear CMOS Jumper CLR-CMOS
9
1
10
2
1
MIC+
2
Ground
3
Vbias
4 AuD_Vcc(AVCC)
5 L_R_Out 6
R_Out Back
7
N.C
8
Key
9 L_L_Out 10 L_Out Back
2-2 Front Audio Output Ports
07 Installation And Setup
9
1
10
2
1
VCC
2
VCC
3
D-
4
D-
5
D+
6
D+
7
GND
8
GND
9
N.C
10
KEY
2-3 Expansion Ports
PCI-EX16 PCI-EX1
2-4 PCI-E Slot
10
2
9
PWR LED+ PWR LEDPWR_SW PWR_SW
N.C
1
HDD LED+ HDD LEDRESET_SW RESET_SW
KEY
2-5 F_PANEL1 Ports
Installation And Setup08
To place the CPU properly on the motherboard, the SURFACE of the LGA1150 CPU has two pairs of starting points and a golden triangle. The golden triangle indicates Pin1
Figure 2-6 CPU installation
1 2
4
3
30°
1. Remove the screw from the screw base 2. Remove the screw base
3. Tighten the screw base screwed into the length M.2 module to the M.2 interface distance hole
4. Insert your M.2 module into the M.2 interface at a 30 degree angle
5. Place the screw on the trailing edge
notch of your M.2 module and tighten to
5
the screw base
9 Installation And Setup
2-7 M.2 Interface Installation
1. Pull the clips at both ends of the
1
memory slot outwards, and the
memory strip corresponds to the
protruding position of the slot to
determine the direction of installa-
tion
2
ON
DIP
1 2345678
2. Align the memory strip to the
2
3 slot and press down
3. Make the clips on both ends of
the slot spring up automatically
2-8 Memory Installation
1.Use a screwdriver to remove the bezel and screws on the main unit
1
3 2
2.Need to pick up the card slot of the card slot when installing the graphics card 3.Insert the graphics card into the card slot of the graphics card
4.After the installation is in
5
place, the chuck will automati-
4 cally return to its position.
5.Secure the graphics card to
6
the chassis with screws
6.Install the power cord
2-9 Graphics Card Installation
Installation And Setup10
SATA 3.0
SATA 2.0
2-10 SATA Interface
Drivers Installation
Driver Directory
Driver Description Operating System
B85 Chipset Driver B85 Suond Card Driver
B85 LAN Driver
Intel chip information installation
Realtek series sound card driver installation
Realtek network card driver installation
win7/win10 win7/win10 win7/win10
2.Intel Chip Information Installation Run”Control Panel – System – Hardware – Device Manager” Click the right mouse button to change the driver’s hardware device and proceed with the installation below Option: Propertyl – Update driverl – Not connect to Internet Manually installation Find the corresponding directory Select “Next step”
11Drivers Installation
3.Audio driver installation Before this installation, please check the model of the audio chip on the motherboard first(you may refer to this manual), Select the proper driver accordingly for installation.
3.1 Audio driver installation (take HD Audio series for example) Run “driver installer”: /B85 SUOND/Realtek_Audio_XP_Win7_ 8/setup.exe Click on “next”to continue,and then”finished” The system will automatically restart itself to finish the installation
3.2 Driver installation of external video card Getting into Windows desktop, choose “setting”/ “control”,and then “add/remove programs”. Later, choose “Realtek High Definition Audio Driver” in the menu and click on “add/remove”so that the driver will be automatically removed.
4.Driver installation of external video card Run”driver installer”, take Setup.exe, click on “next”- “yes” -“next” -“next”and”finished”
Drivers Installation12
The system will automatically search for devices to complete the installation
5.Driver installation of network Run “driver installer”: B85 LAN/RTL810x_8111_win7/setup.exe click on “next”-“installation”-“finished” and restart the computerthe system will automatically search for devices to complete the installation.
BIOS Settings
In order to enable the computer to work well or execute specific functions, CMOS SETUP normally stores all kinds of data in CMOS SRAM of the motherboard. When the computer is shut down, motherboard’s battery will supply power to CMOS SRAM. When the computer is turned on and starts POST(Power On Self Test), press”Delete/Del”key to enter into AMI BIOS CMOS SETUP main page. Motherboard warm boot key is”F7″ Menu: please pay attention to every option in the settings menu. When there is a triangle shaped symbol on the left side of menu, it means that you choose this sub-menu,so a pop-up sub-menu will be available.
13BIOS Settings
1.Main Menu Function
Main Advanced Chipset Boot Security Save Exit
Main System Overview Date/Time settings, HDD specs/Monitor type settings. Advanced Advanced Settings BIOS special function settings, such as virus alert, booting disk priority etc. Chipest Advanced Chipest Settings Boot Boot Settings Security Security Settings Save Save Setting Exit Exit Options Exit settings include loading of optimized defaults value/ loading of fail-safe defaults / discarding changes/ exiting without saving.Exit settings include loading of optimized defaults value/ loading of fail-safe defaults / discarding changes/ exiting without saving.
BIOS Settings14
