574325 2 Gang Wireless and Batteryless Lighting Control
Product Information:
The 2-gang wireless and batteryless lighting control is a
versatile device that allows you to control your lighting system
wirelessly without the need for batteries. It is compatible with
various wired products such as switches, micromodules,
socket-outlets, and latching relays. The control operates in the
frequency bands of 2.4 – 2.4835 GHz with a power level of less than
20 mW. The pack includes two wireless controls with ON/OFF and
dimming functions, along with stickers for easy identification.
Product Usage Instructions:
- Start the configuration: Press the
configuration button of the Module Control or press the middle of
the wireless master switch until its light briefly turns green.
Ensure all wired products’ lights turn green. - Pair the wireless, batteryless switch to control
connected products:- Tap the product you want to control with the wireless switch
three times. The product’s light will flash rapidly. - If you are controlling a latching relay, press its main button
until the configuration indicator flashes slowly in blue. Release
it and then tap the wired product you want to control three times
with the wireless switch. The indicator light of the product to be
controlled will flash rapidly. - While holding the setup button on the wireless switch, briefly
press the ON or OFF button of the chosen side (1 or 2). - The indicator light of the product to control will briefly turn
blue and then turn green again, indicating successful pairing.
Verify correct pairing by pressing ON/OFF buttons. - You can control multiple switches with the same wireless switch
by repeating the pairing operation for each product you want to
control.
- Tap the product you want to control with the wireless switch
- Complete the installation:
- If necessary, erase the configuration of the wireless switch by
briefly pressing the configuration button of the Module Control or
the middle of the wireless Home/Away master switch. - While holding the setup button on the wireless switch, press
the upper button for 5 seconds. Confirm that the control is
correctly reset by testing ON and OFF commands. - Place the provided stickers on the wireless controls. Test one
sticker on a non-visible area of the wall before fixing them
permanently. - You can also fix the wireless controls permanently to the wall
using screws.
- If necessary, erase the configuration of the wireless switch by
For more information, you can visit the official website at
www.legrandoc.com/067724L.
The product complies with directive 2014/53/EU, and the EU
declaration of conformity can be found on the website: www.legrandoc.com.
2-gang wireless and batteryless lighting control 0 677 24L/74L/80L 0 770 54L – 6 000 88L 5 742 89/96 – 5 743 25 – 5 748 38 7 418 12L/42L/72L
Requires to install the connected starter pack and one or more «… with Netatmo» connected switch, micromodule or socket outlet.
Module Control
Gateway power outlet and home/ away wireless master switch
Or
Pack contents:
2-gang wireless and batteryless lighting control
Short push ON/OFF1 Long push Dim +25% (2 short pushs OFF1)
Short push ON/OFF2 Long push Dim +25% (2 short pushs OFF2)
Stickers x2
Short push ON/OFF1 Long push Dim -25% (2 short pushs OFF1)
Short push ON/OFF2 Long push Dim -25% (2 short pushs OFF2)
Frequency bands: 2.4 – 2.4835 GHz Power level: < 20 mW
Setup button
Do not remove the cover plate
LE12478AC-EN
1 Start the configuration
Press the configuration button of Module Control or press the middle of the wireless master switch until its light briefly turns green, and then stop pressing. All wired products lights will turn green.
Or > 3 s
2 Pair the wireless, batteryless switch to control the connected products (switch, micromodule,
socket-outlet, latching relay). Make sure that the indicator lights on the wired products are green and not flashing. If not, go back to precedent step. 1 .
2
A1
B
C
+
A1
B
C
+
A2
B
C
+
A1 Tap 3 times the product to be controlled with the wireless, batteryless control. The light of the product to control flashes
rapidly.
A2 For the specific case of the latching relay, press the main button of the latching relay until the configuration indicator
flashes slowly in blue, release it then tap the wired product you want to control 3 times with the wireless, batteryless control. The indicator light of the product to be controlled flashes rapidly.
B While holding the “setup” button on the wireless, batteryless control, briefly press the “ON” or “OFF” button of the chosen
side (1 or 2).
C The indicator light of the product to control will briefly turn blue, and then will turn green again.The pairing was successful.
Check the correct pairing by pressing ON/OFF buttons
Multiple pairing: You can control several switches with the same wireless, batteryless switch by repeating the operation for each product that you want to control.
3 Complete the installation
If necessary, erase the configuration of the wireless, batteryless control (factory reset)
Or
< 1 s
< 1 s
+
5 s
To complete your installation, briefly press the configuration of the Module Control or the middle of the wireless Home / Away master switch.
All the indicator lights on the products switch off
While holding the “setup” button on the wireless, batteryless control, press the upper button for 5 seconds. Confirm that your control is correctly reset by making an ON command, then OFF
3
Put the stickers in place
Before fixing the wireless control(s) with the removable stickers provided, test one on a non-visible area of the wall.
H < 2 m H > 2 m
You can also fix the wireless control(s) permanently to the wall with screws.
www.legrandoc.com/067724L
LEGRAND – Pro and Consumer Service – BP 30076 87002 LIMOGES CEDEX FRANCE · www.legrand.com
The undersigned, Legrand declares that the radio-electric equipment type (0 677 24L/74L/80L – 0 770 54L – 6 000 88L – 5 742 89/96 – 5 743 25 – 5 748 38 7 418 12L/42L/72L) complies with directive 2014/53/EU. The full text of the EU declaration of conformity is available on the following website: www.legrandoc.com
Download the app Your installation is ready. You can download the Legrand Home + Control application to control your lights remotely.
FCC ID: 2ACN8-ZLGP1X
IC: 12132A-ZLGP1X
Model : ZLGP18
This device contains licence-exempt transmitter(s)/receiver(s) that comply with FCC RF and Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This device complies with FCC and ISED radiation exposure limits set forth for general population. This device must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Caution: the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
FCC NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on, the user is encouraged to try to correct interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.
Safety instructions Make sure the power supply is disconnected before any intervention. Strictly comply with instructions for installation and use.
4
Model: ZLGP18
